- Page 1 USER MANUAL MAISI Car Dashboard Camera Ambarella A7 Congratulations on your purchase! Please read and understand all instruction before using this camera. If you do not use device properly and follow all instructions, the warranty may be voided.
- Page 2 PRIOR TO USE 1. Install the device near the rear-view mirror to obtain the best open-field view. Do NOT install the camcorder in a location that will obstruct your required driving view. 2. Make sure that the lens is within the wiping range of the windscreen wiper to ensure a clear view even when it rains.
- Page 3 LED Indicator LCD Panel Mini HDMI USER MANUAL Note: MAISI Car Dashboard Camera To operate the camcorder, press the corresponding buttons (5, 8, 9, 10) according to guide icons shown on the screen. Ambarella A7 Congratulations on your purchase! Please read and understand all instruction before using this camera.
- Page 4 2.2 Installing in Vehicles 2 Getting Started 2.2.1 Mount to windshield 2.1 Inserting the Memory Card Insert the memory card with the gold contacts facing the 1. Attach the bracket to the camcorder. back of the camcorder. Push the memory card until it clicks Slide it into the bracket holder until you into place.
- Page 5 2. Plug the other end of the car charger to the cigarette 2.2.2 Adjust the camcorder position lighter socket of your vehicle. Once the vehicle engine is started, the camcorder automatically turns on. Car charger 1. Loose the knob to swivel input: DC 12 / 24V.
- Page 6 2.4 LED Indicator 2.5.2 Set the Date and Time To set the correct date and time, do the following: Status Explanation LED Indicator Color 1. Press the button to enter the Power off, battery charging Green on-screen display (OSD) menu. Power off, battery fully Charged LED Light Off 2.
- Page 7 3.1.3 Emergency Recording Number Item Description Recording Duration Indicates the recording duration. During Video Recording, press the Date and Indicates the current recording date and time. button to enter Guide Icon (Menu) Press the button to enter the OSD menu. emergency recording mode, Guide Icon Press the...
- Page 8 6. Press the button to pause the 3.2.3 Deleting Files playback. Press it again to resume. To delete file(s), do the following: 1. If recording is in progress, press button to stop recording. 2. Press the button to enter the OSD menu.
-
Page 9: Menu Tree
4.2 Menu Tree 4 Adjusting the Settings Refer to the below table for details on menu items 4.1 Using the Menu and available menu options. You can customize the video recording and other general settings via the on-screen display (OSD) menus. Menu Item Description Available option... -
Page 10: Specifications
Specifications Motion Detection If Motion Detection is activated, On / Off the camcorder will automatically Item Description triggerrecording when the Image sensor 1/3” CMOS sensor camcorder detects any motion in Effective pixels 2688 (H) x 1520 (V) front. When the battery is fully Storage media Support Micro SDHC, up to 32GB class 10 charged and is...
