  • Page 2 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other in- Interior features terior features for a comfortable driving experience. Maintenance and Cleaning and protecting your vehicle, performing do-it- care...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Index 1-7. Safety information Before driving Correct driving posture..77 SRS airbags ......79 Child restraint systems..91 1-1. Key information Installing child restraints..99 Keys........20 1-2. Opening, closing and When driving locking the doors Smart entry & start system ... 23 Wireless remote control ..
  • Page 4 2-3. Operating the lights and 3-2. Using the audio system wipers Audio system types .... 214 Headlight switch....159 Using the radio ....216 Fog light switch ....163 Using the CD player ... 220 Windshield wipers and Playing back MP3 and washer ......
  • Page 5 TABLE OF CONTENTS Index 3-4. Using the hands-free Maintenance and care phone system (for cellular phone) Hands-free phone system 4-1. Maintenance and care (for cellular phone) Cleaning and protecting features......263 the vehicle exterior... 306 Using the hands-free Cleaning and protecting phone system the vehicle interior....
  • Page 6 When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 374 Maintenance data (fuel, oil level, etc.) ... 426 If your vehicle needs to be towed ......375 Fuel information ....436 If you think something is wrong........
  • Page 7 Pictorial index Exterior Windshield wipers P. 164 ∗ Moon roof P. 62 Outside rear view mirrors P. 57 Hood P. 318 Turn signal lights P. 133 Turn signal lights P. 133 Headlights (high beam) P. 159 Headlights (low beam) P. 159 Front position lights P.
  • Page 8 Rear window defogger P. 213 Fuel filler door P. 66 Trunk P. 39 Doors P. 36 License plate lights P. 159 Tires ●Rotation P. 335 Turn signal lights P. 133 ●Replacement P. 398 ●Inflation pressure P. 434 Tail lights P. 159 ∗...
  • Page 9 Pictorial index Interior Head restraints P. 46 Parking brake lever P. 134 SRS driver airbag P. 79 Seat belts P. 48 Horn P. 135 Power window Auxiliary box P. 296 ∗ switches P. 59 SRS front passenger airbag P. 79 Glove box P.
  • Page 10 ∗ Rear view monitor system P. 174 Vanity mirrors P. 299 Sun visors P. 298 Auxiliary box P. 296 Personal lights P. 290 Anti-glare inside rear view mirror P. 55 Interior light P. 290 ∗ SRS curtain shield airbags P. 79 ∗...
  • Page 11 Pictorial index Interior Type A Power window switches P. 59 Door lock switch P. 36 Window lock switch P. 59...
  • Page 12 Type B Power window switches P. 59 Door lock switch P. 36 Window lock switch P. 59...
  • Page 13 Pictorial index Instrument panel ∗ Audio switches P. 248 Gauges and meters P. 136 Multi-information display P. 146, 155 Windshield wiper and Headlight switch P. 159 washer switch P. 164 Turn signal lever P. 133 ∗ Emergency flasher switch Fog light switch P.
  • Page 14 Vehicles with an automatic air conditioning system Air conditioning system P. 202 Rear window defogger switch P. 213 ∗ Engine immobilizer system/alarm indicator P. 70, 74 Vehicles with a manual air conditioning system Air conditioning system P. 208 Rear window defogger switch P.
  • Page 15 Pictorial index Instrument panel ∗ Talk switch P. 268 ∗ Telephone switch P. 268 ∗ Cruise control switch P. 170 Engine (ignition) switch (vehicles without a smart entry & start system) P. 126...
  • Page 16 Outside rear view mirror switches P. 57 ∗ VSC/TRC off switch P. 182 ∗ Manual headlight leveling dial P. 160 ∗ Headlight cleaner switch P. 169 Auxiliary box P. 296 ∗ : If equipped...

  • Page 17: For Your Information

    All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of equipment.
  • Page 18 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 19 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

  • Page 20: Before Driving

    Before driving 1-1. Key information 1-5. Refueling Keys........20 Opening the fuel tank cap........66 1-2. Opening, closing and 1-6. Theft deterrent system locking the doors Engine immobilizer Smart entry & start system ......70 system ......23 Double locking system..72 Wireless remote control ..

  • Page 21: Keys

    1-1. Key information Keys The following keys are provided with the vehicle. Vehicles with a smart entry & start system Electronic keys • Operating the smart entry & start system (→P. 23) • Operating wireless remote control function (→P. 33) Mechanical keys Key number plate Vehicles without a smart entry &...
  • Page 22 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 410) ■...
  • Page 23 1-1. Key information NOTICE ■ To prevent key damage ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.

  • Page 24: Opening, Closing And Locking The Doors Smart Entry & Start System

    1-2. Opening, closing and locking the doors ∗ Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key...
  • Page 25 1-2. Opening, closing and locking the doors Unlocking and locking the doors (front door handles only) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
  • Page 26 1-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside the cabin Antenna outside the trunk Antenna inside the trunk Antennas inside the cabin...
  • Page 27 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handles.
  • Page 28 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situ- ations, the communication between the electronic key and the vehicle may be affected, preventing the smart entry &...
  • Page 29 1-2. Opening, closing and locking the doors The system will resume operation when... ● The vehicle is locked using the door handle lock switch. ● The vehicle is locked/unlocked using the wireless remote control func- tion. (→P. 33) ● The vehicle is locked/unlocked using the mechanical key. (→P. 411) ■...
  • Page 30 1-2. Opening, closing and locking the doors • The electronic key is near the ground or in a high place, or too close to the rear bumper center when the trunk is unlocked. • The electronic key is on the instrument panel, package tray, floor, or in the glove box when the engine is started or “ENGINE START STOP”...
  • Page 31 1-2. Opening, closing and locking the doors The following table describes circumstances and correction procedures when only alarms are sounded. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- using the entry function tronic key from the while the electronic key passenger compart- was still inside the passen-...
  • Page 32 Starting the engine: →P. 412 ● ■ When the electronic key battery is fully depleted →P. 345 ■ Customization that can be configured at Toyota dealer It is possible to deactivate the smart entry & start system, etc. (Customizable features→P. 437)
  • Page 33 (→P. 25) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.

  • Page 34: Wireless Remote Control

    1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles with a smart entry & start system Locks all doors Unlocks all doors Unlocks the trunk (Push and hold) Vehicles without a smart entry &...
  • Page 35 1-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds (vehicles with a smart entry & start system) and the emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: Once; Unlocked: Twice) Trunk: A buzzer sounds to indicate that the trunk has been unlocked.
  • Page 36 When a wireless key (that emits radio waves) is being used nearby ● When the wireless key has been left near an electrical appliance such as a personal computer ■ Customization that can be configured at Toyota dealer Settings (e.g. trunk unlocking function) can be changed. (Customizable features→P. 437)

  • Page 37: Doors

    1-2. Opening, closing and locking the doors Doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. ■ Entry function (vehicles with a smart entry & start system) →P. 24 ■...
  • Page 38 1-2. Opening, closing and locking the doors ■ Inside lock button Locks the door Unlocks the door Pulling the door handle can open the driver's door even if the lock button is in the lock position. Locking the front doors from the outside without a key Move the inside lock button to the lock position.
  • Page 39 1-2. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...

  • Page 40: Trunk

    1-2. Opening, closing and locking the doors Trunk The trunk can be opened using the key, trunk opener, entry function or wireless remote control. ■ Opening the trunk from inside the vehicle Trunk opener Pull up the lever to release the trunk lid.
  • Page 41 1-2. Opening, closing and locking the doors Luggage security system To protect luggage stored in the trunk against theft, do the following procedures. Push down the security lock STEP levers to lock the rear seatbacks. Turn the master key (vehicles STEP without a smart entry &...
  • Page 42 1-2. Opening, closing and locking the doors ■ Which key to the vehicle is to leave with a parking attendant after the luggage security system is set →P. 21 CAUTION ■ Caution while driving ● Keep the trunk lid closed while driving. If the trunk lid is left open, it may hit near-by objects while driving or lug- gage in the trunk may be unexpectedly thrown out, causing an accident.
  • Page 43 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.

  • Page 44: Adjustable Components Front Seats

    1-3. Adjustable components Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) CAUTION ■ Seat adjustment ● Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of...

  • Page 45: Rear Seats

    1-3. Adjustable components Rear seats The seatbacks of the rear seats can be folded down. Stow the rear outside seat belt STEP buckles and move the rear center seat belt buckle as shown. Check that the security lock STEP lever in the trunk is raised. Fold the seatback down while STEP pulling...
  • Page 46 1-3. Adjustable components CAUTION ■ After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the seatback is securely locked in position by lightly rocking it back and forth.

  • Page 47: Head Restraints

    1-3. Adjustable components Head restraints Pull the head restraints up. Down Push and hold the lock release button when lowering the head restraint. Lock release button ■ Removing the head restraints Pull the head restraint up while pushing the lock release button. Lock release button ■...
  • Page 48 1-3. Adjustable components CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...

  • Page 49: Seat Belts

    1-3. Adjustable components Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the neck or slide off the shoul-...
  • Page 50 1-3. Adjustable components ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal...
  • Page 51 1-3. Adjustable components ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 52 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 53 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 54 1-3. Adjustable components CAUTION ■ For Australian owners Observe the following additional WARNINGS. WARNING: Seatbelts are designed to bear upon the bony structure of the body, and should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as applicable;...

