Solair World SWWR-26GW Installation And Operation Instruction Manual

Thermal boosted hybrid air conditioners

Advertisement

"An energy revolution where your comfort costs less"
Relax In comfort with SolAir World's
Thermal Boosted Hybrid Air Conditioners
www.solairworld.com
INSTALLATION AND OPERATION INSTRUCTION MANUAL FOR:
SINGLE HEAD
SWWR-26GW
SWWR-35GW
SWWR-60GW
SWWR-72GW
DUAL HEAD
SWWR-35/35G
SWW(R)26GW-3
SWWR-72/72G
SWW(R)35GW-3
SWWR-35/72G
TRIPLE HEAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWWR-26GW and is the answer not in the manual?

Questions and answers

Summary of Contents for Solair World SWWR-26GW

  • Page 1 “An energy revolution where your comfort costs less” Relax In comfort with SolAir World’s Thermal Boosted Hybrid Air Conditioners INSTALLATION AND OPERATION INSTRUCTION MANUAL FOR: SINGLE HEAD DUAL HEAD TRIPLE HEAD SWWR-26GW SWWR-35/35G SWW(R)26GW-3 SWWR-35GW SWWR-72/72G SWW(R)35GW-3 SWWR-60GW SWWR-35/72G SWWR-72GW...
  • Page 2: Note To Users

    Technical Support: 1300 550 140 Congratulations on purchasing a SolAir World Thermal Boosted Hybrid Air Conditioning System. come. To understand how your SolAir World Thermal Boosted Hybrid Air Conditioning System works and to using the system. licensed Air Conditioner Installer.
  • Page 3: Table Of Contents

    Operating Instructions and Installation Guide Wall Mounted Split System Contents Note to users. Page 1 ..........................1. General Information Page 4 SWWR-35GW..............Page 5 Page 6 SWWR-60GW..............Page 7 SWWR-72GW..............Dual & Triple Head............P age 8 Page 9 Page 10 1.3 System Operating Principles....................
  • Page 4: General Information

    Operating Instructions and Installation Guide Wall Mounted Split System Section 1 General Information _______________________ Page 3...
  • Page 5 Operating Instructions and Installation Guide Wall Mounted Split System SolAir World SWWR-26GW MC MODEL Rated Cooling Capacity (Watts) 2600 2600 2900 Rated Heating Capacity (Watts) 2900 220V/50Hz/60Hz 220V/50Hz/60Hz Rated Power Input (Volts/Hertz) 480 - 600 480 - 600 Rated Cooling Power Input (Watts) 2.00 - 2.50...
  • Page 6 Operating Instructions and Installation Guide Wall Mounted Split System SolAir World SWWR-35GW MC MODEL Rated Cooling Capacity (Watts) 3500 3500 Rated Heating Capacity (Watts) 3800 3800 220V/50Hz/60Hz 220V/50Hz/60Hz Rated Power Input (Volts/Hertz) Rated Cooling Power Input (Watts) 580 - 800 580 - 800 2.34 - 3.36...
  • Page 7 Operating Instructions and Installation Guide Wall Mounted Split System SolAir World SWWR-60GW MC MODEL Rated Cooling Capacity (Watts) 6000 6000 Rated Heating Capacity (Watts) 6600 6600 Rated Power Input (Volts/Hertz) 220V/50Hz/60Hz 220V/50Hz/60Hz Rated Cooling Power Input (Watts) 1160 - 1390...
  • Page 8 Operating Instructions and Installation Guide Wall Mounted Split System SolAir World SWWR-72GW MC MODEL Rated Cooling Capacity (Watts) 7200 7200 Rated Heating Capacity (Watts) 7900 7900 Rated Power Input (Volts/Hertz) 220V/50Hz/60Hz 220V/50Hz/60Hz Rated Cooling Power Input (Watts) 1540 - 1760...
  • Page 9: Swwr-35Gw

    Operating Instructions and Installation Guide Wall Mounted Split System Dual Head Triple Head Solair World SWWR-35/35GW SWW(R)-26GW-3 SWWR-72/72GW SWW(R)-35GW-3 SWWR-35/72GW outdoor unit. single head. Triple Head Units are only compatible with tube collector. _______________________ Page 8...
  • Page 10: Safety Information

    If any unusual circumstances occur including, but not limited to strange noises or smells, smoke, abnormal temperature increases or changes to appearance of components please switch off the power immediately and contact your local distributor of SolAir World Thermal Boosted Air Conditioning System. DO NOT attempt to repair the system yourself.
  • Page 11: System Operating Principles

