CUSTOMER MESSAGE
TOOL BIT RESHARPENING POLICY
WARRANTY INFORMATION

TABLE OF CONTENTS

Inside Front Cover
3
6
8
10
11
21
22
24
28
30
32
33
40
Inside Back Cover
Inside Back Cover

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 301A and is the answer not in the manual?

Questions and answers

Related Manuals for TRI tool 301A

Summary of Contents for TRI tool 301A

  • Page 1: Table Of Contents

    TABLE OF CONTENTS CUSTOMER MESSAGE Inside Front Cover SAFETY PRECAUTIONS GENERAL DESCRIPTION SPECIFICATIONS MAINTENANCE OPERATION INSTALLING THE QL CUTTING SPEEDS AND FEEDS COLLETS TOOL BITS TROUBLE SHOOTING ACCESSORIES ILLUSTRATED PARTS BREAKDOWN DEWALT SAFETY INSTRUCTIONS TOOL BIT RESHARPENING POLICY Inside Back Cover WARRANTY INFORMATION Inside Back Cover...
  • Page 2 Copyright 2006 Proprietary property of TRI TOOL Inc. No reproduction, use, or duplication of the information shown hereon is permitted without the express written consent of TRI TOOL Inc.

  • Page 3: Safety Precautions

    Model 301 Tube Squaring Machine SAFETY PRECAUTIONS IN GENERAL When using rotating head cutting equipment, basic safety precautions should always be followed to reduce the risk of personal injury. Operate this tool only in accordance with specific operating instructions. Do not override the deadman switch on the power unit. Locking down, ob- WARNING: structing, or in any way defeating the deadman switch on the power drive unit may result in serious injury.
  • Page 4 TRI TOOL INC. TOOL CARE Maintain tools with care. Keep tools in good operating condition. Sharp tool bits perform better and safer than dull tool bits. Well maintained tools function properly when needed. Check for damaged parts. If a tool has malfunctioned, been dropped or hit, it must be checked for damage.
  • Page 5 Model 301 Tube Squaring Machine Disconnect power supply during setup and maintenance. Use all ‘Stop’ or Shut off’ features available when changing or adjusting tool bits, maintaining the tool, or when the tool is not in use. Remove adjusting keys and wrenches before applying power to the equipment. Develop a habit of checking the tool before turning it on to make sure that all keys and wrenches have been removed.

  • Page 6: General Description

    TRI TOOL INC. GENERAL DESCRIPTION The Model 301*, Tube Squaring Machine is a lightweight portable machine designed for facing and squaring .125” to 1.102” (3.2 mm to 28.0 mm) outside diameter tubing with an ability to handle up to .125” (3.2 mm) thick wall.
  • Page 7 Model 301 Tube Squaring Machine *DESIGNATIONS FOR THE MODEL 301 Model No. Part No. Description 301A 01-1203 Tube Squaring Machine powered by an Air Motor 301AQL 01-1322 Tube Squaring Machine with a Quick Lock attachment powered by an Air Motor...

  • Page 8: Specifications

    TRI TOOL INC. SPECIFICATIONS Model 301 with an Air Motor: Weight: 6.75 lbs. (3.1 kg) (varies slightly with Collet size) Power requirements: 22 cfm at 90 psi (10 L/s at kPa) Envelope, Model 301A Tube Squaring Machine 92-0630 : Rev. 060811...
  • Page 9 Model 301 Tube Squaring Machine Model 301 with an Electric Motor: Weight: 6.8 lbs. (3/1 kg) (varies slightly with Collet size) Power Requirements: Model 301E110 115 VAC +10%, 25 to 60 Hz Model 301E220 220 VAC +10%, 25 to 50 Hz Envelope, Model 301E Tube Squaring Machine 92-0630 : Rev.

  • Page 10: Maintenance

    Tool life may be severely shortened, unless chips and/or other debris that NOTE: have been deposited on the Cutting Head during the machining operation are removed. Disassembly of a power unit voids warranty, except when performed by a NOTE: TRI TOOL Inc. designated repair technician. Clean-Up 92-0630 : Rev. 060811...