  • Page 55: Steering Wheel

    1-3. Adjustable components Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically. After adjustment, pull the lever up to secure the steering wheel.

  • Page 56: Anti-Glare Inside Rear View Mirror

    1-3. Adjustable components Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light.
  • Page 57 1-3. Adjustable components ■ To prevent sensor error (vehicles with an auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. ■ When the shift lever is in R (vehicles with a rear view monitor system) The auto anti-glare function will not operate.

  • Page 58: Outside Rear View Mirrors

    1-3. Adjustable components Outside rear view mirrors Mirror angle can be adjusted using the switches. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down Left...
  • Page 59 1-3. Adjustable components Folding back the mirrors Push backward to fold the mir- rors. ■ The outside rear view mirrors can be operated when Vehicles without a smart entry & start system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart entry &...

  • Page 60: Opening And Closing The

    1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway.
  • Page 61 1-4. Opening and closing the windows and moon roof ■ The power windows can be operated when Vehicles without a smart entry & start system The engine switch is in the “ON” position. Vehicles with a smart entry & start system The “ENGINE START STOP”...
  • Page 62 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. CAUTION ■...

  • Page 63: Moon Roof

    1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open The moon roof stops slightly before the fully opened posi- tion to reduce wind noise.
  • Page 64 1-4. Opening and closing the windows and moon roof ■ The moon roof can be operated when Vehicles without a smart entry & start system The engine switch is in the “ON” position. Vehicles with a smart entry & start system The “ENGINE START STOP”...
  • Page 65 1 second. Then it will tilt down, open and close. Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer.
  • Page 66 1-4. Opening and closing the windows and moon roof CAUTION ■ Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.

  • Page 67: Refueling Opening The Fuel Tank Cap

    1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Vehicles without a smart entry & start system Turn the engine switch OFF and ensure that all the doors and win- dows are closed.
  • Page 68 ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
  • Page 69 This may cause static electricity to build up, resulting in a possible ignition hazard. ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 70 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface.

  • Page 71: 1-6. Theft Deterrent System

    1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without a smart entry &...
  • Page 72 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle NOTICE ■...

  • Page 73: Double Locking System

    1-6. Theft deterrent system ∗ Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this sys- tem have labels on the win- dow glass of both front doors.
  • Page 74 1-6. Theft deterrent system Canceling the double locking system Using the entry function: Hold the outside door handle on the driver side. Using the wireless remote control: Press CAUTION ■ Double locking system precaution Never activate the double locking system when there are people in the vehi- cle, because all the doors cannot be opened from inside the vehicle.

  • Page 75: Alarm

    1-6. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations when the alarm is set. ● A locked door or trunk is unlocked or opened in any way other than using the entry function or wireless remote control door lock function.
  • Page 76 1-6. Theft deterrent system ■ Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm: ● Unlock the doors or trunk using the entry function or wireless remote control. ● Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■...
  • Page 77 1-6. Theft deterrent system ● A person inside the vehicle opens a door, the trunk or hood. ● The battery is recharged or replaced when the vehicle is locked. ■ When the battery is disconnected Be sure to cancel the alarm system. If the battery is disconnected before canceling the alarm, the system may be triggered when the battery is reconnected.

  • Page 78: Safety Information Correct Driving Posture

    1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 43) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 79 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.

  • Page 80: Srs Airbags

    1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 81 1-7. Safety information Airbag system components Driver’s knee airbag SRS warning light equipped) Driver airbag Front passenger airbag Side and curtain shield Curtain shield airbags airbag sensors (if equipped) equipped) Side airbags (if equipped) Airbag sensor assembly Curtain shield airbag sen- Front airbag sensors sors (if equipped) The main SRS airbag system components are shown above.
  • Page 82 1-7. Safety information ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Vehicles with curtain shield airbags: Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, and parts of the front and rear pillars and roof side rail, may be hot for several min- utes.
  • Page 83 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
  • Page 84 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags [if equipped]) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 85 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
  • Page 86 1-7. Safety information ● The surface of the seats with the side airbag (if equipped) is scratched, cracked, or otherwise damaged. ● Vehicles with curtain shield airbags: The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked or other- wise damaged.
  • Page 87 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 88 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 89 1-7. Safety information CAUTION ■ SRS airbag precautions ● Vehicles with curtain shield airbags: Do not lean against the door, the roof side rail or the front, side and rear pillars. ● Vehicles without curtain shield airbags: Do not lean against the front door. ●...
  • Page 90 1-7. Safety information CAUTION ■ SRS airbag precautions ● Vehicles with curtain shield airbags: Do not attach anything to areas such as the door, windshield glass, side door glass, front and rear pillars, roof side rail or assist grip. ● Vehicles with curtain shied airbags: Do not hang coat hangers or other hard objects on the coat hooks.
  • Page 91 ● Vehicles with curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillars garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ● Vehicles without curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad are damaged or cracked, have them replaced by your Toyota dealer.

  • Page 92: Child Restraint Systems

    General installation instructions are provided in this manual. (→P. 99) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. ● Toyota recommends that you use a child restraint system which conforms to the regulation “ECE No.44”.
  • Page 93 1-7. Safety information Baby seat (infant seat) Equal to Group 0 and 0 of “ECE No.44” Child seat (convertible seat) Equal to Group 0 and I of “ECE No.44” Junior seat (booster seat) Equal to Group II and III of “ECE No.44”...
  • Page 94 1-7. Safety information Child restraint system suitability for various seating positions Provided information in the table shows your child restraint system suitability for various seating positions. Seating position Rear seat Front passenger seat Outside Center Mass groups Up to 10 kg (22 lb.) Never put (0 - 9 months) Up to 13 kg (28 lb.)
  • Page 95 1-7. Safety information Key of letters inserted in the above table: Suitable for “universal” category child restraint system approved for the use in this mass group. UF: Suitable for forward-facing “universal” category child restraint system approved for the use in this mass group. Not suitable seat position for children in this mass group.
  • Page 96 1-7. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchor) Provided information in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Rear outside ISO/L1 Carrycot ISO/L2...
  • Page 97 1-7. Safety information (1) For the CRS which do not carry the ISO/XX size class identifica- tion (A to G), for the applicable mass group, the car manufac- turer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for use in this mass group.
  • Page 98 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 99 1-7. Safety information CAUTION ■ Child restraint precautions ● Vehicles with side and curtain shield airbags: Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system.

  • Page 100: Installing Child Restraints

    1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts on the rear seats)
  • Page 101 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing  Baby seat (infant seat)/child seat (convertible ■ seat) Place the child seat on the rear STEP seat facing the rear of the vehi- cle.
  • Page 102 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 103 1-7. Safety information Forward facing  Child seat (convertible seat) ■ Place the child seat on the seat STEP facing the front of the vehicle. Run the seat belt through the STEP child seat and insert the plate into the buckle. Make sure that the belt is not twisted.
  • Page 104 1-7. Safety information Remove the head restraint. STEP Latch the hook of the top strap STEP onto the anchor bracket. (→P. 106) Make sure the seat belt is tightly secured, and that there is not slack in the belt. Replace the head restraint. STEP...
  • Page 105 1-7. Safety information ■ Junior seat (booster seat) Place the junior seat (booster STEP seat) on the seat facing the front of the vehicle. Sit the child in the junior seat STEP (booster seat). Fit the seat belt to the junior seat (booster seat) according to the manufacturer's instructions and insert the plate into the buckle.
  • Page 106 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint system) Check the positions of the exclu- sive fixing bars, and install the child restraint system to the seat.
  • Page 107 1-7. Safety information Child restraint systems with a top strap Secure the child restraint using a seat belt or ISOFIX rigid STEP anchors, and do the following. Outside Remove the head restraint. Center Lower the head restraint to the lowest position. Open the anchor bracket cover, STEP Front of vehicle...
  • Page 108 Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119-22010)
  • Page 109 1-7. Safety information CAUTION ■ When installing a junior (booster) seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 50) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
  • Page 110 1-7. Safety information CAUTION ■ When installing a child restraint system ● Extreme Hazard! Do not use a rear- ward facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid infla- tion of the front passenger airbag can cause death or serious injury to the child.
  • Page 111 When installing a child restraint system ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system installation. ● When a junior (booster) seat is installed, always ensure that the shoulder belt is positioned across the center of the child's shoulder.

  • Page 112: When Driving

    When driving 2-1. Driving procedures 2-3. Operating the lights and wipers Driving the vehicle .... 112 Headlight switch....159 Engine (ignition) switch (vehicles with a smart Fog light switch ....163 entry & start system)..122 Windshield wipers and Engine (ignition) switch washer ......

