User manual
NivuLog Easy
User Manual for the GPRS Data Logger NivuLog
NIVUS GmbH
Im Taele 2
75031 Eppingen, Germany
Phone: +49 (0)7262 9191-0
Fax: +49 (0)7262 9191-999
E-mail: info@nivus.com
Internet: www.nivus.de
NivuLog Easy - Rev. 05 as of 02.07.2012
(Original Instruction Manual - German)
Rev. 05 valid from:
Firmware version: 02v003
l
Modem version: 02v003 and 3v002
l
Hardware version: 2.1
l
Easy
1 of 73

Advertisement

Table of Contents
loading

Related Manuals for Nivus NivuLog

Summary of Contents for Nivus NivuLog

  • Page 1: User Manual For The Gprs Data Logger Nivulog Easy

    User manual NivuLog Easy User Manual for the GPRS Data Logger NivuLog Easy (Original Instruction Manual - German) Rev. 05 valid from: Firmware version: 02v003 Modem version: 02v003 and 3v002 Hardware version: 2.1 NIVUS GmbH Im Taele 2 75031 Eppingen, Germany...

  • Page 3: Table Of Contents

    Chapter 1 Table of contents Chapter 1 Table of contents User Manual for the GPRS Data Logger NivuLog Easy Chapter 1 Table of contents Chapter 2 Declaration of conformity Chapter 3 Specifications Chapter 4 General specifications 4.1 Translation 4.2 Copyright 4.3 General descriptive names...
  • Page 4 9.1.1 Operating elements 9.1.1.1 Status LED 9.1.1.2 Buttons 9.1.1.3 Solenoid switch 9.2 User interface on the Device to Web-Server 9.2.1 Site configuration 9.2.1.1 Site 9.2.1.2 Comments 9.2.1.3 Measurement channels 9.2.1.3.1 Basis 4 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 5 Chapter 12 Troubleshooting and repair 12.1 General problems 12.2 Evaluating the device log 12.2.1 Evaluating the device log on the Device to Web server 12.2.2 Evaluating the device log using DeviceConfig NivuLog Easy - Rev. 05 as of 02.07.2012 5 of 73...
  • Page 6 Chapter 13 Spare parts and accessories 13.1 Internal expansions 13.2 Assembly sets 13.3 Antennas 13.4 Accu and battery packs 13.5 Sensors 13.6 Other accessories Chapter 14 Branch offices 6 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 7: Chapter 2 Declaration Of Conformity

    Désignation: Enregistreur de données GPRS Typ / Type: NivuLog 4, NivuLog PCM, NivuLog Easy erklären wir in alleiniger Verantwortung, dass die auf dem Unionsmarkt ab dem Zeitpunkt der Unterzeichnung bereitgestellten Geräte die folgenden einschlägigen Harmonisierungsvorschriften der Union erfüllen: we declare under our sole responsibility that the equipment made available on the Union market as of the date of signature of this document meets the standards of the following applicable Union harmonisation legislation: nous déclarons, sous notre seule responsabilité, à...

  • Page 9: Chapter 3 Specifications

    Interval counter: min. impulse length 20ms, load 8k9 Additional information is provided in "Technical details regarding the universal inputs" on page 28. External 1 x Cable temperature sensor 3m(todo) (Optional equipment) temperature sensor NivuLog Easy - Rev. 05 as of 02.07.2012 9 of 73...
  • Page 10 Data transmission By means of GSM/GPRS quad-band modem to the relevant Device to Web server The NivuLog Easy is equipped with an integrated SIM chip. Monthly data volume <4MB for two minute measurement cycle and 120 minute transmission cycle 10 of 73...

  • Page 11: Chapter 4 General Specifications

    4.4 Safety instructions For the connection, commissioning and operation of the NivuLog Easy , the following information and higher legal regulations of the country (e.g. ÖVE), such as valid EX regulations as well as the applicable safety and accident prevention regulations for the respective application case must be observed.

  • Page 12: Use Of The Hazard Warnings

    The device may not be operated in highly flammable areas such as petrol filling stations, fuel storage sites, chemical factories and explosion sites. Do not operate the device in the vicinity of flammable gases, vapours or dusts. 12 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 13: Safety Measures For Installing The Antenna

    The antenna must not be extended outside protected buildings and must be protected against lightning strikes. The voltage supply must be switched off before replacing the antenna. 4.5 Overview Overview NivuLog Easy NivuLog Easy - Rev. 05 as of 02.07.2012 13 of 73...

  • Page 14: Intended Use

    A Managed Service con- tract with NIVUS GmbH is required for use of the mobile data transmission (see www.nivus.com). This includes the provisioning of the mobile communications connection via the network of the service provider included in the above-mentioned list.

