- Page 1 LCM1502TV ON OFF AUTO VOLUME CHANNEL TV/AV MENU ENTER Owner's Manual Audiovox Specialized Applications, LLC www.asaelectronics.com US PATENT # D467, 234...
- Page 2 Television viewing in a stationary vehicle. In the interest of safety, the LCM1502TV should vehicle will result in an improvement, but may still be never be installed where it will be visible, directly or marginal due to strength.
-
Page 3: Safety Precaution
Congratulations on your purchase of the Flexvision FEATURES LCM1502TV drop down TV/Video Monitor. The LCM1502TV has been designed to give you and your • 15" TFT (Thin Film Transistor) Active Matrix LCD family many years of video entertainment in the mobile (Liquid Crystal Display) Monitor environment. - Page 4 FRONT PANEL FEATURE Figure 1 1 2 3 4 5 7 8 9 ON OFF AUTO 1. POWER CHANNEL VOLUME TV/AV MENU ENTER 2. VOLUME UP and DOWN 3. TV/AV 4. SENSOR EYE 5. THREE POSITION DOME LIGHT SWITCH 6. SCREEN RELEASE 7.
- Page 5 4. Sensor Eye – Allows the remote control to operate the 11. 2 Channel Infrared Transmitter – Used to transmit audio LCM1502TV’s OSD system (On Screen Display), volume to the Wireless IR Headphones. to Wired Headphone Jacks (and optional external speakers), and for control of Video Media Player connected through a source component harness.
-
Page 6: Remote Control Operation
REMOTE CONTROL OPERATION EJECT/DVD POWER TV/CATV TV/VIDEO AUTO PROGRAM SKIP/ SEARCH ERASE/ PIC/SEL BATTERY INSTALLATION MENU MUTE ENTER Before attempting to operate the Remote Control, install the batteries as described below. RETURN DISPLAY 1) Turn the Remote Control face down. Press down on the VOL –... - Page 7 REMOTE CONTROL OPERATION 1. EJECT/DVD Button Press this button to eject a disc. 2. TV/VIDEO Button Press this button to access the AUDIO/VIDEO input jacks, on the front and rear of the TV. As the button is pressed, the on- screen display will cycle as follows: 3.
- Page 8 LEFT Button Allows the user to shift left in the menu options. (DVD) RETURN Button This button will allow you to go back one menu step. 10. VOLUME (–) Button Use these button to lower the TV sound level (also used to make picture adjustments in picture selector mode). 11.
- Page 9 17. "REW" REWIND Button If this button is pushed while the tape is stopped, the tape will rewind. If this button is pushed while the tape is playing, the VCP will go into rewind search mode. For more information on search feature of the VCP, consult VCP owner’s manual. This button also use to scans backward on a disc if the remote select to DVD mode.
- Page 10 24. DVD Button Switches certain function keys on the remote control for DVD functions. 25. VOLUME (+) Button Use these button to raise the TV sound level (also used to make picture adjustments in picture selector mode). 26. CHANNEL Button Use this button to advance to the next lower channel (also used to select desired function on the menu).
- Page 11 32. PIC/SEL Button Each time this button is pressed the on-screen picture adjustment display cycles through “adjustment screens” as follows: COLOR CONTRAST BRIGHTNESS SHARPNESS TINT Then use the VOLUME +/- buttons to raise (+) or lower (-) the level. The display will automatically turn off if no adjustments are made within four seconds, or if any other button is pressed.
-
Page 12: Adjusting The Picture
ADJUSTING THE PICTURE When watching TV programs, the quality of the picture can be adjusted to suit your taste. 1. Press MENU. The main menu appears. MAIN MENU SELECT VIDEO CLOSED CAPTION SET PICTURE AUTO-PROGRAM ANTENNA INPUT PARENTAL CONTROL 2. Press SELECT VIDEO. The video source appears. Press this button to access the AUDIO/VIDEO input jacks. - Page 13 3. Select CLOSED CAPTION and then press ENTER. Closed captioning lets you display the audio portion of a program as text on the TV screen. This is useful to the hearing impaired or anyone who wants to watch a program without the sound. There are two types of closed captioning available: C1 (Caption 1) and C2 (Caption 2).
- Page 14 5. Select the item to adjust. For example: To adjust brightness, press CHANNEL up or down buttons to select BRIGHTNESS and press ENTER. SET PICTURE 32 BRIGHTNESS COLOR CONTRAST BRIGHTNESS SHARPNESS TINT RESET 6. Adjust the level: Press VOLUME 50 BRIGHTNESS VOLUME...
- Page 15 7. To adjust other items, repeat all above. Notes: The menu or display disappears from the screen if you do not press + or – within a few seconds. Whenever a menu or display disappears from the screen, the + and – buttons on the front of the TV become the volume adjustment buttons.
- Page 16 8. Press either CHANNEL up or down to select the function. Make sure the highlight bar is AUTO PROGRAM and then press ENTER. MAIN MENU AUTO-PROGRAM SELECT VIDEO CLOSED CAPTION ERASE SET PICTURE AUTO PROGRAM AUTO-PROGRAM ANTENNA INPUT PARENTAL CONTROL 9.
