  • Page 1 060R115-000 Issue 1 DataComm V.34 PL Modem Installation and Operation...
  • Page 3 060R115-000 Issue 1 DataComm V.34 PL Modem Installation and Operation...
  • Page 4 General DataComm, Inc. The information in this document is subject to change without notice. General DataComm assumes no responsibility for any damages arising from the use of this document, including but not limited to, lost revenue, lost data, claims by third parties, or other damages.

  • Page 5: Preface

    Preface Scope This manual describes how to install and operate the DataComm V.34 PL (Private Line) modem. The information contained in this manual has been carefully checked and is believed to be entirely reliable. However, as General DataComm improves the reliability, function, and design of their products, is possible that information may not be current.

  • Page 6: Safety Summary

    Wird auch benutzt zum Schutz vor unsicherer Anwendung. WARNUNG Warnung vor drohender Gefahr. Folge bei Nichtbeachtung könnte Tod oder ernsthafte Verletzung sein. GEFAHR Bei Nichtbeachtung führt zum Tod oder ernshafter Verletzung. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 7: Safety Guidelines

    If a wrist strap is not available, periodically touch an unpainted metal surface on the equipment. Never use a conductive tool, like a screwdriver or a paper clip, to set switches. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...

  • Page 8: Service Support And Training

    Service Support and Training Service Support and Training VITAL Network Services, a General DataComm company, is committed to providing the service support and training needed to install, manage, and maintain your GDC equipment. VITAL Network Services provides hands-on training courses through VITAL Network Services Global Technology Training Services.
  • Page 9 060R115-000 Issue 1 V.34 PL Quick Reference Mode FAC0 FAC1 FAC2 FAC3 4W Originate 4W Answer 2W Originate 2W Answer A - Asynchronous Mode of Operation S - Synchronous (FAC0-FAC3) 9 - 9 bits Word Length 10 - 10 bits (FAC0-FAC3)

  • Page 11: Table Of Contents

    Organization........................ iii Safety Summary........................iv Service Support and Training ....................vi Table of Contents Chapter 1: Introduction Description ..........................1-1 DataComm V.34 PL Modem Features................... 1-1 Diagnostics..........................1-2 Equipment List........................1-2 Chapter 2: Installation Unpacking Your Modem ....................... 2-1 Option Jumpers ........................
  • Page 12 Chapter 4: Tests Analog Loopback (ANALOOP).................... 4-2 Analog Loopback with Self-Test................... 4-3 Digital Loopback ........................4-4 Remote Digital Loopback...................... 4-5 Remote Digital Loopback with Self-Test................4-7 End-to-End Self-Test......................4-9 viii DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 13: Chapter 1: Introduction

    Introduction Chapter 1: Overview This chapter describes and lists the features of the DataComm V.34 PL (Private Line) modem, and includes a brief description of the modem’s diagnostics. AL ST RDL DL SEL SD RD MR RS CS CO GD TM ALM V.34 PL...

  • Page 14: Diagnostics

    End-to-End Self-Test (511 or in FSK ALT pattern). Diagnostics To help you restore service quickly in the event of problems, the DataComm V.34 PL offers an array of diagnostics for accurate detection of system faults. Included are Local Loop, Local Loop Self-Test, Digital Loopback, Remote Digital Loopback, Remote Digital Loopback Self-Test, and End-to-End Self-Test.
  • Page 15 DTE cable, male-to-male straight through, DB25-DB25, 25 pins 028H502-0xx Private line cable, 8-pin modular-to-lugs 024H122-xxx Private line cable, model D25S (cut leads) 023H101-xxx 8-pin modular to 8-pin modular S/T 830-028-807 (Sheet 2 of 2) 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 16 Introduction Equipment List DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 17: Chapter 2: Installation

    Keep the box and packing material to use if you ever need to reship the unit. Option Jumpers The DataComm V.34 PL has four factory-set option jumpers. Verify that they are set as shown in Figure 2-1 and described in Table 2-1.

