Status Indicator Lights; 5-Step Charging Process Indicator Lights - Keyline Mini-Pro Instructions Manual

for reference about the indicator lights and charge cycles.

Status Indicator Lights:

Charger State
Something is wrong with the power input
(check your connections and the plug)
Something is wrong with the charger,
battery or an improper connection.
Normal
--- Lamp is lit with steady light
--- Lamp is lit with steady light

5-Step charging process Indicator Lights

Charging Stage
Step1 DESULFATION
Step 2 BULK
Step 3 ABSORPTION
Step 4 ANALYSE (This
step is 3 minutes)
Step 5 FLOAT
--- Lamp is lit with steady light
--- Lamp is lit with steady light
Stop charging
To stop charging at any time, disconnect the plug from the wall socket.
If the charger is left connected to the battery while not plugged into the wall it will not consume
the battery power.
Resume charging
Sometimes, charging can be interrupted for numerous external reasons (power outage,
mistakenly unplugged, lost battery connection, etc...) The charger will restart a new charging
cycle when the power supply is restored.
Complete charging
When the battery is fully charged, the charging stage lamps are lit.
If the voltage drops below 13.6V, the charger will automatically restart a new charging cycle.
The following chart explains indicator light operation:
Power Lamp Error Lamp
--- Lamp is lit with flashing light
--- Lamp is off
Increasing Voltage to
7V-11.5V
11.5V-14.4V
14.4V
The voltage is lower than 12V
The voltage is higher than 12V
13.6V (The charging is complete)
--- Lamp is lit with flashing light
--- Lamp is off
Charging stage Lamp
Charging stage Lamp
0.2s on, 0.2s off
0.5s on, 0.5s off
0.5s on, 0.5s off
0.5s on, 0.5s off
0.5s on, 0.5s off
/
/
Error
Lamp
