media-tech MagicSound BS-2 MT3553 Instruction Manual

MagicSound
Bluetooth Headphones
with Microphone
Instructions
1. Power key/ telephone answering key
2. Touch to increase the volume/ to pick next song
3. Touch to reduce the volume/ to pick previous song
4. Mic hole
5. USB charging port
6. AUX IN port
Features
 Bluetooth Version: 2.1+ EDR
 Support Bluetooth phone calls, Bluetooth Music and
re-dial last number,
 Touch volume control area
 Support other devices (Computer, MP3, CD...) AUX in,
 Built-in lithium battery, with Micro USB charging port
 Smart Electricity-saving (after 3 minutes no connection
or 55 seconds no paring, it will turn off automatically to
save the battery.)

Specifications

 Wireless transmission distance: 10m,
 Battery capacity: 250 mAh
 Frequency range: 20Hz-20kHz
 Sensitivity: 95 dB
 Speaker impedance: 32 ohm
 Speaker Size: 32mm
 Charing time: 2h
 Voice Communication working time: 10h
 Bluetooth Music Playing time: 10h
Operations:
Bluetooth Functions

Bluetooth pairing:

 For first time
paring, press
and hold  key
for seconds to
pairing mode,
the light will indicate in BLUE and RED light flash in
turn. When the pairing is successful, your device will
show the connected Bluetooth icon.
BS-2
 After successful pairing, press  key to play music
sourcing from your device. Press again to pause. When
there is phone call coming, press  key to answer the
call directly, Press and hold  key for 3 seconds to
change to mobile phone private answering. Press and
hold on 3 seconds again back to Bluetooth answering.
 Double click  key to call the Number which you made
last phone call.
Bluetooth Music:
 Click  key for once to play the music sourcing from
your mobiles. Click again to pause.
 Finger touch area is divided into two parts by (.). Quick
double-click the volme inrease or reduce area to realize
songs pick, the next or previous.
 Press and hold the volume control area, you can easily
to increase or reduce the volume continuously.When
it reaches the maximum or minimum, the device will
indicate with a tick voice. Click non-continuously to in-
crease or reduce the volume by steps.
Bluetooth phone calls:
 When there is a phone call incoming, press  key to an-
swer the call directly, press and hold on  key for 3 sec-
onds to change to your mobile phone private answer-
ing, press and hold on once again to back to Bluetooth
answering.
 Double-click  key to call the Number which you made
last phone call.
LINE IN function:
When you want to listen to the music sourcing from other
audio devices, connect the Headphone with them, with
the AUX in Cable inside the AUX in port as the picture
shows.
On this model, the Bluetooth will turn off automatically,
turn it on is not allowed.
Charging function:
Connect the Charging cable with a adapter or (Computer's
USB port), while the other end insert into the USB charg-
ing port as pictures shows. This device will indicate in RED
light keeping bright on the right when charging. When it is
full, the RED light will turn off automatically.
Accessories:
AUX IN cable (length: 1.2M)
Charing Cable (length: 0.8M)
MT3553
Instructions Manual
EN