  • Page 113: Driving Procedures Driving The Vehicle

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 122, 126 ■ Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. STEP (→P.
  • Page 114 2-1. Driving procedures ■ Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. STEP Set the parking brake. (→P. 134) STEP Shift the shift lever to P. (→P. 129) STEP When parking on a hill, if necessary, block the wheels. Turn the “ENGINE START STOP”...
  • Page 115 ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ●...
  • Page 116 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the trunk is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immedi- ately. ●...
  • Page 117 2-1. Driving procedures CAUTION ● Do not shift the shift lever to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to D (vehicles with an automatic transmission) or 1 (vehicles with a manual transmission) while the vehicle is moving back- ward.
  • Page 118 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ● Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
  • Page 119 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in...
  • Page 120 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
  • Page 121 2-1. Driving procedures NOTICE ■ When driving the vehicle Vehicles with a manual transmission ● Do not rest your foot on the clutch pedal while driving. Doing so may cause clutch trouble. ● Do not use any gears other than the first gear when starting off and mov- ing forward.
  • Page 122 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...

  • Page 123: Engine (Ignition) Switch (Vehicles With A Smart Entry & Start System)

    2-1. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine Check that the parking brake is set.
  • Page 124 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* Emergency flashers can be used.
  • Page 125 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power off function The “ENGINE START STOP” switch will automatically turn OFF when left in ACCESSORY mode for 1 hour or more.
  • Page 126 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...

  • Page 127: Engine (Ignition) Switch (Vehicles Without A Smart Entry & Start System)

    2-1. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) ■ Starting the engine Automatic transmission Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
  • Page 128 2-1. Driving procedures ■ Turning the key from “ACC” to “LOCK” Shift the shift lever to P (auto- STEP matic transmission) or N (man- ual transmission). (→P. 129, 131) Push in the key and turn to the STEP “LOCK” position. ■...
  • Page 129 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for a long period if the engine is not running. ■ When starting the engine ● Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.

  • Page 130: Automatic Transmission

    2-1. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever Vehicles without a smart entry & start system While the engine switch is in the “ON” position, depress the brake pedal and move the shift lever. Vehicles with a smart entry &...
  • Page 131 2-1. Driving procedures ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving* Position for engine braking Position for more powerful engine braking Position for maximum engine braking : Shifting to the D position allows the system to select a gear suitable for the driving conditions.

  • Page 132: Manual Transmission

    2-1. Driving procedures ∗ Manual transmission ■ Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. ■ Shifting the shift lever to R Shift the shift lever to R while lifting up the ring section.
  • Page 133 2-1. Driving procedures ■ Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. km/h (mph) Shift position Maximum speed 45 (27) 84 (52) 123 (76) 166 (103) 197 (122) NOTICE ■ To prevent damage to the transmission ●...

  • Page 134: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.

  • Page 135: Parking Brake

    2-1. Driving procedures Parking brake Setting the parking brake Fully set the parking brake while depressing the brake pedal. Releasing the parking brake Slightly raise the lever and then lower it completely while pressing the button. ■ Usage in winter time See “Winter driving tips”...

  • Page 136: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.

  • Page 137: Instrument Cluster Gauges And Meters

    2-2. Instrument cluster Gauges and meters ■ Optitron type meters Vehicles without a smart entry & start system The following gauges, meters and displays illuminate when the engine switch is in the “ON” position. Vehicles with a smart entry & start system The following gauges, meters and displays illuminate when the “ENGINE START STOP”...
  • Page 138 2-2. Instrument cluster Odometer/trip meter display change button →P. 139 Odometer, trip meter and instrument panel light control display Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset.
  • Page 139 2-2. Instrument cluster ■ Non-Optitron type meters Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Low fuel level warning light →P. 387 Odometer/trip meter display change button →P.
  • Page 140 2-2. Instrument cluster Odometer, trip meter and instrument panel light control display Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
  • Page 141 2-2. Instrument cluster Vehicles with non-Optitron type meters Odometer Trip meter A Trip meter B Instrument panel light control display (when the headlight switch is on) : Pushing and holding the button will reset the trip meter. : Pushing and holding the button will adjust brightness of the instrument panel lights.

  • Page 142: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. ■ Instrument cluster Vehicles with Optitron type meters Vehicles with non-Optitron type meters...
  • Page 143 2-2. Instrument cluster ■ Center panel...

  • Page 144: Tail Lights

    There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
  • Page 145 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
  • Page 146 Have the vehicle inspected by your Toyota dealer immediately if this occurs.

  • Page 147: Multi-Information Display (Vehicles With Optitron Type Meters)

    2-2. Instrument cluster Multi-information display (vehicles with Optitron type meters) The multi-information display presents the driver with a variety of driving-related data, including the current outside temperature, clock and date. ● Outside temperature dis- play (→P. 147) Indicates the outside tempera- ture.
  • Page 148 2-2. Instrument cluster Switching the display Display items can be switched by pressing the “DISP” button. ● Clock Displays the clock. ● Outside temperature Displays the outside temperature. The temperature range that can be displayed is from -30°C (-22°F) to 50°C (122°F). ●...
  • Page 149 2-2. Instrument cluster ● Average fuel consumption Displays the average fuel consumption since the function was reset. • The function can be reset by pressing the “DISP” button for longer than one second when the aver- age fuel consumption is displayed. •...
  • Page 150 2-2. Instrument cluster Setting up display ■ Before setting Display the set up screen on the multi-information display STEP when the vehicle is stopped. Press and hold the “DISP” button STEP to enter the adjustment mode. Select the desired item on the STEP menu screen.
  • Page 151 2-2. Instrument cluster ■ Setting the clock Select “CLOCK” on the menu screen. (→P. 149) STEP Press the “DISP” button to adjust STEP the hours. After adjusting the hours, wait 5 seconds to allow the hours to be automatically input. Press the “DISP”...
  • Page 152 2-2. Instrument cluster ■ Setting the date Select “DATE” on the menu screen. (→P. 149) STEP Press the “DISP” button to select STEP the year. After selecting the year, wait 5 seconds to allow the year to be automatically input. Press the “DISP”...
  • Page 153 2-2. Instrument cluster ■ Selecting the units Select “UNITS” on the menu screen. (→P. 149) STEP Select the desired item on the STEP unit screen. Press and hold the “DISP” button to input the choice. Select the desired item. STEP Distance units Select the desired distance unit.
  • Page 154 2-2. Instrument cluster Date form Select the desired date form. Press and hold the “DISP” button to input the choice. ■ Selecting the language Select “LANGUAGE” on the menu screen. (→P. 149) STEP Select the desired language. STEP Press and hold the “DISP” button to input the choice.
  • Page 155 2-2. Instrument cluster ■ System check display (if equipped) Vehicles without a smart entry & start system After turning the engine switch to the “ON” position, system operation is checked. When the system check is complete, is displayed before returning to the normal screen. Vehicles with a smart entry &...

  • Page 156: Multi-Information Display (Vehicles With Non-Optitron Type Meters)

    2-2. Instrument cluster Multi-information display (vehicles with non-Optitron type meters) The multi-information display presents the driver with a variety of driving-related data, including the current outside temperature and clock. Clock Indicates the time and sets the clock. Trip information and outside temperature display Trip information: Displays driv- ing range, fuel consumption...
  • Page 157 2-2. Instrument cluster ● Outside temperature Displays the outside temperature. The temperature range that can be displayed is from -30°C (-22°F) to 50°C (122°F). ● Instantaneous fuel consumption Displays instantaneous fuel consumption. ● Average fuel consumption Displays the average fuel consumption since the function was reset.
  • Page 158 2-2. Instrument cluster ● Average vehicle speed Displays the average vehicle speed since the engine was started or the function was reset. The function can be reset by pressing the “DISP” but- ton for longer than one second when the average vehicle speed is displayed.
  • Page 159 2-2. Instrument cluster ■ When disconnecting and reconnecting battery terminals The following information data will be reset. ● Clock ● Average fuel consumption ● Driving range ● Average vehicle speed ■ Outside temperature display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to charge.

  • Page 160: Operating The Lights And

    2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. The front position, tail, license plate instrument panel lights turn on. The headlights and all lights listed above turn (If equipped) The headlights and front position lights...
  • Page 161 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to flash the high beams.
  • Page 162 2-3. Operating the lights and wipers ■ Guide to dial settings Occupancy and luggage load conditions Dial position Occupants Luggage load Driver None Driver and front pas- None senger All seats occupied None All seats occupied Full luggage loading Driver Full luggage loading ■...
  • Page 163 ■ Customization that can be configured at Toyota dealer Settings of light sensor sensitivity can be changed. (Customizable features→P. 437) NOTICE ■...

  • Page 164: Fog Light Switch

    2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. The fog lights can be used when the headlights or front position lights are turned on. Front fog lights on ∗...

  • Page 165: Windshield Wipers And Washer

    2-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper with interval adjuster When intermittent wiper operation is selected, wiper intervals can be adjusted. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Decreases the intermittent windshield wiper frequency...
  • Page 166 2-3. Operating the lights and wipers Wash/wipe operation Wipers operate automatically. Rain-sensing windshield wipers With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper opera- tion Low speed wiper operation...
  • Page 167 2-3. Operating the lights and wipers Sensor sensitivity (low) Sensor sensitivity (high) Wash/wipe operation Wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) ■ The windshield wiper and washer can be operated when Vehicles without a smart entry &...
  • Page 168 2-3. Operating the lights and wipers ■ Raindrop sensor (vehicles with rain-sensing windshield wipers) ● The raindrop sensor judges the amount of raindrops. An optical sensor is adopted. It may not operate properly when sunlight from the rising or setting of the sun intermittently strikes the windshield, or if bugs etc.
  • Page 169 2-3. Operating the lights and wipers NOTICE ■ When the windshield is dry Do not use the wipers, as they may damage the windshield. ■ When the washer fluid tank is empty Do not operate the switch continually as the washer fluid pump may over- heat.