  • Page 18: Option Jumpers

    For DataComm Shelf installation only NOTE: The built-in CCITT V.24/ V.28/ISO 2110 (TIA/EIA-232-F) interface does not use a DTE interface card. 060P014-021 V.34 PL Basecard Figure 2-1 DataComm V.34 PL Card Layout DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 19: Dte Interface Cards

    Preface of this manual. Modem Installation You can install the DataComm V.34 PL in any unused slot in the enclosure or shelf. To install the DataComm V.34 PL: 1. Insert the modem into its slot with the GDC logo on top (or to the right), then slide it in until it makes contact.

  • Page 20: Electrical Connections

    2-Wire line transmit/receive pair 4-Wire line receive pair GDC D25S Cable 023H101-010 (10 ft.) or 023H101-020 (20 ft.) To Business with customer furnished lugs Equipment Figure 2-2 V.34 PL in Standalone Enclosure DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...
  • Page 21 7 - DR 4-Wire 8 - DT 4-Wire PC/DT PR/DR M/TEK5 MIC/TEK6 Strip ends of cable, and secure in block. Figure 2-3 V.34 PL Connections in DataComm and DataComm USS Shelf 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 22 3/11 not used not used 3/11 4/12 not used not used 5/13 not used not used 6/14 not used not used 7/15 (Sheet 1 of 2) DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 23: Dte Cables

    If not, reset the modem. If decimal point four still does not flash, then either the power supply is not connected properly, or the modem is not functioning. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 24 Installation Verifying Your Connections DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 25: Chapter 3: Operation

    Operation Chapter 3: Overview This Chapter describes how to operate and configure the DataComm V.34 PL modem by means of the modem's front panel push buttons (displayed in throughout this chapter) and display. The DataComm V.34 PL front panel, illustrated in...

  • Page 26: Front Panel Indicators

    The modem is in a test mode. The modem is not in a test mode. Alarm Not used. Off-Hook The modem is in the off-hook state. The modem is in the on-hook state. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 27: Operating Procedures

    Operation Operating Procedures Operating Procedures The DataComm V.34 PL allows you to perform a number of operations from the front panel. It displays status information and allows you to configure some aspects of the modem, as well as perform diagnostics.

  • Page 28: Configuration

    Operating Procedures Configuration The DataComm V.34 PL leased-line only modem allows you to select a configuration profile. As soon as it is powered up, it performs a display test then displays “gdc” momentarily, then continuously enters the leased line handshake mode.
  • Page 29 USr1 would become the power up profile. To abort option configuration mode, press AL. If any options were changed, they remain in effect. This action does not save to a user profile or power up profile. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 30 Notes: Defaults shown in Bold for FAC0 through FAC3 * If EIA pins 18 and 21 are not used, this option must be disabled (d) to prevent the modem from randomly entering the Test Mode. DataComm V.34 PL Modem 060R115-000 Installation and Operation...

  • Page 31: Private Line Operation [Fac0 - Fac3 Or Usr0 - Usr3]

    DTE data rate, etc. Data Mode The DataComm V.34 PL modem is in data mode while it has a telephone line connection to another modem or is in the process of establishing a connection. In Data Mode the modem transmits all the data it receives from the DTE over the phone line.

  • Page 32: Clock Selection

    The synchronous format relies on transmit and receive clocks to maintain character timing. It therefore does not need start and stop bits for each character as does the asynchronous format. The DataComm V.34 PL modem can be configured to use one of the following three clock sources to transmit synchronous data: •...

  • Page 33: Testing The Modem

    When that is the case the connection usually will not be dependable and will be filled with errors. To correct such situations, the transmit level of the DataComm V.34 PL for private line operation can be configured in 1 dBm increments between 0 dBm and -15 dBm. This selection can be done from the front panel by entering tL then 0 to 15.

  • Page 34: Ccitt V.54 Loop

    (for example, the actual error count is 12345, but the modem displays 2.345). To stop the Setup ST test, press AL, RDL, or DL. Running 3-10 DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 35: Ccitt V.54 Loop 2 (Remote Digital Loopback)

    AL, or DL. If the remote modem initiated the test, the local modem lights decimal points three and four while the test is Running (Local) running. Running Remote 060R115-000 DataComm V.34 PL Modem 3-11 Issue 1 Installation and Operation...
  • Page 36 Operation Operating Procedures 3-12 DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 37: Chapter 4: Tests

    WITH SELF-TEST PASS FAIL PASS REMOTE MODEM COMMUNICATION PROBLEM LINE PROBLEM PASS FAIL FAIL PASS FAIL REMOTE TERMINAL OR COMMUNICATION REMOTE TERMINAL-MODEM LINE PROBLEM CONNECTION PROBLEM Figure 4-1 Fault Isolation Sequence 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...

