Please read this
document carefully
before installation!
ADSL Loop Extender Power Supply
AEC-RACK
AEC-C2P & AEC-C1PL
Installation Manual
Version: 6.1
Widearea Telecommunication Technology Co., Ltd
nd
rd
Add: 2
,3
East Round Longtan Industry Garden 10#,Chengdu, Sichuan, China
Tel: (86)28 84207501 (86)28 84207506
Fax: (86)28 84209696
E-mail:
master@widearea.com.cn
Web Site: http://www.widearea.com.cn
Advertisement
Related Manuals for Widearea AEC-C1PL
Summary of Contents for Widearea AEC-C1PL
-
Page 1: Before Installation
ADSL Loop Extender Power Supply AEC-RACK AEC-C2P & AEC-C1PL Installation Manual Version: 6.1 Widearea Telecommunication Technology Co., Ltd Add: 2 East Round Longtan Industry Garden 10#,Chengdu, Sichuan, China Tel: (86)28 84207501 (86)28 84207506 Fax: (86)28 84209696 E-mail: master@widearea.com.cn... - Page 2 All brand names and trademarks are the property of their respective owners. This publication may not be reproduced in whole or in part without the express written permission of Widearea.
-
Page 3: Table Of Contents
2. Technical Specifications ............ 4 3. Physical Structure .............. 4 4. Application ................. 7 5. Installation Procedure ............8 6. Troubleshooting ............... 11 This publication may not be reproduced in whole or in part without the express written permission of Widearea. -
Page 4: General Description
AER800-2P, or two ports Extender and additional copper pairs are required to supply power. AEC-C1PL is one outlet power supply for line power supply ADSL Loop Extender AER800-xPL. Each outlet can supply for one port line power Extender. no additional copper pairs are required to supply power. -
Page 5: Technical Specifications
Centralized and regular power supply, make the CO clean Comprehensive over-voltage protection. Easy to install, deploy and maintain 2. Technical Specifications Table 1 –Technical Specifications of AEC-RACK, AEC-C2P & AEC-C1PL Temperature -10℃～+45℃ Operating Environment 5%～95% Relative Humidity (Non-condensing) Input Voltage DC48V（36V～72V）... - Page 6 Extender. The instruction of the DC122V/DC155V switch of AEC-C2P, please see the remark below. when the card is AEC-C1PL, you can get 1х155V and ADSL signal from “A2,B2” outlet, supply power for the signal line power Extender. ...
- Page 7 DC122V can power for one port or two ports ADSL Loop Extender, and DC155V can power for four ports ADSL Loop Extender. This publication may not be reproduced in whole or in part without the express written permission of Widearea.
-
Page 8: Application
AEC-C1PL Figure 4 the panel of AEC-C1PL In figure 4, “PWR” indicates the status of the equipment. After power supply is connected, press the button “K”, and the corresponding PWR indicator should be solid on. Flashing indicator indicates short circuits or over-current alarm condition. -
Page 9: Installation Procedure
L1: The signal twist pair connecting power supply to Extender L2: The signal twist pair connecting ADSL Loop Extender to Modem. Note: Signal line power supply Extender with remote power supply AEC-C1PL from central office, no additional copper pair required to power the Extender. 5. Installation Procedure 1. - Page 10 Extender’s ground terminal. The other end of the wire should connect to a good ground point. ⑵ Insert Power Supply card AEC-C2P or AEC-C1PL into AEC-RACK. ⑶ Connect the power supply cable Attention: The cable connecting of AEC-C2P and AEC-C1PL is different, please make sure the type of your card and follow the respective method below.
- Page 11 DSLAM/Switch, connect it to the “A1, B1” terminal of AEC-C1PL. Choose the signal line linked to the Extender, connect it to “A2, B2” terminal of AEC-C1PL. Attention: Do not connect the cable linked to the Extender to the “A1, B1”...
-
Page 12: Troubleshooting
Output is OK but the Power output cable Correct the power output Extender does not work. connection is error or short. connection or check cable. Table 5 AEC-C1PL Troubleshooting Problem Description Possible Reason Suggested Resolution Power cord is not correctly Check... - Page 13 Output is OK but ADSL Signal cable connection is Correct the Signal cable extender does not work. error or short connection or check cable. This publication may not be reproduced in whole or in part without the express written permission of Widearea.