  • Page 170: Headlight Cleaner Switch

    2-3. Operating the lights and wipers ∗ Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ■ The headlight cleaner can be operated when Vehicles without a smart entry & start system When the engine switch is in the “ON”...

  • Page 171: 2-4. Using Other Driving Systems

    2-4. Using other driving systems ∗ Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch ■ Set the vehicle speed Turn the “ON-OFF” button on. STEP Press the button once more to deactivate the cruise control.
  • Page 172 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releasing it.
  • Page 173 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected.
  • Page 174 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Keep the “ON-OFF” button off when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause an accident resulting in death or serious injury.

  • Page 175: Rear View Monitor System

    2-4. Using other driving systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen. This reversed image is a similar image to the one on the inside rear view mirror.
  • Page 176 2-4. Using other driving systems ■ Rear view monitor guide lines Guide lines are displayed on the screen. The guide lines may look differently depending on vehicle orientation or road conditions. Vehicle width extension guide lines (blue) These lines indicate the estimated vehicle width extension. Distance guide line (blue) This line indicates a position on the ground about 1 m (3 ft.) behind on the ground of the rear bumper of your vehicle.
  • Page 177 2-4. Using other driving systems ■ Switching the screen ON/OFF mode When the screen is displayed, press “AUTO” on the inside rear view mirror to switch the screen ON/OFF mode. Screen ON mode: Green indicator comes Screen OFF mode: Amber indicator comes on.
  • Page 178 2-4. Using other driving systems ■ Rear view monitor system camera The rear view monitor system camera is located on the trunk as shown in the illus- tration. The camera uses a special lens. The distance of the image that appears on the screen differs from the actual dis- tance.
  • Page 179 2-4. Using other driving systems ■ Smear effect If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect* characteristic to the camera may occur. *: Smear effect: A phenomenon that occurs when a bright light is picked up by the camera;...
  • Page 180 Conditions which may affect the rear view monitor system ● If the back of the vehicle has been hit, the camera’s position and mounting angle may have changed. Have the vehicle inspected by your Toyota dealer. ● Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
  • Page 181 If this happens, wipe it off as soon as possible. Do not rub hard. ● When replacing tires, please consult your Toyota dealer. If you replace the tires, the area displayed on the screen may change.

  • Page 182: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 183 2-4. Using other driving systems Vehicles with non-Optitron type meters If the vehicle is in danger of slip- ping or the front wheels spin, the indicator flashes to indicate that the VSC/TRC systems have been engaged. A buzzer (intermittent) sounds to indicate that VSC is operating.
  • Page 184 2-4. Using other driving systems ■ Turning off TRC and VSC Vehicles with Optitron type meters Push and hold the button for more than 3 seconds while the vehicle is stopped to turn off TRC and VSC. The slip indicator light and mes- sage on multi-information display should come on.
  • Page 185 2-4. Using other driving systems ■ Reactivation of TRC and VSC linked to the engine switch position (vehicles without a smart entry & start system) Turning the engine switch OFF after turning off the TRC and VSC systems will automatically re-enable them. ■...
  • Page 186 If the slip indicator comes on and stays on The following cases may indicate that a malfunction has occurred in the VSC system or the TRC system. Contact your Toyota dealer immediately. Vehicles with Optitron type meters The warning message on the multi-information display comes on and a buzzer sounds.
  • Page 187 In addition, make sure that the tires are inflated to the appro- priate tire pressure level. The ABS and VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.

  • Page 188: Driving Information Cargo And Luggage

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. ● Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
  • Page 189 2-5. Driving information CAUTION ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.

  • Page 190: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 191 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission) or R (manual transmission) without setting the parking brake.
  • Page 192 2-5. Driving information ■ Tire chains Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires. ● Install tire chains following the instructions provided in the accompanying manual.

  • Page 193: Trailer Towing

    To tow a trailer safely, use extreme care and drive the vehicle in accordance with the trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. For towing purposes, we recommend use of the following parts: ●...
  • Page 194 Total trailer weight Tongue load Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kits, etc.
  • Page 195 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 800 km (500 miles) of driving.
  • Page 196 2-5. Driving information CAUTION ■ To avoid accident or injury ● The total trailer weight (trailer weight plus the weight of cargo) must not exceed 1300 kg (2866 lb.). ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue load capacities.
  • Page 197 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
  • Page 198 2-5. Driving information ● As stopping distance is increased when towing a trailer, vehicle-to- vehicle distance should be increased. For each 10 km/h (6 mph) of speed, allow at least one vehicle and trailer length. ● Avoid sudden braking as you may skid, resulting in jackknifing and loss of control.
  • Page 199 2-5. Driving information ● Due to the added load of the trailer, your vehicle's engine may overheat on hot days (at temperatures over 30°C [85°F]) when driving up a long or steep grade. If the engine coolant temperature gauge indicates overheating, immediately turn off the air condition- ing (if in use), pull your vehicle off the road and stop in a safe spot.
  • Page 200 2-5. Driving information CAUTION ■ To avoid an accident ● Observe the legal maximum speeds for trailer towing. ● Slow down and downshift before descending steep or long downhill grades. Do not make sudden downshifts while descending steep or long downhill grades.

  • Page 201: 3-1. Using The Air Conditioning

    3-1. Using the air conditioning system and defogger Automatic air conditioning system ......202 Manual air conditioning system ......208 Rear window defogger..213 3-2. Using the audio system Audio system types... 214 Using the radio....216 Using the CD player..220 Playing back MP3 and WMA discs......
  • Page 202 Interior features ® 3-3. Using the Bluetooth 3-5. Using the interior lights audio system Interior lights list....289 ® • Interior light......290 Bluetooth audio • Personal lights ....290 system ......251 ® Using the Bluetooth 3-6. Using the storage features audio system ....

  • Page 203: Automatic Air Conditioning System

    3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets are automatically selected and fan speed is automatically adjusted according to the temperature setting. Temperature control Automatic mode Windshield defogger Air conditioning Outside air or on/off button recirculated air mode Fan speed...
  • Page 204 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on ■ Adjusting the fan speed Press “∧” (increase) or “∨” (decrease) on The fan speed is shown on the display.
  • Page 205 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. Air flows to the feet. Air flows to the feet and the windshield defogger operates. ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) each time...
  • Page 206 3-1. Using the air conditioning system and defogger Defogging the windshield Defogging The air conditioning system oper- ates automatically. Recirculated air mode will auto- matically switch to outside air mode. Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down.
  • Page 207 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
  • Page 208 3-1. Using the air conditioning system and defogger NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is stopped.

  • Page 209: Manual Air Conditioning System

    3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air outlet selection dial Temperature control dial Fan speed control dial Outside air or recirculated air mode Air conditioning on/off button Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
  • Page 210 3-1. Using the air conditioning system and defogger ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can also be selected for more detailed adjustment. Air flows to the upper body.
  • Page 211 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. Air flows to the windshield and side windows. The air intake is automatically switched to outside air mode. Pressing to turn the air conditioning on clears the wind- shield and side windows faster.
  • Page 212 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down. Turn the knob up to open the vent and down to close the vent.
  • Page 213 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.

  • Page 214: Rear Window Defogger

    3-1. Using the air conditioning system and defogger Rear window defogger Clear the rear window using the defogger. Vehicles with an automatic air conditioning system On/off The defoggers will automati- cally turn after approximately15 minutes. Vehicles with a manual air conditioning system On/off...

  • Page 215: Using The Audio System Audio System Types

    3-2. Using the audio system ∗ Audio system types CD player with changer controller and AM/FM radio Title Page Using the radio P. 216 Using the CD player P. 220 Playing back MP3 and WMA discs P. 225 Operating an iPod P.
  • Page 216 3-2. Using the audio system NOTICE ■ To prevent battery discharge Do not leave the audio system on longer than necessary when the engine is stopped. ■ To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.

  • Page 217: Using The Radio

    3-2. Using the audio system ∗ Using the radio TA mode button Power Volume Station selector Adjusting the frequency Changing the Automatic presetting of program types radio stations AM/FM mode AF mode button buttons Seeking the frequency Setting station presets Manually or pressing “...
  • Page 218 3-2. Using the audio system Automatically Press and hold until you hear a beep. Up to 6 stations are set in order of reception quality. When the settings are finished, 2 beeps will be heard. In the FM1 or FM2 mode, the stations automatically set by the audio sys- tem will be set in the FM3 presets.
  • Page 219 3-2. Using the audio system ■ Traffic information Press TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received. The station returns to the previous one when the traffic infor- mation ends. TA mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received.
  • Page 220 3-2. Using the audio system ■ EON (Enhanced Other Network) system (for traffic announcement function) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.