  • Page 11: Operation

    Use of dull or improperly designed Tool Bits or Tool Bits not manufactured by WARNING: TRI TOOL Inc. may result in poor performance and may constitute abuse of this machine and therefore voids the TRI TOOL Inc. factory warranty. GENERAL GUIDE LINES FOR SELECTING A TOOL BIT Selection of the Tool Bit should be based on tubing material, the tubing size, and how critical is it to have a near burr free end.
  • Page 12 TRI TOOL INC. The M-42 Tool Bits are for use with the exotic alloys where the high heat resistance is required to avoid burning the cutting edge of the Tool Bit. M-42 can improve the life expectancy of the Tool Bit under some conditions on stainless steel.
  • Page 13 Model 301 Tube Squaring Machine Tool Bit Installed With The Tool Bit Installed With The Cutting Edge In Cutting Edge Out Tool Bit Tightening 92-0630 : Rev. 060811...
  • Page 14 TRI TOOL INC. Do NOT install the Tool bit backwards. Tighten the Set Screws to secure the Tool bit to the Cutting Head. Select the proper size Collet for the outside diameter of the tube or pipe to be squared.
  • Page 15 Model 301 Tube Squaring Machine INSTALLING A COLLET IN THE MODEL 301QL Remove the Ball Lock Pin from the Collet Clamping Assy of the Model 301QL by pulling straight out. Be sure that the Toggle Clamp Lever is in the up position to allow the pin to NOTE: be pulled out.
  • Page 16 TRI TOOL INC. Connect the Model 301 to the air supply and pull the trigger to start rotation of the Cutting Head. Ensure that the air supply has an adequate FRL (filter/regulator/lubricator) NOTE: installed and adjusted properly. Power requirement for a Model 301 equipped with an Electric Motor.
  • Page 17 Model 301 Tube Squaring Machine ADJUSTMENT OF THE CUTTING SPEED Use the Speed Control to adjust the cutting speed. Refer to the section ‘Cutting Speeds and Feeds’ for the recommended cutting NOTE: speeds. In order to obtain a minimum burr tube end, it is essential that heat build up be avoided.
  • Page 18 TRI TOOL INC. Adjust the cutting RPM with the Speed Control to just above the required cutting speed as the Tool Bit enters the cut. The Tool will slow down slightly as the cutting load increases, apply additional power to hold the cutting speed.
  • Page 19 Model 301 Tube Squaring Machine On the Model 301 loosen the Collet Nut to release the tube or pipe. On the Model 301QL pull the Toggle Clamp Lever back to release the tube or pipe. If the next cut is to be identical to the previous cut, then follow the sequence starting with ‘Installing a Collet in the Model 301’...
  • Page 20 TRI TOOL INC. This Tool Bit allows the tubing to be positioned in the Collet so that only 1/16” (1.6 mm) to 1/8” (3.2 mm) is unsupported by the Collet at the cut line. Another method is to use a consumable aluminum “pot chuck” which has been made from approximately 6”...

  • Page 21: Installing The Ql

    Model 301 Tube Squaring Machine INSTALLING THE QL Prepare the Model 301 for installation with the QL Kit. Disconnect the Model 301 from its power source. Remove the Knurled Nut from the end of the Model 301 Beveling Head Assembly. The Knurled Nut will not be used in the QL operation, however, it is recommended to retain the Knurled Nut for future use.

  • Page 22: Cutting Speeds And Feeds

    TRI TOOL INC. CUTTING SPEEDS AND FEEDS CUTTING SPEEDS The chart below shows RPM required to obtain a specified Tool Bit cutting speed on the surface of a pipe or tube. Cutting Speeds RPM for RPM for RPM for Outside Diameter...
  • Page 23 Model 301 Tube Squaring Machine CUTTING FEEDS Use very light feed for initial beveling or until a continuous cut is established. This is very important for longer Tool Bit life when cutting through flame cut or out-of-round pipe ends. Use adequate feed, .003” to .006” (.08 mm to .15 mm) per revolution thereafter to establish a continuous chip cut.

  • Page 24: Collets

    30-1823 11/32" .344" 8.74 mm 30-1824 .354" 9.00 mm 30-1825 23/64" .359" 9.13 mm 30-1826 3/8" .375" 9.53 mm 30-1827 .394" 10.00 mm 30-1828 .400" 10.16 mm 30-1829 Contact TRI TOOL Inc. for sizes not listed 92-0630 : Rev. 060811...
  • Page 25 30-1846 .602" 15.29 mm 30-1847 5/8" .625" 15.88 mm 30-1848 .630" 16.00 mm 30-1849 41/64" .641" 16.27 mm 30-1850 21/32" .656" 16.66 mm 30-1851 .669" 17.00 mm 30-1852 Contact TRI TOOL Inc. for sizes not listed 92-0630 : Rev. 060811...
  • Page 26 23.83 mm 30-1870 31/32" .969" 24.61 mm 30-1871 63/64" .984" 25.00 mm 30-1872 1" 1.000" 25.40 mm 30-1873 3/4" 1.050" 26.67 mm 30-1874 1 1/16" 1.063" 27.00 mm 30-1875 Contact TRI TOOL Inc. for sizes not listed 92-0630 : Rev. 060811...
  • Page 27 27.20 mm 30-1876 1.102" 28.00 mm 30-1877 Contact TRI TOOL Inc. for sizes not listed Replacement Spring (P/N 40-0229) 3 each required per Collet. Replacement O-Rings (P/N 28-0252 and P/N 28-0253) 1 each required per Collet. 92-0630 : Rev. 060811...