  • Page 15: Device Labelling

    Chapter 4 General specifications 4.8 Device labelling The specifications in this manual apply exclusively to the device type NivuLog Easy . The type plate is located on the right side of the device and includes the following specifications: Name and address of manufacturer...

  • Page 16: Installation Of Replacement And Wear Parts

    17) and then check again that all relevant data has been transmitted. If you are using an external charging voltage to charge the accu pack of the NivuLog Easy , disconnect this from the device before removing the accu or battery pack. The remaining cables and antenna can then be removed.

  • Page 17: Chapter 5 Functional Principle

    Chapter 5 Functional Principle 5.1 ALOHA transmission mode ALOHA transmission mode is a special connection mode whereby the NivuLog Easy creates a connection to the Device to Web server for a period of time configured using the "Basic settings" configuration section (see "Aloha/wake-up duration"...

  • Page 19: Chapter 6 Storage, Delivery And Transport

    0... +30°C Note: The table above only includes the storage conditions for the two energy sources used most frequently for the NivuLog Easy . Please consult the appropriate factsheet for information about the storage conditions of other accu or battery packs.

  • Page 20: Transportation

    Device to Web-Server. An RMA number is mandatory for any returns and can be obtained from the Support & Service Centre (see "Branch offices " on page 73). The return shipment of the NivuLog Easy must occur in the original packaging and with freight and insurance paid to NIVUS GmbH (see "Branch offices "...

  • Page 21: Chapter 7 Installation

    7.2 Installing the NivuLog Easy Important note: Ensure the installation is completed properly. Comply with the existing legal and/or operational directives. Improper handling can cause injuries and/or damage to the devices. NivuLog Easy - Rev. 05 as of 02.07.2012 21 of 73...

  • Page 22: Wall Mounting

    NLM0HALEASY) 1. First attach the assembly loop (3) using the screws (2) included in the "Universal bracket for housing NivuLog Easy 86x126 (NLM0HALEASY)" equipment set to the NivuLog Easy (see "Step 1 of the wall mounting" on page 22).

  • Page 23: Safety Instructions For The Cabling

    If you are using your own screws, you must also insert the wall plugs into the holes before mounting the NivuLog Easy with the attached assembly loop (3) to the wall (see "Step 2 of the wall mounting" on page 22).

  • Page 24: Electrical Installation

    The NivuLog Easy must not be operated in the field with the lid open. The NivuLog Easy cannot be operated without an internal power supply (accu or battery pack). Ensure the polarity of the connector is correct when replacing the accu or battery pack.
  • Page 25 10 Mounting for the accu or battery pack 5 connector X4 for the external temperature sensor 11 Status LED 6 M12x1.5 cable screw connection (cable diameter 12 Button of 3.5 to 7 mm) NivuLog Easy - Rev. 05 as of 02.07.2012 25 of 73...
  • Page 26 2. Connection of the external temperature sensor: If the external temperature sensor was ordered at the same time as the NivuLog Easy , it should already be connected correctly. If you ordered an external temperature sensor at a later date as an accessory, the following steps...

  • Page 27: Connecting The Gsm Antenna

    The standard antenna is directly attached to the antenna connector (see "Overview" on page 13) of the NivuLog Easy . In the event of a low radio signal strength, you can use the Flat antenna Smart Disc FME-F ( - upon request).

  • Page 28: Technical Details Regarding The Universal Inputs

    Attaching an external voltage will cause damage to the universal input. In comparison to "digital" mode, the energy consumption during "LP digital" mode with a closed switch contact is thus reduced by a factor of 13. 28 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 29: Technical Details Regarding The Outputs

    The accu or battery voltage is supplied directly to the voltage output V protected by a PTC (I 200mA). batt The voltage available at this output is therefore directly dependent on the charging condition of the accu or battery pack. NivuLog Easy - Rev. 05 as of 02.07.2012 29 of 73...

  • Page 30: Technical Details Regarding Energy Management

    7.4.5 Technical details regarding energy management The device will work until 3,1V, if the NivuLog Easy is operated without an external charging voltage (V ). It then switches to energy-saving mode in which only the charge controller is active. If an external charging voltage (V ) is supplied in this mode, the accu pack can be charged up again.

  • Page 31: Chapter 8 Initial Start-Up

    You can also use suitable test signals to simulate the sensors to establish the optimum configuration of the NivuLog Easy prior to its actual first use. This will reduce the time needed for on-site installation to a mini- mum.

  • Page 32: Testing The Communication With The Device

    2. Configure the created site according to your requirements (see "Site configuration" on page 37). 3. Link the NivuLog Easy with the created site (see "Site" on page 37). 4. Initiate the ALOHA transmission mode (see "ALOHA transmission mode" on page 17) so that the con- figuration of the site is transmitted to the NivuLog Easy .
  • Page 33 -74 to -83dBm -84 to -93dBm -94 to -107dBm <= -108dBm Note: Additional explanation about evaluating the "battery": "Battery" > 3.81V 3,81V...3,70V 3,71V...3,63V 3,64V...3,59V 3,6V...3,19V <= 3.2 V or invalid value NivuLog Easy - Rev. 05 as of 02.07.2012 33 of 73...