    Operating Instructions and Installation Guide Wall Mounted Split System 1.3 System Operating Principles * The Air Conditioning System uses both mains electrical power and solar thermal energy. The Air components. The Air ________________________ Page 10...
  • Page 12 Operating Instructions and Installation Guide Wall Mounted Split System 1.3 System Operating Principles ________________________ Page 11...
  • Page 13 Operating Instructions and Installation Guide Wall Mounted Split System 1.3 System Operating Principles ________________________ Page 12...
  • Page 14: System Components

    Operating Instructions and Installation Guide Wall Mounted Split System 1.4 System Components Please note that the graphic example below is based on the standard SolAir World Thermal Boosted air inlet power plug operational light Timing sleeping light upper and lower wind...
  • Page 15: Installation Guide

    Operating Instructions and Installation Guide Wall Mounted Split System Section 2 Installation Guide ________________________ Page 14...
  • Page 16: Trouble Shooting

    Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting Non Failure Conditions then back on. Failure Display Indicators Model No.’s SWWR-26GW and SWWR-35GW Failure Type Display Status • Indoor Temperature Sensor Failure • Indoor Transmitter Failure •...
  • Page 17 Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting WARNING! Symptom Problem NORMAL Doesn’t operate FUNCTION immediately: unit operation during that period. Noise is heard: changes. Smells: conditioner. Mist or steam are emitted: or stops: internal parts to warm up.. setting.
  • Page 18: Operating Tips

    Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting Symptom Item to check the out door unit: Doesn’t operate at all: Poor Cooling The water in the Thermal collector is low The unit operates remote control unit’s setting: Operating Tips Auto Restart (Optional)
  • Page 19 Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting E4 Troubleshooting Questionnaire Questions if the system has been operating normally before the E4 error code has appeared: Questions if the system has just been installed and the E4 error code has appeared: ________________________ PLEASE NOTE:...
  • Page 20 Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting Test Running 1. Check that all tubing and wiring are properly connected. Prepare remote according to the arrow direction. 2. Insert new batteries making sure that the (+) position.
  • Page 21: Pump Down

    Operating Instructions and Installation Guide Wall Mounted Split System 2.0 Trouble Shooting NOTICE should be added. PUMP DOWN CAUTION • Be sure to perform Pump Down procedure in the cooling mode. Pump Down Procedure 4. Turn on the unit’s operating switch and start the cooling operation. _______________________ Page 20...
  • Page 22: General Installation Information

    Operating Instructions and Installation Guide Wall Mounted Split System General Installation Information Electrical Information judgement as to whether the installation is suitable. The power circuit should be dedicated solely to the SolAir World System. Systems Standard Circuit’s Electrical Standard Electrical...
  • Page 23 MC Model Liquid pipe Gas pipe MC Model 1020g 880g SWWR-26GW 6.35 (1/4) 9.52 (3/8) 6.35 (1/4) 12.70 (1/2) 1300g 1050g SWWR-35GW 6.35 (1/4) 12.70 (1/2) 1600g 1350 SWWR-60GW 9.52 (3/8)
  • Page 24 Operating Instructions and Installation Guide Wall Mounted Split System General Installation Information Thermal Collector Installation • SOUTH in the northern hemisphere. • • • • • that the condensation can be pumped up to the collector panel. Thermal Collector Panel Option 2 •...
  • Page 25 Operating Instructions and Installation Guide Wall Mounted Split System General Installation Information Thermal Collector Selection • • SolAir World Model No. Collector Type Ideal Climate Zone Flat Panel 3 litres SWWR-26GW Heat Tube 13 litres SWWR-26GW Flat Panel 3 litres...
  • Page 26 Operating Instructions and Installation Guide Wall Mounted Split System 2.1 General Installation Information Heat Tube Collector 1) The glass heating tubes which include a multi layered wall with an absorbent material to attract solar 3) The seals between the heat tubes and the water tank. ________________________ Page 25...
  • Page 27: Indoor Unit Installation

    Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation Select the best Location Indoor Unit 1. There should not be any heat or steam near the unit. 2. Select a place where there are no obstacles around the unit.
  • Page 28: Fixing Installation Plate

    Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation Fixing Installation Plate The wall you select should be strong and solid enough to 1. Mount the installation plate on the wall with suitable use anchor bolts. •...
  • Page 29 Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation Flaring Work Cut the pipes and the cable. 1. Use the piping kit accessory or the pipes purchased locally. 2. Measure the distance between the indoor and the outdoor unit.
  • Page 30 Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation If a flare Check work again. Connecting the Piping Indoor installation through the wall. chassis.. For right rear piping 1. Route the indoor tubing and the drain hose in the outdoor unit through the piping hole Do not connect the cable to the indoor unit.
  • Page 31 Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation 4. Indoor unit installation plate.) Ensure that the hooks are properly seated on the installation plate until the hooks engage into their slots (clicking sound). Connecting the piping to the indoor unit and drain hose to drain pipe.
  • Page 32 Operating Instructions and Installation Guide Wall Mounted Split System 2.2 Indoor Unit Installation For left rear piping 1. Route the indoor tubing and the drain hose to the required piping hole position. into the piping hole. 3. Insert the connecting cable into the indoor unit. •...
  • Page 33 Operating Instructions and Installation Guide Wall Mounted Split System Indoor Unit Installation Wrap the insulation material around the connecting portion. indoor unit pipe heat insulation material. Bind them 2. Wrap the area which accommodates the rear piping 3. Bundle the piping and drain hose together by wrapping into the rear piping housing section.
  • Page 34: Outdoor Unit Installation

    Operating Instructions and Installation Guide Wall Mounted Split System 2.3 Outdoor Unit Installation Installation guide at the seaside CAUTION are produced. Otherwise it needs additional anticorrosion treatment on the heat exchanger. Selecting the location (Outdoor Unit) to the sea wind. the outdoor unit.
  • Page 35 Operating Instructions and Installation Guide Wall Mounted Split System 2.3 Outdoor Unit Installation • • Unit must be sprayed with Anti-rust upon installation with Kirby Coat or Similar. IF THIS IS NOT DONE THE WARRANTY ON THE UNIT IS VOID. If install is within 15km’s from the seaside Anti-rust must be sprayed on the unit every 3 months.
  • Page 36 Operating Instructions and Installation Guide Wall Mounted Split System supports using the threaded studs pre-inserted ________________________ Page 35...
  • Page 37 Operating Instructions and Installation Guide Wall Mounted Split System • to ensure that the silicon sealing ring inside is not dislodged. • Lubricate the white plastic tee joint (water drain) with the to ensure that the silicon sealing ring is not dislodged. similar sized and shaped object until a replacement tube can Thermal Collector.
  • Page 38: Flat Panel Thermal Collector Installation

    Operating Instructions and Installation Guide Wall Mounted Split System 2.5 Flat Panel Thermal Collector Installation the outdoor unit. Vertical Installation ________________________ Page 37...
  • Page 39 Operating Instructions and Installation Guide Wall Mounted Split System 2.5 Flat Panel Thermal Collector Installation • To Waste • _______________________ Page 38...
  • Page 40 Operating Instructions and Installation Guide Wall Mounted Split System 2.5 Flat Panel Option 2 • • It works on thermal radiation absorbtion. • HOW IT WORKS conductors which are welded behind this black chrome plate. The heat that is tansmitted to the copper Specification of Flat plate solar collectror size 1000×550×87(mm)
  • Page 41: Gassing Installation

    Operating Instructions and Installation Guide Wall Mounted Split System 2.6 Gassing Installation • If there is no nitrogen in the head unit check, for leak. pressure connecting pipes. spanner. • Vac down the thermal panel tank and indoor unit possible ( 1 hour minimum) ________________________ Page 40...
  • Page 42 Operating Instructions and Installation Guide Wall Mounted Split System 2.6 Gassing Installation sealing attachment. copper sealing attachment. • Use soapy water or halogen detection instrument to detect • sealing attachment. • • expel air. ________________________ Page 41...
  • Page 43 Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installation 3 Block Terminal the terminal board on the outdoor unit. WARNING: The heating element (white cable) that comes from the panel /tube does not need to be connected in warmer climates. This is an auxilary booster when temperatures are down to -0°...
  • Page 44: Wiring Installation

    Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installatio 3 Block Terminal The electrical terminations are: 1 = Brown 2 = Yellow jacket is held down. ________________________ Page 43...
  • Page 45 Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installation 3 Block Terminal ________________________ Page 44...
  • Page 46 Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installation 4 Block Terminal model has a backup heater to maintain the temperature in cold weather.. to the terminal board on the outdoor unit. WARNING: The heating element (white cable) that comes from the panel /tube does not need to be connected in warmer climates.
  • Page 47 Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installation 4 Block Terminal The electrical terminations are: 1 = Brown 2 = Yellow jacket is held down. _______________________ Page 46...
  • Page 48 Operating Instructions and Installation Guide Wall Mounted Split System 2.7 Wiring Installation 4 Block Terminal SWWR-26GW SWWR-35GW SWWR-60GW SWWR-72GW SWWR-35/35GW SWWR-72/72GW SWWR-35/72GW SWWR-26GW-3 SWWR-35GW-3 _______________________ Page 47...
  • Page 49: Operating Instructions

