Summary of Contents for ADT Pulse iHUB-3001B
-
Page 1: Installation Guide
Installation Guide Copyright © 2010 ADT Security Service, Inc. All rights reserved. ISSUE 2.0 11/2010... -
Page 2: About This Guide
Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT Copyright © 2010 ADT Security Service, Inc. All rights reserved. About This Guide This document does not cover the physical installation and special configurations that may be required for the security system components. Refer to the manufacturer's documentation for each device for those specifics. - Page 3 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT Upgrading the iHub Software Prior to activating the service, the software in the iHub may need to be upgraded to the latest version. This process takes approximately 30 minutes to complete and should be performed early in the install process so it can be done parallel with the site’s installation activities.
- Page 4 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 4. Select the type of security system panel you are installing, and click Continue. The Enter Activation Key screen appears. 5. The iHub’s current firmware will be displayed, along with the Latest firmware version required.
- Page 5 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 6. The firmware upgrade process will take about 30 minutes to complete. During this time, other installation activities may be done. 7. When the upgrade is complete, the iHub will reboot and the LEDs will return to the “green / dark / dark / green”...
-
Page 6: Connecting The Hardware
Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT Activating the Service with Security Panel Before continuing the activation process, you must make the hardware connections. Since each security panel is different, follow the instructions in the next section, "Connecting the Hardware", for the specific security panel you are installing. - Page 7 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT External Antenna units: 1. If the iHUB has an external antenna, the unit can be located on a wall or on a horizontal surface (desk top). Try to place it at least 6 inches from other communication or heat generating devices.
- Page 8 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 4. Select the type of hardware you are installing, and click Continue. The Enter Activation Key screen appears. 5. Enter the activation key, and click Continue. Note: The activation key contains numbers from 0-9 and letters from A-F.
- Page 9 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 6. Select the appropriate options for the installation based on the information on the Installer Reference Sheet, and click Continue. The Physical Setup screen appears. The exact wording on this screen varies based on the security panel you are installing and the service options you selected on the previous screen.
-
Page 10: Creating A User Account
Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT Assigning the Site Owner The next step in the procedure is to set the site owner, configure the site settings, and sign in to the web portal to complete the installation process. The user selection screen should still be displayed on the computer. - Page 11 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 2. Enter the required information for the customer. Note: The customer’s email address will also be their username. Click Continue. The Site Information screen appears. Continue with "Configuring Site Information" on page Configuring Site Information When you click Continue on either the user selection screen or the Create User Account screen, the Site Information screen appears.
- Page 12 The Security Panel User Access Code must match the same access code in the ADT Pulse portal. For example if the user access code is 1234 (not recommended), the ADT Pulse setting must also be 1234 or remote control will not be possible.
- Page 13 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT 3. Enter your installer password in the Installer Password field, and click Sign In. The web portal launches and displays a site status message at the top of the page indicating that the site is in install mode.
- Page 14 Installation Guide for the iHub-3000B-ADT, iHub-3001B-ADT Specifications, Approvals and Certifications. Ethernet 1 (10/100 Mbit/sec port) 1 (10/100 Mbit/sec port) Wireless WiFi IEEE 802.11b/g Z-Wave Built-in Z-Wave module Wired Control RS232/ RS422 1 (External RS232 / RS422 by screw terminal connector)
- Page 15 FCC Warning statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