  • Page 221: Using The Cd Player

    3-2. Using the audio system ∗ Using the CD player Power Volume CD eject Selecting a CD (with changer only) Displays text message Playback Random playback Repeat play Selecting a track, fast-forwarding or reversing Loading CDs Insert a CD. Ejecting CDs Press and remove the CD.
  • Page 222 3-2. Using the audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press and hold “ ∧ ” or “∨” on Selecting a CD (CD player with changer only) To select the desired CD, press (∨) or (∧). Repeat play ■...
  • Page 223 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
  • Page 224 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs or 8 cm (3 in.) CD adapters or Dual Disc. Doing so may damage the CD player and/or the CD insert/eject function. ●...
  • Page 225 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than a CD into the CD slot. ●...

  • Page 226: Playing Back Mp3 And Wma Discs

    3-2. Using the audio system ∗ Playing back MP3 and WMA discs Power Volume CD eject Selecting a CD (with changer only) Selecting a file Playback Displays text message Selecting a folder Random playback Repeat play Selecting a file, fast-forwarding or reversing Loading and ejecting MP3 and WMA discs →P.
  • Page 227 3-2. Using the audio system Selecting files Turn the dial or press “∧” or “∨” on to select the desired file. Fast-forwarding and reversing files To fast-forward or reverse, press and hold “ ∧ ” or “∨” on Repeat play ■...
  • Page 228 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
  • Page 229 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 230 3-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 231 3-2. Using the audio system ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
  • Page 232 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used (→P. 223) ■ CD player precautions (→P. 224)

  • Page 233: Operating An Ipod

    3-2. Using the audio system ∗ Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod After pulling the lid to open, STEP open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
  • Page 234 3-2. Using the audio system Selecting a play mode Press to select iPod menu mode. STEP Turning changes the play mode in the following order: STEP “PLAYLISTS”→“ARTISTS”→“ALBUMS”→“SONGS”→ “PODCASTS”→“GENRES”→“COMPOSERS”→ “AUDIOBOOKS” Press to select the desired play mode. STEP ■ Play mode list First Second Third...
  • Page 235 3-2. Using the audio system ■ Selecting a list Turn to display the first selection list. STEP Press to select the desired item. STEP Pressing the knob changes to the second selection list. Repeat the same procedure to select the desired item. STEP To return to the previous selection list, select “GO BACK”...
  • Page 236 3-2. Using the audio system Repeat play Press (RPT) To cancel, press (RPT) again. Switching the display Press Each time the button is pressed, the display changes in the following order: Elapsed time → Album title → Track title → Artist name Adjusting sound quality and volume balance Press to enter iPod menu mode.
  • Page 237 3-2. Using the audio system ■ iPod problems To resolve most problems encountered when using your iPod, disconnect your iPod from the vehicle iPod connection and reset it. For instructions on how to reset your iPod, refer to your iPod Owner’s Man- ual.
  • Page 238 3-2. Using the audio system CAUTION ■ Caution while driving Do not connect iPod or operate the controls. NOTICE ■ If the lid cannot be fully closed Depending on the size and shape of the iPod that is connected to the sys- tem, the lid may not close fully.

  • Page 239: Operating A Usb Memory

    3-2. Using the audio system ∗ Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory After pulling the lid to open, STEP open the cover and connect a USB memory.
  • Page 240 3-2. Using the audio system Selecting a folder ■ Selecting folders one at a time Press (∨) or (∧) to select the desired folder. ■ Returning to the first folder Press and hold (∨) until you hear a beep. Selecting files Turn or press “∧”...
  • Page 241 3-2. Using the audio system Repeat play ■ Repeating a file Press (RPT) To cancel, press (RPT) again. ■ Repeating all the files in a folder Press and hold until you hear a beep. (RPT) To cancel, press (RPT) again. Switching the display Press Each time the button is pressed, the display changes in the following...
  • Page 242 3-2. Using the audio system ■ USB memory ● Compatible devices USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12 mbps) •...
  • Page 243 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
  • Page 244 3-2. Using the audio system ● MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
  • Page 245 3-2. Using the audio system NOTICE ■ If the lid cannot be fully closed Depending on the size and shape of the USB memory that is connected to the system, the lid may not close fully. In this case, do not forcibly close the lid as this may damage the USB memory or the terminal, etc.

  • Page 246: Optimal Use Of The Audio System

    3-2. Using the audio system ∗ Optimal use of the audio system Displays the current mode Changes the following set- ting • Sound quality and vol- ume balance (→P. 246) The sound quality and bal- ance setting changed to produce the best sound.
  • Page 247 3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Sound qual- Mode Turn to the Turn to the Level ity mode displayed left right Bass* “BAS” -5 to 5 High Treble* “TRE” -5 to 5 Front/rear volume “FAD”...

  • Page 248: Using The Aux Port

    3-2. Using the audio system ∗ Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. After pulling the lid to open, STEP open the cover and connect the portable audio device.

  • Page 249: Using The Steering Wheel Audio Switches

    3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio mode: Selects radio stations CD mode: Selects tracks, files (MP3 and WMA) and discs ®...
  • Page 250 3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time is pressed. → AM→FM1→FM2→FM3→CD mode→CD changer mode* ® →AUX→iPod or USB memory mode→AM Bluetooth audio mode* : If installed with a CD changer : If equipped Adjusting the volume...
  • Page 251 3-2. Using the audio system Selecting a folder (CD player without changer or USB memory) Press to select CD or USB memory mode. STEP Press and hold “∧” or “∨” on until you hear a beep. STEP Selecting a disc in the CD player (CD player with changer only) Press to select the CD mode.

  • Page 252: Audio System

    ® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
  • Page 253 ® 3-3. Using the Bluetooth audio system ■ When transferring ownership of the vehicle Be sure to initialize the system to prevent personal data from being improp- erly accessed. (→P. 282) ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG.

  • Page 254: Using The Bluetooth

    ® 3-3. Using the Bluetooth audio system ® ∗ Using the Bluetooth audio system ■ Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
  • Page 255 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press until “BTA”...

  • Page 256: Audio System

    ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system First menu Second menu Operation detail Registering a portable “Pair Audio” player Selecting a portable “Select Audio” player to be used Changing the registered “Change Name” name of a portable “Setup”...

  • Page 257: Operating A Bluetooth

    ® 3-3. Using the Bluetooth audio system ∗ ® Operating a Bluetooth enabled portable player Power Volume Album selector buttons Selector knob Text button Playback/Pause button Playback button Selecting a track, fast-forwarding or reversing Selecting an album Press (∨) or (∧).
  • Page 258 ® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press and hold “ ∧ ” or “∨” on Switching the display Press Each time is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed time Using the steering wheel audio switches →P.

  • Page 259: Setting Up A Bluetooth ® Enabled Portable Player

    ® 3-3. Using the Bluetooth audio system ∗ ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
  • Page 260 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio” using , and perform the procedure for reg- istering a portable player. (→P. 254) Selecting a portable player to be used Select “Select Audio” using STEP Select the portable player to be used, and select “Confirm”...
  • Page 261 ® 3-3. Using the Bluetooth audio system Changing the registered name of a portable player Select “Change Name” using STEP Select the name of the portable player to be changed using STEP Select “Record Name” using , and say the new name STEP after the beep.
  • Page 262 ® 3-3. Using the Bluetooth audio system Changing the passkey Select “Set Passkey” using STEP Select a 4 to 8-digit number using STEP The number should be input 1 digit at a time. When the entire number to be registered as a passkey has STEP been input, press again.

  • Page 263: Bluetooth ® Audio System Setup

    ® 3-3. Using the Bluetooth audio system ∗ ® Bluetooth audio system setup ■ System setup items and operation procedures →P. 280 ∗ : If equipped...

  • Page 264: Using The Hands-Free Phone System (For Cellular Phone)

    3-4. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system (for cellular phone) features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.

  • Page 265: Using The Hands-Free

    3-4. Using the hands-free phone system (for cellular phone) Title Page Using the hands-free phone system ■ Using the hands-free phone system for the first time P. 267 ■ Menu list of the hands-free phone system Making a phone call ■...
  • Page 266 3-4. Using the hands-free phone system (for cellular phone) ■ Conditions affecting operation The hands-free phone system may not operate normally in the following situ- ations: ● The cellular phone is turned off, or located outside the service area. ● The cellular phone has a low battery.
  • Page 267 3-4. Using the hands-free phone system (for cellular phone) NOTICE ■ To prevent damage to a cellular phone Do not leave a cellular phone in the vehicle. The temperature inside may become high resulting in damage to the phone.

  • Page 268: Using The Hands-Free Phone System (For Cellular Phone)

    3-4. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system (for cellular phone) ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold)
  • Page 269 3-4. Using the hands-free phone system (for cellular phone) ■ Steering wheel Volume The voice guidance volume cannot be adjusted using this button. On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Off-hook switch Turns the hands-free sys- tem on/starts a call Talk switch Turns the voice command...
  • Page 270 3-4. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
  • Page 271 3-4. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Second First menu Third menu Operation detail menu Dialing a number stored in “Callback” the incoming call history memory Dialing a number stored in “Redial”...
  • Page 272 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Security” “Phbk Lock” Locking the phone book “Phbk Unlock” Unlocking the phone book Registering the cellular “Pair Phone” phone to be used Changing a registered name “Change Name”...
  • Page 273 3-4. Using the hands-free phone system (for cellular phone) ■ Automatic volume adjustment When vehicle speed is 80 km/h (50 mph) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 70 km/h (43 mph) or less. ■...