    Operating Instructions and Installation Guide Wall Mounted Split System Section 3 Operating Instructions ________________________ Page 48...
  • Page 50: General Operating Instructions

    Operating Instructions and Installation Guide Wall Mounted Split System 3.1 General Operating Instructions Optimum Operation • sunlight. system. Working Temperature Range Cooling Heating Indoor Temperature >18 Outdoor Temperature ________________________ Page 49...
  • Page 51: Remote Control Function

    Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type A. Remote Control Button Displays Signal Transmitting section Operation display Temp. adjustment button Power ON/OFF button Operation Selection Button Turbo button Fan speed control button Swing button LED button Timer ON/OFF button Time set button...
  • Page 52 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type A. Warning To Change Batteries Operate Automatically ensure they are disposed. According to the room temperature when two batteries. the operation starts the operation mode •The range that the signal can reach is about 6 •When the signal does not operate the replace the 2 batteries with the new ones...
  • Page 53 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type A. Caution To select the “COOL” “DRY” 1. When the room temperature is slightly lowered “FAN” “ON/OFF” modes in the outdoor and indoor unit operate 2. 3 minute delay star. 1.
  • Page 54 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type A. To set time ON/OFF Function Set the comfortable sleeping mode functio 1. The machine is on. the display and begins to glitter. It will last 1 min to 2.
  • Page 55 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type B. Remote Control Button Displays Signal Transmitting section Operation display Temp. adjustment button Fan speed control button e button Power ON/OFF button Sleep mode set button Swing button Operation Selection button Health set button...
  • Page 56 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function TypeB. Warning To Change Batteries Operate Automatically ensure they are disposed. According to the room temperature when two batteries. the operation starts the operation mode •The range that the signal can reach is about 6 beeps will be heard •When the signal does not operate the...
  • Page 57 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type B. Caution To select the “COOL” “DRY” 1. When the room temperature is slightly lowered in the outdoor and indoor unit operate “FAN” “ON/OFF” modes 2. 3 minute delay star. 1.
  • Page 58 Operating Instructions and Installation Guide Wall Mounted Split System 3.2 Remote Control Function Type B. To set time ON/OFF Function Set the comfortable sleeping mode functio 1. The machine is on. the display and begins to glitter. It will last 1 min to 2.
  • Page 59: Routine Maintenance

    Operating Instructions and Installation Guide Wall Mounted Split System 3.3 Routine Maintenance Thermal Collector maintenance. The water inside the solar collector and the copper piping entering and exiting the thermal collector Take particular care with water exiting the water drain. collector.
  • Page 60: Cleaning The Air Filter

    Operating Instructions and Installation Guide Wall Mounted Split System 3.3 Routine Maintenance Cleaning the air filter Frontpanel maintenance Cut off the power supply after using it for about 100 hours. the power supply. Clean as follows. Grasp position “a” and pull panel.
  • Page 61: Outdoor Unit

    Operating Instructions and Installation Guide Wall Mounted Split System 3.3 Routine Maintenance Outdoor Unit • Particular care should be taken when cleaning around the interconnecting electrical cable opening and plastic handles. ________________________ Page 60...
  • Page 62: Packing Lists

    Operating Instructions and Installation Guide Wall Mounted Split System 3.5 Packing List Outdoor Unit Packing List SWWR-26GW, SWWR-35GW, SWWR-60GW Name Spec. Quatntity Outdoor Unit Low Pressure Connecting Pipe *3600mm High Pressure Connecting Pipe *3600mm Plastic Belting T8*20m Penetration Joint #6 (cool & heat type)
  • Page 63: Packing List

    Operating Instructions and Installation Guide Wall Mounted Split System 3.5 Packing List Solar Collector Packing List 1. Vacuum Tube Name Type Insulated Tank 1 pce 10pcs (SWW(R)-26/35GW) Vacuuum Tube 11pcs (SWW(R)-60/72GW) Insulated Tank Support 1 pc Collector Tube Bracket 1 pc Ventilation Cup Groupware 1 pc Tube Supporting Bowl...
  • Page 64 Operating Instructions and Installation Guide Wall Mounted Split System NOTES _______ ________________________ Page 63...