- Page 17 CABLE TV (CATV) OPERATION In addition to normal broadcast reception of VHF and UHF channels, if you are a cable TV subscriber, your new TV is capable of receiving many unscrambled cable channels without the use of a converter box. When set to broadcast TV it receives channels 2~69.
-
Page 18: Parental Control Settings
PARENTAL CONTROL SETTINGS This item helps parents set the standard for the programs their children are going to watch. 1. With the TV on, press the MENU button until special menu will appear. 2. Use the Channel up and down buttons to select the Parental Control item. 3. - Page 19 PARENTAL CONTROL SETTINGS To access the PARENTAL CONTROL menu : 1. Make sure the remote is in TV mode by pressing the TV button. 2. Press MENU (the TV Main menu appears). 3. Press the down arrow button to highlight PARENTAL CONTROL, and press ENTER. Enter Password OSD appear, then enter Parental Control Password to go through Parental Control Setting.
- Page 20 ACTIVATING V-CHIP Selecting this option lets you activate and deactivate parental control settings. 1. Make sure the remote is in TV mode by pressing the TV button. 2. Press MENU (the Main menu appears). 3. Press the down arrow button until the PARENTAL CONTROL is highlighted, then press ENTER. 4.
- Page 21 TV RATINGS The TV Ratings screen allows you to block all program ratings and specific content themes above a specified age-based rating level. When you block a content theme for a specific rating, you automatically block that content theme for higher rated programs as well. For example, if you want your child to watch programs that have a TV-G rating and lower (in other words, you want the child to watch TV-G, TV-Y7, and TV-Y), then you need to block out higher ratings.
-
Page 22: Movie Ratings
MOVIE RATINGS The MOVIE RATINGS menu lets you decide which TV movies can and can’t be viewed according to the age-based rating of the MPAA (Motion Picture Association of America). The TV locks and unlocks the parental control settings using a password you select. If you want your child to watch movies that have a PG rating and lower (in other words, movies rated PG and G), then you could automatically block out all other movies with higher ratings. - Page 23 SETTING AND RESETTING YOUR PASSWORD Selecting this option lets you simply create a new password at any time. Once you enter a new password from the SET PASSWORD menu, it is the password you use until you change it again. 1.
-
Page 24: Operation
A three-position slide switch controls the Dome Lights on the The LCM1502TV incorporates a Infrared Sensor which relays LCM1502TV. Sliding the switch to the ON position will turn the the signals from the Remote Control to allow the LCM1502TV Dome Lights ON. The OFF position will prevent the Dome to be controlled simply by pointing it’s Remote Control at the... -
Page 25: Video Output
AUX IN-R (RED) monitor(s). This output will provide a video signal that duplicates the AUX IN-V (YLW) signal displayed by the LCM1502TV to an additional Monitor or Video IR2-IN-R (RED) IR2-IN-L (WHT) display. Please see your installer for more information. -
Page 26: Optional Accessories
WIRED FM MODULATOR (P/N FMT100) Your video system may be equipped with an optional RF modulator, that allows you to listen to the LCM1502TV’s audio signal by tuning your vehicle’s radio to the selected frequency, (88.7 or 89.1- check with your installer) and tuning on the remote mounted RF modulator switch. -
Page 27: Typical System Connections
TYPICAL SYSTEM CONNECTIONS 49 Mhz FM Transmitter Antenna Accessory Harness IR Transmitter LED 2 PIN IR Connector Yellow RCA(Video) White RCA(Audio Left) 4 PIN Power Red RCA(Audio Right) Connector... - Page 28 18 PIN MAIN HARNESS DETAIL PIN NO. COLOR FUNCTION AWG TERMINATION BLACK LINE AUDIO GROUND RED/WHITE RCA CONNECTOR BLACK AUDIO GROUND (SHIELD) 5-PIN CONNECTOR (PIN 2) BLACK POWER GROUND 5-PIN CONNECTOR (PIN 5) LINE AUDIO (R) OUT RED RCA CONNECTOR YELLOW VIDEO OUT YELLOW RCA CONNECTOR...
-
Page 29: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION Poor TV Reception • Perform auto programming of the tuner • Verify antenna condition. • NOTE: Due to the nature of TV signals, vehicle motion, direction the vehicle is facing, distance from the transmitter, nearby surroundings and weather may adversely affect TV reception. -
Page 30: Specifications
SPECIFICATIONS LCD Brightness 450 nits (min) Operation Temperature -20°C~ 65°C Storage Temperature -40°C ~ 80°C Video Display System NTSC Audio Output 0.6W (Variable) Current Draw 3.2A Weight 6 kgs Overall Dimensions 15.5" x 14.5" x 2.5" (H x W x D) - Page 31 90 DAY/ 12 MONTH LIMITED WARRANTY AUDIOVOX SPECIALIZED APPLICATION, LLC (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced (at the Company's option) without charge for parts and repair labor.
- Page 32 www.asaelectronics.com 01/2006...
