Summary of Contents for MultiQ 42P2
- Page 1 42P2 TINSE2219Y1----...
-
Page 2: Table Of Contents
Table of Contents 1. Cautions and Warnings ..........2 2. Product Safety Precautions ......... 3 3. Introduction ..............4 4. Overview ..............5 4-1. Unpacking ............. 5 4-2. Front/Lateral Panel Controls ......... 6 4-3. Rear Panel Controls ..........7 4-4. Remote Control Button .......... 8 5. -
Page 3: Cautions And Warnings
1. Cautions and Warnings CAUTION !! RISK OF ELECTRIC SHOCK DO NOT OPEN C AUT ION: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified personnel. WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS MONITOR TO RAIN OR MOISTURE. -
Page 4: Product Safety Precautions
2. Product Safety Precautions Follow all warnings and instructions marked on the product. Do not use this product near water - e.g. near a bathtub, washbasin, swimming pool, kitchen, laundry tub or in a wet basement. This monitor should be installed on a solid horizontal base. ... -
Page 5: Introduction
3. Introduction Welcome to enjoy the fantastic world of LCD-monitors. This new technology will bring you a whole new feeling for your “monitor”. We show here some of the major advantages of the LCD monitor. You will most certainly find some other advan- tages when you use it. -
Page 6: Overview
4. Overview This chapter will guide you through the correct installation procedures of your LCD monitor. 4-1. Unpacking After you unpack your LCD Monitor, please make sure that the following items are included in the carton and in good condition. If you find that any of these items are damaged or missing, please contact your dealer immediately. -
Page 7: Front/Lateral Panel Controls
4. Overview 4-2. Front/Lateral Panel Controls 1. POWER button Turns power on/off from standby mode, there is a wait period between on/off cycles. 2. Adjust buttons Use these buttons to adjust value of selected item or change setting On Screen Display menu. 3. -
Page 8: Rear Panel Controls
4. Overview 4-3. Rear Panel Controls The following picture provides the connection outline. 1. HDMI input Connects to the digital video signals. 2. VGA input Connects to VGA input of computer 3. SERVICE USB port is provided for after service/engineering use ONLY. -
Page 9: Remote Control Button
4. Overview 4-4. Remote Control Button 1. Standby power on/off Push this button to turn on the display from Standby mode. Push it again to turn off to Standby mode. 2. SEL Use SEL button up or down to navigate through the on screen display menu. -
Page 10: Hardware Installation
5. Hardware Installation 5-1. Installation 1. Power off both the Computer/equipment and Monitor before making any connections. 2. Install monitor on a solid surface such as a VESA metal. 3. Connect the power cable to the back of the LCD monitor. 4. -
Page 11: Video Input Pin Assignment
5. Hardware Installation 5-2. Video Input Pin Assignment This section describes the pin assignments of the D-sub and HDMI connector. 1. 15 Pin D-sub Connector Pin No. Signal Connector Pin No. Signal Connector Red Video Signal Green Video Signal Ground Blue Video Signal DDC data Ground... -
Page 12: Applicable Video Timing For Video Input
5. Hardware Installation 5-3. Applicable Video Timing for Video Input The following table lists the supported display quality modes that the LCD monitor provides. If other video modes are used, the monitor will stop working or display unsatisfactory picture quality. MQ42 series model Horizontal Vertical... - Page 13 5. Hardware Installation Horizontal Vertical Nominal Refresh Pixel Nominal Nominal Mode Resolution Rate Clock Frequency Frequency (Hz) (MHz) +/- 0.5 kHz +/- 1 Hz 1360*768 47.712 60.015 85.500 720*480i 15.734 59.940 27.000 720*576i 15.625 50.000 13.500 720*480P 31.469 59.940 27.000 720*576P 31.250 50.000...
-
Page 14: Screen Adjustment
6. Screen Adjustment 6-1. Screen Adjustment Operation Procedure Using lateral panel or remote control to change INPUT sources. 1). Press the INPUT key on the panel or the remote control. 2). Press the INPUT key will cycle the display through all available input signal sources. - Page 15 6. Screen Adjustment The on-screen status display shows detailed information regarding the operational status of the display. The status display automatically appears whenever there is a change in the status of the display such as input change. The status display will automatically disappear after a timeout period. 14 - English...
-
Page 16: Video Input Sources
6. Screen Adjustment 6-2. Video Input Sources The following OSD main menu shows the OSD functions that are supported by different video input sources. Please make sure which video source you are using, then select the correct func- tions in the MENU display. Note: 1). -
Page 17: Osd Adjusting And Controls
6. Screen Adjustment 6-3. OSD Adjusting and Controls Explanation of each available picture control settings are listed in the below: PICTURE MODE There are four preset picture modes that you can choose from to optimize the video picture according to the type of programming you are watching: (1) USER (2) STANDARD (3) CINEMA (4) VIVID. - Page 18 6. Screen Adjustment FORMAT Use to change various screen with modes. There are two modes to choose from: (1) 16:9 (2) 4:3 When the input source is HDMI and the resolution is one of below table, there are three modes to choose from: (1) 16:9 (DVD), (2) 16:9 (PC), (3) 4:3 720x480I@60Hz 1920x1080I@60Hz 720x480P@60Hz...
-
Page 19: Advanced Functions
6. Screen Adjustment 6-4. Advanced Functions The “SYSTEM” menu provides the user with some functions regarding the menu language, menu timeout, menu background, backlight and software version. Figure 6-2. OSD-SYSTEM Menu MENU LANGUAGE Only English is available. MENU TIMEOUT It is used to set the timeout of the OSD menu. -
Page 20: Troubleshooting Tips
7. Troubleshooting Tips In the event that you experience trouble with your Monitor, check the following items before contacting the dealer from whom the Monitor was purchased. The most common problems usually involve an incorrect connection from the Graphics card or equipment to the Monitor. Do not exceed the maximum refresh rate recommended for the monitor. -
Page 21: Specification
8. Specification MQ42 series model LCD panel type 42.0” Resolution 1920 x1080 max. Pixel dimension 0.4845 mm (H) x 0.4845 mm (V) LCD monitor colour 16.7 M max. Manual control keys POWER, MENU, INPUT, ADJ +, ADJ -, SEL +, SEL -. H: + 89... -
Page 22: Appendix
9. Appendix Safety Guidelines CAUTION: The socket-outlet should be installed near the equipment and should be easily accessible. CAUTION: Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for the individual country. Some examples are listed below: USA………...UL Switzerland…….SEV... -
Page 23: Ce Conformity For Europe
9. Appendix FOR EUROPEAN COUNTRIES In Europe you must use a cord set which is appropriate for the receptacles in your country. The cord set is HAR-Certified, and a special mark that will appear on the outer sheath, or on the insulation of one of the inner conductors. AC PLUG CORD PRECAUTIONS FOR THE UNITED KINGDOM For your safety please read the following text carefully. -
Page 24: Safety Instructions
Protective earth (ground) Attention, consult ACCOMPANYING DOCUMENTS Dangerous voltage Disposal The lamp in this product contains mercury. For disposal, return to MultiQ or follow local governing ordinances or hospital procedure. Cleaning MAKE SURE THE LCD DISPLAY IS TURNED OFF.