  • Page 274: Making A Phone Call

    3-4. Using the hands-free phone system (for cellular phone) ∗ Making a phone call ■ Making a phone call ● Dialing by inputting a name ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial” ● Dialing a number stored in the incoming history memory “Call back”...
  • Page 275 3-4. Using the hands-free phone system (for cellular phone) Speed dialing Press the off-hook switch. STEP Press the preset button in which the desired number is regis- STEP tered. Press the off-hook switch. STEP When receiving a phone call ■ Answering the phone Press the off-hook switch.
  • Page 276 3-4. Using the hands-free phone system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the off-hook switch and select “Redial” (when using a STEP number stored in the outgoing call history memory) or “Call back”...

  • Page 277: Setting A Cellular Phone

    3-4. Using the hands-free phone system (for cellular phone) ∗ Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below using ●...
  • Page 278 3-4. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used Select “Select Phone” using STEP Select the cellular phone to be used and select “Confirm” STEP using Changing a registered name Select “Change Name” using STEP Select the cellular phone name to be changed using STEP...
  • Page 279 3-4. Using the hands-free phone system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” using causes the list of registered cel- lular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Deleting a cellular phone Select “Delete Phone”...
  • Page 280 3-4. Using the hands-free phone system (for cellular phone) Turning the hands-free phone automatic connection on/off ■ Turning off the automatic connection Select “Hands-free power” using STEP Select “Turn off” using STEP ■ Turning on the automatic connection Select “Hands-free power” using STEP Select “Turn on”...

  • Page 281: Security And System Setup

    3-4. Using the hands-free phone system (for cellular phone) ∗ Security and system setup To enter the menu of each setting, follow the steps below using ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
  • Page 282 3-4. Using the hands-free phone system (for cellular phone) ■ Changing the PIN Select “Set PIN” using STEP Enter the registered PIN using STEP Enter a new PIN using STEP Input the code 1 digit at a time. Locking or unlocking the phone book Select “Phbk Lock”...
  • Page 283 3-4. Using the hands-free phone system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using STEP ® Turn to display the Bluetooth device address and STEP name. Select “Go Back” using to return to “System Setup”. STEP Initialization Select “Initialize”...
  • Page 284 3-4. Using the hands-free phone system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ®...

  • Page 285: Using The Phone Book

    3-4. Using the hands-free phone system (for cellular phone) ∗ Using the phone book To enter the menu of each setting, follow the steps below using ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1.
  • Page 286 3-4. Using the hands-free phone system (for cellular phone) ■ Adding procedure Select “Add Entry” using STEP Use one of the following methods to input a telephone num- STEP ber: Transferring data from the cellular phone STEP2-1 Select “By Phone” and then “Confirm” using STEP2-2 Transfer the data from the cellular phone.
  • Page 287 3-4. Using the hands-free phone system (for cellular phone) Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History” using STEP2-2 Select “Outgoing” or “Incoming” using STEP2-3 Select the desired data using Select “Record Name” using , and say the desired STEP name after the beep.
  • Page 288 3-4. Using the hands-free phone system (for cellular phone) Setting speed dials Select “Speed Dial” using STEP Select the desired data using STEP Select the desired preset button, and register the data into STEP speed dial by either of the following methods: a.
  • Page 289 3-4. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” using STEP Select the desired data to be deleted, and select “Confirm” STEP using Deleting speed dials Select “Del Spd Dial” using STEP Press the preset button in which the desired speed dial is reg- STEP istered, and select “Confirm”...

  • Page 290: 3-5. Using The Interior Lights

    3-5. Using the interior lights Interior lights list Interior light (→P. 290) Personal lights (→P. 290) Engine switch light (vehicles without a smart entry & start sys- tem) ■ Illuminated entry system Vehicles without a smart entry & start system When the interior light switch is in the “DOOR”...

  • Page 291: Interior Light

    “DOOR” position, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features→P. 437) Interior light...

  • Page 292: Using The Storage Features List Of Storage Features

    3-6. Using the storage features List of storage features Glove box Auxiliary boxes Cup holders Console box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...

  • Page 293: Glove Box

    3-6. Using the storage features Glove box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking.

  • Page 294: Console Box

    3-6. Using the storage features Console box Console box Type A Lift the lid while pulling the lever. Type B Lift the lid while pulling the lever. Lift the lid and tray. Lift the lid. Pull the tray up to open the box.

  • Page 295: Cup Holders

    3-6. Using the storage features Console box and cup holders ■ When using the console box lid as an armrest (type B only) If necessary, the console box lid can slide forward. Pull the lid forward by grasping the front of the lid. CAUTION ■...
  • Page 296 3-6. Using the storage features Cup holders Rear Pull the armrest down. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.

  • Page 297: Auxiliary Boxes

    3-6. Using the storage features Auxiliary boxes Auxiliary boxes Type A Pull up the lever. Type B Push the lid. Type C Pull up the lever.
  • Page 298 3-6. Using the storage features Auxiliary boxes CAUTION ■ Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. ■ Items unsuitable for storing (type B only) Do not store items heavier than 0.2 kg (0.4 lb.). Doing so may cause the auxiliary box to open and the item inside may fall out, resulting in an accident.

  • Page 299: Other Interior Features Sun Visors

    3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.

  • Page 300: Vanity Mirrors

    3-7. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened.

  • Page 301: Ashtrays

    3-7. Other interior features Ashtrays Portable The ashtray can be installed in a cup holder. (→P. 294) Rear Pull the lid to open. Pull the ashtray to remove. CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident.

  • Page 302: Cigarette Lighter

    3-7. Other interior features Cigarette lighter Pull the lid to open, and push the cigarette lighter down. The cigarette lighter will pop up when it is ready for use. ■ The cigarette lighter can be used when Vehicles without a smart entry & start system The engine switch is in the “ACC”...

  • Page 303: Armrest

    3-7. Other interior features Armrest Pull the armrest down for use. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest.

  • Page 304: Floor Mat

    When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...

  • Page 305: Cargo Hooks

    3-7. Other interior features Cargo hooks Cargo hooks are provided for securing loose items. CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their positions when they are not in use.

  • Page 306: Maintenance And Care

    Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..306 Cleaning and protecting the vehicle interior ..310 4-2. Maintenance Maintenance requirements....313 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 315 Hood ......... 318 Positioning a floor jack..320 Engine compartment..

  • Page 307: Maintenance And Care Cleaning And Protecting The Vehicle Exterior

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 308 4-1. Maintenance and care ■ Aluminum wheels (if equipped) ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
  • Page 309 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 310 4-1. Maintenance and care NOTICE ■ When using an automatic car wash (vehicles with rain-sensing wind- shield wipers) Set the wiper switch to “OFF”. If the wiper switch is in “AUTO”, the wipers may operate and the wiper blades may be damaged. ■...

  • Page 311: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 312 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 313 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...

  • Page 314: 4-2. Maintenance

    Warranty Service. ■ Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for ser- vice. Toyota technicians are well-trained specialists. And they are receiving the latest service information through technical bulletins, service tips, and in- dealership training programs.

  • Page 315: 4-2. Maintenance

    ● Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. CAUTION ■...

  • Page 316: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

    • Baking soda Battery condition (→P. 330) • Grease • Conventional wrench (for terminal clamp bolts) • Toyota Super Long Life Coolant or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine coolant level (→P.
  • Page 317 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 318 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. ■...

  • Page 319: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Push the auxiliary catch lever STEP to the left and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the...
  • Page 320 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...

  • Page 321: Positioning A Floor Jack

    4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear...
  • Page 322 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.

  • Page 323: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (→P. 333) Battery (→P. 330) Engine coolant reservoir Fuse box (→P. 349) (→P. 328) Electric cooling fan Engine oil filler cap Condenser (→P. 329) (→P. 325) Radiator (→P. 329) Engine oil level dipstick (→P.
  • Page 324 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover Battery cover ■ Installing the clips...
  • Page 325 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, STEP wait more than five minutes for the oil to drain back into the bottom of the engine.
  • Page 326 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 327 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 328 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...

  • Page 329: Engine Coolant

    If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, engine coolant filler cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
  • Page 330 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 331 4-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Checking battery fluid Check that the level is between the upper line and the lower line.
  • Page 332 Open and close any of the doors. STEP Start the engine. (If the engine does not start first time, repeat STEP the procedure.) If the engine will not start even after multiple attempts at the above method, contact your Toyota dealer.
  • Page 333 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: ●...
  • Page 334 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. ■ When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
  • Page 335 4-3. Do-it-yourself maintenance CAUTION ■ When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■...

  • Page 336: Tires

    ■ Tire rotation Vehicles with aluminum wheel tires Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate your Front tires approximately every 10000 km (6000 miles).
  • Page 337 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Tire life Any tire over 6 years old must be checked by a qualified technician even if they have seldom or never been used or damage is not obvious.
  • Page 338 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).

  • Page 339: Tire Inflation Pressure

    Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 340 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...

  • Page 341: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
  • Page 342 4-3. Do-it-yourself maintenance CAUTION ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.