  • Page 35: Chapter 9 User Interfaces

    Chapter 9 User interfaces The configuration of the NivuLog Easy is carried out via the web interface on the Device to Web server (see "User interface on the Device to Web-Server" on page 37), which your responsible sales partner will provide to you.

  • Page 36: Buttons

    GPRS connection established or button/solenoid switch actuates Normal measuring operation according to configuration until the next transmission 9.1.1.2 Buttons The button can also be used to initiate the ALOHA transmission mode or to instruct the NivuLog Easy to immediately give out the error/status code. User action...

  • Page 37: Solenoid Switch

    Empty comment field (is also displayed below the device type in the site list) 9.2.1.3 Measurement channels 9.2.1.3.1 Basis Title 1-4 Freely selectable channel title for the universal inputs Title 1Wire Freely selectable channel title for the external temperature sensor NivuLog Easy - Rev. 05 as of 02.07.2012 37 of 73...
  • Page 38 String, which is used as the measurement unit by all of the server display elements Decimal Number of decimal places that are used by all of the server places display elements 38 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 39 Selection of the temperature unit that is used by all of the server display elements Decimal Number of decimal places that are used by all of the server places display elements NivuLog Easy - Rev. 05 as of 02.07.2012 39 of 73...

  • Page 40: Config

    Up & down Minimum signal length for x seconds on both edges Time Time x, for which the decay modes "up" "down", and "up & down" are used 40 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 41 4 channels: per 15 measurement values). To calculate the number of considered measurement values see "Example for explaining the recording, measuring and burst cycles (in conjunction with the decay)" on page 59. NivuLog Easy - Rev. 05 as of 02.07.2012 41 of 73...
  • Page 42 In the event of an error, the last valid measurement value is maintained until a new valid measurement value is present. 42 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 43 If the measurement value is below the borders lower limit, the error value "UF" (underflow) is issued. If the measurement value is above the upper limit, the error value "OF" (overflow) is issued. NivuLog Easy - Rev. 05 as of 02.07.2012 43 of 73...
  • Page 44 In the event of an error, the last valid measurement value is maintained until a new valid measurement value is present. 44 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 45 If the measurement value is below the borders lower limit, the error value "UF" (underflow) is issued. If the measurement value is above the upper limit, the error value "OF" (overflow) is issued. NivuLog Easy - Rev. 05 as of 02.07.2012 45 of 73...
  • Page 46 In the event of an error, the last valid measurement value is maintained until a new valid measurement value is present. 46 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 47 If the measured value is above borders 20.1 mA, the error value "OF" (overflow) is issued. If the measured value is above 21 mA, the error value "SC" (short cut) is issued. NivuLog Easy - Rev. 05 as of 02.07.2012 47 of 73...
  • Page 48 In the event of an error, the last valid measurement value is maintained until a new valid measurement value is present. 48 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 49 If the measured value is above 20.1 mA, the error value "OF" (overflow) is issued. If the measured value is above 21 mA, the error value "SC" (short cut) is issued. NivuLog Easy - Rev. 05 as of 02.07.2012 49 of 73...
  • Page 50 If the measured value is above 2.01V, the error value "OF" (overflow) is issued. NAMUR If the measured value is above 2.01V, the borders error value "OF" (overflow) is issued. 50 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 51 If the measured value is above 10.05V, the error value "OF" (overflow) is issued. NAMUR If the measured value is above 10.05V, the borders error value "OF" (overflow) is issued. NivuLog Easy - Rev. 05 as of 02.07.2012 51 of 73...

  • Page 52: Alarms

    Activate online mode Edge Selection of the edge at which the trigger should be initiated Rising Rising edge initiates trigger. Falling Falling edge initiates trigger. Both Both edges initiate trigger. 52 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 53: Calculated Channels

    String, which is used as the measurement unit by all of the server display elements Decimal Number of decimal places which are used by all of the server display places elements Shifts element down Shifts element up NivuLog Easy - Rev. 05 as of 02.07.2012 53 of 73...

  • Page 54: Calculation

    Indicates the amount of time that an output channel is switched on in "Ext warmup time" mode before the measurement. Title 1 Freely selectable channel title for the switchable sensor supply Title 2 Freely selectable channel title for the isolated switch contact 54 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 55 String, which is used as the measurement unit by all of the server display elements Decimal places Number of decimal places that are used by all of the server display elements NivuLog Easy - Rev. 05 as of 02.07.2012 55 of 73...

