Keyline Mini-Pro Automatic Battery Charger Instructions
12V 110-240VAC - 1.25A
Features:
MCU-controlled, multiple charging stages
5-Step charging process
LED charge steps display
Error warning
Surge protection
Battery reverse polarity protection
Over-voltage protection
Over-current protection
Short-circuit protection
IP65 (dust and liquid resistant)
The KeyLine Chargers Mini-Pro line has the following special features:
Reverse Polarity Protection:
determine if the polarity is correct or not and will never short circuit, cause a spark or harm
the charger or battery as a result of reversing the polarity of the connectors.
Short Circuit Protection
circuit connection directly across its DC outlet terminals indefinitely without damaging
charger, equipment and without risk of shock, spark or excessive heat.
IP65 Weather Proof Rating:
at this price point. This means that it has strong resistance to liquid and dust ingress. That means you
can leave it in weather exposed environments and it will still perform beautifully. It is not intended
to be submerged in liquid.
Surge Protection:
between the power source and the battery being charged so that a surge will not damage batteries or
equipment attached to the battery.
Over Voltage Protection:
to ensure that it will not be overcharged and damage the battery. This is really the reason why most
The charger can electronically and automatically
: The battery charger is protected and can sustain a short
The Mini-Pro charger line is a sealed unit unlike many others
The charger has an internal surge protection that will sustain a power surge
This charger is smart and constantly monitors the battery's voltage
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Keyline Mini-Pro
- Page 1 IP65 Weather Proof Rating: The Mini-Pro charger line is a sealed unit unlike many others at this price point. This means that it has strong resistance to liquid and dust ingress. That means you can leave it in weather exposed environments and it will still perform beautifully.
- Page 2 KeyLine chargers uses quick connect universal SAE cords to accept other KeyLine accessories and adapters; we made it universal so that you can use accessories that you may own already and still be able to use this great charger. Quick Connect plugs are also great so that you can leave your battery terminals connected and then connect and disconnect the charger with ease and quickness.
- Page 3 Table 1 Length of cord (feet) AWG (gauge) of cord 7) Do not operate charger with damaged cords or accessories – replace the cord, charger or accessory immediately. 8) Do not operate charger if it has been visually damaged or if you can hear that something has come loose inside the charger.
- Page 4 The charger output power is completely determined by the condition and state of the battery being charged. KeyLine Mini-Pro chargers have 3 LED status lights to (1 red, 2 green) that indicate the status of the charger and the battery it is charging.
- Page 5 When you attempt to charge a low or dead battery with low voltage (9 volts or less), the Mini-Pro will provide full charge power to the battery However, we make no guarantee that the recharge will be successful. There is a strong likelihood that the battery has already been damaged and needs to be replaced instead of recharged (remember this unit is intended for maintaining batteries).
- Page 6 for reference about the indicator lights and charge cycles. Status Indicator Lights: The following chart explains indicator light operation: Charger State Power Lamp Error Lamp Charging stage Lamp Something is wrong with the power input (check your connections and the plug) Something is wrong with the charger, battery or an improper connection.
- Page 7 Trouble Shooting Checklist None of the charger lights are on after connecting AC power (plugging into receptacle): Check that the plug is securely connected to the receptacle and if so, then verify that the AC outlet is functioning correctly by plugging in another appliance or using a voltmeter to measure power.
- Page 8 KeyLine Chargers makes no specific claims nor does it make or imply any specific guarantee or warranty with respect to either the physical configuration or performance of any of the battery chargers listed herein or otherwise, including suitability or compatibility for purpose or merchantability.