  • Page 343: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the “ENGINE START STOP” switch or the engine STEP switch OFF. Open the glove box. Slide off STEP the damper.
  • Page 344 2 minutes at 500 kPa (5.0 kgf/cm or bar, 72 psi). If it is not available, have the filter cleaned by your Toyota dealer. ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule.
  • Page 345 4-3. Do-it-yourself maintenance NOTICE ■ To prevent damage to the system ● When using the air conditioning system, make sure that a filter is always installed. ● When cleaning the filter, do not clean the filter with water.

  • Page 346: Key Battery

    4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
  • Page 347 4-3. Do-it-yourself maintenance Remove the depleted battery. STEP Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles without a smart entry & start system) Remove the cover. STEP Remove the module. STEP...
  • Page 348 Use a CR1632 (vehicles with a smart entry & start system), or CR2016 (vehicles without a smart entry & start system) lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer.
  • Page 349 4-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...

  • Page 350: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch or the engine STEP switch OFF.
  • Page 351 4-3. Do-it-yourself maintenance 2. Remove the lid. Type B 1. Open the glove box. Slide off the damper. 2. Push in each side of the glove box to disconnect the claws. After a system failure, see “Fuse layout and amperage rat- STEP ings”...
  • Page 352 4-3. Do-it-yourself maintenance Remove the fuse with the pull- STEP out tool. Check if the fuse has blown. STEP Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
  • Page 353 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer.

  • Page 354: Engine Compartment

    4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit H-LP CLN 30 A Headlight cleaner RDI FAN 40 A Electric cooling fan Anti-lock brake system, vehicle sta- ABS NO. 3 30 A bility control Anti-lock brake system, vehicle sta- ABS NO.
  • Page 355 4-3. Do-it-yourself maintenance Fuse Ampere Circuit P-SYSTEM 30 A No circuit 50 A EFI MAIN, HORN, IG2 H-LP LH LO, H-LP RH LO, H-LP H-LP MAIN 50 A LH HI, H-LP RH HI 50 A No circuit SPARE 10 A Spare fuse SPARE 30 A...
  • Page 356 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ IGT/INJ 15 A sequential multiport fuel injection system, starting system Multiport fuel injection system/ EFI MAIN 20 A sequential multiport fuel injection system, EFI NO. 1, EFI NO. 2 HORN 10 A Horn Multiport fuel injection system/...
  • Page 357 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 10 A H-LP LH LO Left-hand headlight (low beam) 15 A : Vehicles without discharge headlights (low beam) : Vehicles with discharge headlights (low beam)
  • Page 358 4-3. Do-it-yourself maintenance ■ Instrument panel (type A) Fuse Ampere Circuit Front position lights, tail lights, license plate lights, front fog lights, manual headlight leveling dial, TAIL 10 A multiport fuel injection system/ sequential multiport fuel injection system, instrument cluster lights Switch illumination, instrument PANEL 7.5 A...
  • Page 359 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Steering lock system, SRS airbag system, multiport fuel injection sys- tem/sequential multiport fuel injec- 7.5 A tion system, smart entry & start system, charging system, starting system METER 7.5 A Gauge and meters SEAT HTR 15 A No circuit Air conditioning system, rear win-...
  • Page 360 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Stop lights, high mounted stop- light, anti-lock brake system, main body ECU, multiport fuel injection STOP 10 A system/sequential multiport fuel injection system, shift lock control system DOOR 25 A Power door lock system ACC-B 25 A CIG, ACC...
  • Page 361 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.

  • Page 362: Light Bulbs

    You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 363 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal light Back-up light Stop/tail light License plate lights Replacing light bulbs ■ Headlight low beams (halogen bulbs) Turn the bulb base counterclock- STEP wise. Pull the bulb out while pressing STEP the lock release of the connector.
  • Page 364 4-3. Do-it-yourself maintenance ■ Headlight high beams Turn the bulb base counterclock- STEP wise. Pull the bulb out while pressing STEP the lock release of the connector. ■ Front fog lights (if equipped) Remove the fender liner bolts STEP and a clip.
  • Page 365 4-3. Do-it-yourself maintenance Remove the fender liner. STEP Unplug connector while STEP depressing the lock release. Turn the bulb counterclockwise. STEP ■ Front position lights Turn the bulb base counterclock- STEP wise.
  • Page 366 4-3. Do-it-yourself maintenance Remove the light bulb. STEP ■ Front turn signal lights Turn the steering wheel away from the side being worked on. STEP This will move the tire to provide more room. Remove the fender liner clips. STEP Remove the fender liner and turn STEP the bulb base counterclockwise.
  • Page 367 4-3. Do-it-yourself maintenance Remove the light bulb. STEP ■ Stop/tail lights and rear turn signal lights Open the trunk lid and remove STEP the cover. Turn the bulb base counterclock- STEP wise. Stop/tail light Rear turn signal light Remove the light bulb. STEP...
  • Page 368 4-3. Do-it-yourself maintenance ■ Back-up light Open the trunk lid and remove STEP the cover. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
  • Page 369 Remove the light bulb. STEP ■ Lights other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (discharge bulb) ● Side turn signal lights ● High mounted stoplight...
  • Page 370 LED high mounted stoplight and side turn signal lights The high mounted stoplight and side turn signal lights consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
  • Page 371 4-3. Do-it-yourself maintenance ■ Installing the fender liner clip Type A Install the clip. Type B Install the clip.
  • Page 372 Doing so could result in electric shock and serious injury or death. ■ Discharge headlights (if equipped) ● Contact your Toyota dealer before replacing discharge headlights (includ- ing light bulbs). ● Do not touch the high-intensity discharge headlight’s high voltage socket when the headlights are turned on.
  • Page 373 4-3. Do-it-yourself maintenance...

  • Page 374: When Trouble Arises

    When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers..374 If a warning light turns If your vehicle needs to on or a warning buzzer be towed ......375 sounds......384 If you think something If a warning message is is wrong ......

  • Page 375: Essential Information Emergency Flashers

    5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.

  • Page 376: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer such as or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 377 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard, surfaced roads for short distances at low speeds.
  • Page 378 5-1. Essential information CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
  • Page 379 5-1. Essential information Insert the towing eyelet into the STEP hole and tighten partially by hand. Tighten down the towing eyelet STEP securely using a wheel nut wrench. ■ Location of the emergency towing eyelet →P. 398 CAUTION ■ Installing towing eyelets to the vehicle Make sure that towing eyelets are installed securely.
  • Page 380 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck from the front Release the parking brake. NOTICE ■...
  • Page 381 5-1. Essential information Towing with a wheel lift-type truck from the rear Vehicles with an automatic trans- mission: Use a towing dolly under the front wheels. Vehicles with a manual transmis- sion: We recommend to use a towing dolly under the front wheels.
  • Page 382 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged.

  • Page 383: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 384: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an airbag inflates upon collision, the fuel pump shut off system stops supplying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.

  • Page 385: If A Warning Light Turns

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* Indicates the following: •...
  • Page 386 Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system.

  • Page 387: System

    Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
  • Page 388 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light (non-Optitron type Check that all doors and a meters) trunk are closed.
  • Page 389 If the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible. ■...
  • Page 390 5-2. Steps to take in an emergency ■ Electric power steering warning light (warning buzzer) The electric power steering warning light may come on and the warning buzzer may sound when the voltage is low or the voltage drops. CAUTION ■...

  • Page 391: If A Warning Message Is Displayed

    Multi-information display If any of the warning lights turns on again after performing the fol- lowing actions, contact your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem.
  • Page 392 Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates an abnormal engine oil pressure.
  • Page 393 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning message Details Indicates a malfunction in the steering lock sys- tem.
  • Page 394 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the TRC and VSC. A buzzer also sounds. (If equipped) Indicates a malfunction in the EPS. A buzzer also sounds.
  • Page 395 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning message Details Correction procedure Indicates that one or more of the side Make sure that all of the doors is not fully side doors are closed.

  • Page 396: Start System

    5-2. Steps to take in an emergency Follow the correction procedures. (vehicles with a smart entry & start system) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Correction Interior Exterior Warning message Details procedure buzzer...
  • Page 397 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details procedure buzzer buzzer Indicates that the driver’s door has been opened or closed with the Turn the shift lever in P, “ENGINE the “ENGINE START STOP” 3 times START STOP”...
  • Page 398 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details procedure buzzer buzzer Indicates that a door has been opened or Press the closed and the “ENGINE “ENGINE START STOP”  START STOP” Once switch while switch has been applying the turned twice to brakes.

  • Page 399: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 400 5-2. Steps to take in an emergency Taking out the jack Remove the auxiliary box. STEP Loosen STEP Tighten...
  • Page 401 5-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. STEP Vehicles with 195/65R15 spare STEP tire only: Remove the spare wheel cushion. Loosen the center fastener that STEP secures the spare tire.
  • Page 402 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel chock Flat tire positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left-...
  • Page 403 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground.
  • Page 404 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 405 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 103 N•m (10.5 kgf•m, 76 ft•lbf) Vehicles with a steel wheel: STEP Reinstall the wheel ornament.
  • Page 406 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
  • Page 407 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury. • • Have the wheel nuts tightened with a torque wrench to 103 N m (10.5 kgf •...