  • Page 56: Config

    An alarm is initiated if the measurement value meets or exceeds this value. Hyst % Hysteresis for all-clear (e.g. hyst = 5%, alarm or warning at 100 -> all-clear at 95) 56 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 57: Trigger

    A test message is sent to all recipients ("parallel" alarm call plan type) and/or the first recipient ("serial" alarm call plan type) as soon as this page is saved. The check box is subsequently reset automatically. NivuLog Easy - Rev. 05 as of 02.07.2012 57 of 73...

  • Page 58: Basic Settings

    Predefined setting for the American area Predefined setting for the European area Position cycle Time between position update Default view Report, which is loaded into the map by clicking on the device link 58 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 59: Ftp Export Settings

    Note: Several of the configuration fields in the following sub chapters may possibly be hidden depending on the respective user level. In this case, please contact the Device to Web-Server administrator. NivuLog Easy - Rev. 05 as of 02.07.2012 59 of 73...

  • Page 60: Comments

    OS version OS version of the modem Last In each case, the last time stamp of the affected operation connection Last wakeup Last disconnection Last transmission error Last Aloha connection 60 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 61 Only firmware versions that have successfully undergone internal testing are installed (malfunctions cannot be excluded). Beta release Even firmware versions that have not successfully undergone all of the internal tests are installed (malfunctions may occur). NivuLog Easy - Rev. 05 as of 02.07.2012 61 of 73...

  • Page 62: Device-Specific Settings

    Temp.:-40°C to +80°C, V :3,7V AP403D solar Temp.:-40°C to +80°C, always charging LiPo backup Temp.:0°C to +45°C, V :3,7V BP434R Charge regulator deactivated 9.2.2.4 GPRS SIM tariff Selected SIM tariff 62 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 63: Chapter 10 Maintenance

    Check all of the connections for leaks or corrosion on a regular basis. Check all of the cables for mechanical damage at regular intervals. Clean the NivuLog Easy with a soft, moist cloth. Use a mild cleaning agent, if necessary. 10.2 Replacing the accu or battery pack...
  • Page 64 10 Mounting for the accu or battery pack 5 connector X4 for the external temperature sensor 11 Status LED 6 M12x1.5 cable screw connection (cable diameter 12 Buttons of 3.5 to 7 mm) 64 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 65: Charging The Accu Pack

    17) and then check again that all of the relevant data has been transmitted. 2. If you are using an external charging voltage to charge the accu pack of the NivuLog Easy , disconnect this from the device before opening the housing cover.

  • Page 66: Accu Or Battery Pack

    However, the service time of accu packs is not indefinite. In addition to regular servicing and maintenance, its service life is also dependent on the frequency of use and the operating and storage conditions. 66 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...

  • Page 67: Chapter 11 Removal/Disposal

    Dispose of the device in accordance with the locally valid environmental regulations for electronic products. Rechargeable batteries and/or battery packs may not remain in the NivuLog Easy after discharging. Ensure that the used rechargeable batteries and/or battery packs are disposed of in an environmentally proper way.

  • Page 69: Chapter 12 Troubleshooting And Repair

    Communication problems Evaluate the status LED blink code (see "Status LED" on page 35). Load the device log from the NivuLog Easy or the Device to Web server and use DeviceConfig for the evaluation (see "Evaluating the device log" on page 70).

  • Page 70: Evaluating The Device Log

    The optional equipment SIM/USB option (NLM0SIMUSB) is required to read the log entries directly from the NivuLog Easy using the DeviceConfig. With this equipment, all of the log entries stored in the device, including those that have not yet been transmitted to the Device to Web server can be read.
  • Page 71 Description Quantity Order number Battery packs BP434R (-20...+50°C operating temperature) NLM0BP434R Accu packs AP403D (Pb; 2,5Ah; -40...+60°C operating temperature) NLM0AP403D AP413D+ (Li-ion; 13,6Ah; -50...+60°C operating, -20...+60°C charging NLM0AP413D+ temperature) NivuLog Easy - Rev. 05 as of 02.07.2012 71 of 73...
  • Page 72 Cable temperature sensor 3m todo 13.6 Other accessories Description Quantity Order number Tool Pen NLM0TOOLPEN Magnet for device activation NLM5MAGNET cross connection box NLM0ZUB0AZD Charger NLM0LAD413D+ power device NLM0NETZG01 72 of 73 NivuLog Easy - Rev. 05 as of 02.07.2012...
  • Page 73 Tel.: +971 6 55 78 224 Tel. +82 31 999 5920 Internet: www.nivus.de Fax: +971 6 55 78 225 Fax. +82 31 999 5923 E-Mail: Middle-East@nivus.com E-Mail: korea@nivus.com Internet: www.nivus.com Internet: www.nivus.com NivuLog Easy - Rev. 05 as of 02.07.2012 73 of 73...