  • Page 28: Tool Bits

    TRI TOOL INC. TOOL BITS Tube Squaring Tool Bit Tube Squaring Tool Bits Max. Wall Pipe or Tube Tool Bit Squaring Range Thickness Material Heightg Tool Bit P/N .750" 99-1480 DURABIT 1 99-1445 .750" 99-1506 99-1331* .125" OD thru 1.05" OD .125"...
  • Page 29 Model 301 Tube Squaring Machine Beveling Tool Bit 37.5 Degree Max. Wall Pipe or Tube Angle Range Thickness Material Beveling Tool Bit P/N 99-1382 Pipe: 1/2" thru 3/4" sch 40 Tube: .625" thru 1.05" (OD's) .125" 99-1219 92-0630 : Rev. 060811...

  • Page 30: Trouble Shooting

    TRI TOOL INC. TROUBLE SHOOTING Problem: The Tool Bit Chatters Probable causes: The tool bit is loose or overextended. The tool bit is damaged. The tool holder is too loose in the slides. The cutting speed is too fast. The clamping pads are loose on the pipe or tube.
  • Page 31 Model 301 Tube Squaring Machine Problem: There is a loss of air power Probable causes: The air supply pressure is too low. The air filter is plugged. The air line size is insufficient. The air line is too long Problem: There is a loss of hydraulic power Probable causes: The hydraulic supply pressure is too low.

  • Page 32: Accessories

    The following accessories are recommended for use with the Model 301 Tube Facing Machine and are available from TRI TOOL INC. 1. A portable Air Filter Caddy (P/N 75-0100). A FRL is required to protect the warranty and tool on all Tri Tool air driven tools. 2. An Pneumatic Foot Pedal 3.

  • Page 33: Illustrated Parts Breakdown

    Model 301 Tube Squaring Machine ILLUSTRATED PARTS BREAKDOWN MODEL 301 TUBE SQUARING MACHINE 92-0630 : Rev. 060811...
  • Page 34 TRI TOOL INC. Parts List, Model 301 Item Part Description 03-0010 HEAD ASSY, BEVELING 14-0006 SHAFT ASSY 19-0011 HOUSING 20-0016 SHAFT ASSY 29-0028 BEARING, ROLLER 30-0062 RING, RETAINING, EXTERNAL 30-0063 RING, RETAINING, EXTERNAL 30-2278 HANDLE, GRIP 32-0026 PIN, ROLL, 1/8 DIA. X 3/4"...
  • Page 35 Model 301 Tube Squaring Machine AIR MOTOR ASSEMBLY Parts List, Motor Assy, Air Item Part Description 53-0045 VALVE, FLOW CONTROL 54-0149 COUPLING, MALE, QD 57-0199 MOTOR ASSY, AIR 27-0019 ADAPTER 46-0377 SLEEVE 57-0198 MOTOR, AIR 92-0630 : Rev. 060811...
  • Page 36 TRI TOOL INC. ELECTRIC MOTOR ASSEMBLY Parts List, Motor Assy, Electric Item Part Description 58-0004 MOTOR ASSY, ELECTRIC, 110 VAC 27-0018 ADAPTER 58-0003 MOTOR, ELECTRIC, 110 VAC (Milwaukee) MOTOR ASSY, ELECTRIC, 110 VAC (Bosch) 27-0018 ADAPTER 27-0060 ADAPTER 58-0038 MOTOR, ELECTRIC, 110 VAC (Bosch)
  • Page 37 Model 301 Tube Squaring Machine BATTERY POWERED, 14.4V, DRIVE KIT Parts List, Drive Kit, Battery Powered, 14.4V (P/N 58-0162) Item Part Description 19-0995 HOUSING, FRONT 27-0497 ADAPTER 33-0040 SCREW, CAP, 1/4-20 X 3/4" 58-0161 MOTOR, CORDLESS, 14.4 VOLT 30-2350 BATTERY, 14.4v (Dewalt) 92-0630 : Rev.
  • Page 38 TRI TOOL INC. COLLET QUICK LOCK SYSTEM FOR THE MODEL 301 Parts List, Collet Quick Lock System for the Model 301 (05-0240) Item Part Description 20-0629 SHAFT 27-0534 ADAPTER 32-0089 PIN, BALL LOCK, T-HANDLE 32-0140 PIN, DOWEL, 1/4 DIA X 3/4"...
  • Page 39 Model 301 Tube Squaring Machine BASE STAND ASSEMBLY Parts List, Stand Assy, Base (P/N 60-0022) Item Part Description 24-0326 PLATE, BASE 33-0045 SCREW, CAP, 1/4-20 X 1 3/4", ZP 33-0369 SCREW, FLAT, 5/16-18 X 3/4" 48-0173 BLOCK, RETAINING 92-0630 : Rev. 060811...

  • Page 40: Dewalt Safety Instructions

    TRI TOOL INC. DEWALT SAFETY INSTRUCTIONS The DeWALT Cordless Drill/Driver comes with an 'Instruction Manual' and should be referenced for all safety and operating procedures. 92-0630 : Rev. 060811...