  • Page 408: If The Engine Will Not Start

    5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 122, 126) or releasing the steering lock (→P. 124, 127), confirm the following points. ■...
  • Page 409 ● There may be a malfunction in the steering lock system (vehi- cles with a smart entry & start system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart entry & start...

  • Page 410: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.

  • Page 411: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart entry & start system, bring the other key and the key number stamped on the key number plate.

  • Page 412: If The Electronic Key Does Not Operate Properly

    5-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with a smart entry & start system) If communication between the electronic key and vehicle is inter- rupted (→P. 27) or the electronic key cannot be used because the battery is depleted, the smart entry &...
  • Page 413 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Shift the shift lever to P and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch.

  • Page 414: If The Battery Is Discharged

    You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Remove the battery cover. (→P. 323) STEP Remove the engine cover.
  • Page 415 5-2. Steps to take in an emergency STEP Connecting the jumper cables Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle Connect the jumper cable to ground on your vehicle as shown in the illustration.
  • Page 416 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Avoiding a discharged battery ●...
  • Page 417 5-2. Steps to take in an emergency CAUTION ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery. ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

  • Page 418: If Your Vehicle Overheats

    (Optitron type meters) or the indicator needle of the engine coolant temperature gauge (non-Optitron type meters) lowers and then stop the engine. If the fan is not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP STEP...
  • Page 419 Water can be used in an emer- gency if engine coolant is (→ unavailable. P. 431 Have the vehicle checked at the nearest your Toyota dealer. ■ Overheating If you observe the following, your vehicle may be overheating. ● With Optitron type meters: The top segments of the engine coolant tem- perature gauge are flashing.
  • Page 420 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.

  • Page 421: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift STEP lever in P (automatic transmission) or N (manual transmis- sion).
  • Page 422 5-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the wheels and do not rev the engine. ● If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.

  • Page 423: If Your Vehicle Has To Be Stopped In An Emergency

    5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
  • Page 424 5-2. Steps to take in an emergency Vehicles with a smart entry & STEP start system: Stop the engine by pressing and holding the “ENGINE START STOP” switch for 3 consecutive sec- onds or more. Press and hold for 3 seconds or more Stop the vehicle in a safe place by the road.
  • Page 425 5-2. Steps to take in an emergency...

  • Page 426: Vehicle Specifications

    Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..426 Fuel information ....436 6-2. Customization Customizable features ..437...

  • Page 427: Specifications Maintenance Data (Fuel, Oil Level, Etc.)

    The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the right-hand front seat.
  • Page 428 6-1. Specifications This number is also stamped on the top left of the instrument panel. This number is also on the man- ufacturer’s label on the left-hand side center pillar. ■ Engine number The engine number is stamped on the engine block as shown.
  • Page 429 6-1. Specifications Engine Model 2ZR-FE, 3ZR-FE Type 4-cylinder in line, 4-cycle, gasoline 2ZR-FE engine 80.5 × 88.3 mm (3.17 × 3.48 in.) Bore and stroke 3ZR-FE engine 80.5 × 97.6 mm (3.17 × 3.84 in.) 2ZR-FE engine 1798 cm (109.7 cu.in.) Displacement 3ZR-FE engine 1987 cm...
  • Page 430 Without filter 3.9 L (4.1 qt., 3.4 Imp. qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
  • Page 431 6-1. Specifications The 0W portion of the oil viscosity rating indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. The 20 in 0W-20 indicates the oil viscosity when the oil is at its operating temperature.

  • Page 432: Cooling System

    (Reference) Vehicles with a manual transmission 5.6 L (5.9 qt., 4.9 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.

  • Page 433: Manual Transaxle

    NOTICE ■ Manual transaxle gear oil type Using manual transmission gear oil other than “TOYOTA Genuine Manual Transmission Gear Oil LV API GL-4 SAE 75W” may cause occurrence of idle ratting noise and bad fuel consumption. Automatic transaxle 2ZR-FE engine 6.5 L (6.9 qt., 5.7 Imp.
  • Page 434 6-1. Specifications Clutch 5  15 mm (0.2  0.6 in.) Pedal free play Fluid type SAE J1703 or FMVSS No.116 DOT 3 Brakes Vehicles without VSC 64 mm (2.52 in.) Min. Pedal clearance Vehicles with VSC 69 mm (2.72 in.) Min. 1 ...

  • Page 435: Inflation Pressure

    6-1. Specifications Tires and wheels Tire size 195/65R15 91H, 205/55R16 91V Front Rear Vehicle kPa (kgf/cm kPa (kgf/cm speed or bar, psi) or bar, psi) Tire inflation pressure More than (Recommended cold tire 160 km/h 250 (2.5, 36) 250 (2.5, 36) inflation pressure)* (99 mph) 160 km/h...
  • Page 436 6-1. Specifications Light bulbs Light Bulbs Type Headlights Low beam (halogen bulbs) Low beam (discharge bulbs) High beam Front fog lights (if equipped) Front position lights Exterior Front turn signal lights Stop/tail lights 21/5 Rear turn signal lights Back-up light License plate lights Vanity lights Interior light...

  • Page 437: Fuel Information

    Research Octane Number of 91 or higher. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■ If your engine knocks ●...

  • Page 438: Customization Customizable Features

    Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 439 6-2. Customization Customized Item Function Default setting setting Trunk unlocking func- tion (vehicles with a smart entry & start sys- Wireless tem) remote con- trol Trunk unlocking opera- Push twice → P. 33) tion (vehicles with a Push and hold smart entry &...

  • Page 440: Index

    Index Abbreviation list .......440 Alphabetical index....441 What to do if......449...

  • Page 441: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System DISP Display Electronic Control Unit Emergency Locking Retractor Electric Power Steering Light Emitting Diode Supplemental Restraint System Traction Control Vehicle Identification Number Vehicle Stability Control...

  • Page 442: Alphabetical Index

    Alphabetical index Alphabetical index A/C........202, 208 Audio system ABS ........... 181 Antenna ........ 219 Air conditioning filter ....342 Audio input......247 Air conditioning system AUX port ....... 247 CD player......220 Air conditioning filter....342 Automatic air conditioning iPod........
  • Page 443 Alphabetical index Brake assist......181 Child safety Break-in tips ......114 Airbag precautions....86 Battery precautions..332, 416 Child restraint system ..... 91 Care Child-protectors ...... 37 Exterior........306 How your child should wear Interior........310 the seat belt......50 Seat belts ......
  • Page 444 Alphabetical index Doors If your vehicle becomes Door lock......... 36 stuck ........420 Door windows ......59 If your vehicle has to be Double locking system ....72 stopped in an emergency ... 422 If your vehicle needs to be Side mirrors......57 Driver's seat belt reminder towed........
  • Page 445 Alphabetical index Floor mat ........303 Hands-free phone system Fluid (for cellular phone)....263 Washer........333 Hazard lights Fog lights Switch ........374 Head restraints Replacing light bulbs..... 361 Switch ........163 Adjusting ........ 46 Wattage......... 435 Headlight cleaner..... 169 Front fog lights Headlights Replacing light bulbs.....
  • Page 446 Alphabetical index Keys Maintenance Electronic key......20 Do-it-yourself maintenance... 315 Engine switch....122, 126 Maintenance data ....426 If you lose your keys ..... 410 Maintenance requirements ... 313 Manual air conditioning If your electronic key battery is discharged ..411 system........
  • Page 447 Alphabetical index Parking brake ......134 Seats Personal lights Adjustment......43 Switch ........290 Adjustment precautions ..43 Wattage......... 435 Child seats/child restraint system installation ....99 Power windows......59 Cleaning........ 310 Head restraint ......46 Radiator ........329 Properly sitting in the seat ..77 Radio.........
  • Page 448 Alphabetical index Storage precautions ....188 Tools ......... 398 Stuck Towing If your vehicle becomes Emergency towing ....376 stuck ........420 Trailer towing ......192 Traction control ....... 181 Sun visors ........ 298 Sunshade TRC ........... 181 Roof ........63 Trip information ....
  • Page 449 Alphabetical index Warning lights Warning messages Anti-lock brake system..386 Anti-lock brake system..392 Automatic headlight leveling Brake assist system....392 system ........ 386 Brake system ......390 Charging system....391 Brake assist system ....386 Brake system ......384 Electric power steering Charging system ....

  • Page 450: What To Do If

    What to do if... What to do if... If you have a flat tire A tire punctures P. 398 If the engine will not start P. 407 P. 70 Engine immobilizer system The engine does not start If the battery is discharged P.
  • Page 451 What to do if... If a warning light turns on or a A warning light or indicator light P. 384 warning buzzer sounds... comes on Vehicles with Optitron type meters Vehicles with non-Optitron type meters...
  • Page 452 What to do if... ■Warning lights Brake system warning Slip indicator light light P. 384 P. 386 Charging system warn- Cruise control indicator ing light light P. 385 P. 386 Low engine oil pressure Automatic headlight leveling sys- warning light tem warning light P.

  • Page 453: Gas Station Information

    Engine oil capacity With filter 4.2 (4.4, 3.7) (Drain and refill  reference) Without filter 3.9 (4.1, 3.4) Toyota Genuine Motor Oil or equivalent Oil grade: P. 429 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving” or ILSAC...

Table of Contents

Save PDF