  • Page 38: Analog Loopback (Analoop)

    DTE, or the DTE-to- modem connection. Refer to Figure 4-1, Fault Isolation Sequence. To end the test, press AL, RDL or DL. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 39: Analog Loopback With Self-Test

    (for example, the actual error count is 12345, but the modem displays 2.345). To end the test, press AL, RDL or DL. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...

  • Page 40: Digital Loopback

    DTE, the remote DTE-to-modem connection, or the communication line. Refer to Figure 4-1, Fault Isolation Sequence. To end the test, press AL, RDL or DL. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 41: Remote Digital Loopback

    (If the remote modem initiated the test, the local modem lights decimal points three and four while the test is running.) 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 42 Refer to Figure 4-1, Fault Isolation Sequence. To end the test, press AL, RDL, or DL. Note: CTS at the remote modem will drop low during the test. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 43: Remote Digital Loopback With Self-Test

    Establish data communications with a remote modem. Check with the remote attendant that the remote modem will accept Remote Digital Loopback commands. To start the test press RDL, then press ST. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 44 (for example, the actual er- ror count is 12345, but the modem displays 2.345). To end the test, press AL, RDL, or DL. DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 45: End-To-End Self-Test

    (for example, the actual error count is 12345, but the modem displays 2.345). To end the test, press AL, RDL, or DL. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 46 Tests End-to-End Self-Test 4-10 DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...
  • Page 47 Operating Mode Private line - two-wire or four-wire Answer Tone ITU-T V.34 as specified by ITU-T Note: Receiver performance in ITU-T V.34, may be degraded when transmitting above -6 dBm. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...
  • Page 48 +12V ±5% at 0.2A -12V -12V ±5% at 0.2A Dimensions (Printed circuit board) Height 22.2 mm (7/8 in) Width 248 mm (9 3/4 in) Depth 273 mm (10 3/4 in) DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...
  • Page 49 0 to 50×C (32× to 122×F) Non-operating -40 to 70×C (-40× to 158×F) Humidity, operating Up to 95 % humidity (non-condensing) Altitude, operating 0 m to 3,047 m (0 to 10,000 ft) 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...

  • Page 50: Technical Specifications

    Technical Specifications DataComm V.34 PL Modem 060R115-000 Installation and Operation Issue 1...

  • Page 51: Business Equipment Interface Tia/Eia-232-F, Itu-T V.24/V.28/Iso 2110)

    Signals on this circuit are used to provide the data terminal equipment with received signal element timing information. The On-to-Off transition shall nominally indicate the center of each signal element on the BB (Received Data) circuit. 060R115-000 DataComm V.34 PL Modem Issue 1 Installation and Operation...

  • Page 52: Remote Digital Loopback

    The On condition in this circuit indicates a test mode in the DCE, precluding reception or transmission of data signals from or to a remote DTE. The Off condition indicates that the DCE is not in test mode. DataComm V.34 PL Modem 060R115-000...
  • Page 53 Analog Loopback 4-2 Front Panel Controls 3-1 Analog Loopback with Self-Test 4-4 Front Panel Indicators 3-2 Fault Isolation Sequence 4-1 Option Jumpers 2-3 Front Panel 3-1 Testing the Modem 3-9 060R115-000 DataComm V.34 PL Modem IX-1 Issue 1 Installation and Operation...
  • Page 54 Index Transmit Level 3-9 Two-wire Selection 3-7 Unpacking Your Modem 2-1 V.34 PL Connections in DataComm and DataComm USS Shelf 2-5 V.34 PL in Standalone Enclosure 2-4 Verifying Your Connections 2-7 IX-2 DataComm V.34 PL Modem 060R115-000 Installation and Operation...
