- Page 1 Ocean Way Audio Pro2A Operations Manual...
- Page 2 About Ocean Way It all started with speakers. Ocean Way Recording began in 1968, as a showcase for Allen’s custom monitors. Allen needed impressive sounding material for his speakers so he began to record music that sounded dramatic! The studio business boomed and he met the demand with many rooms in several locations.
- Page 3 Through-out the history of Ocean Way Studios, we built the monitor systems for all the control rooms and private studios for selected elite cliental. These many accomplishments, paved the way for Ocean Way Audio delivers “the” sound of Ocean Way Studios in a free standing design. Pro-Series...
- Page 4 Manual of Operations Ocean Way Audio – Pro2A Professional Sound System...
- Page 5 Contents 1) Pro2A Description 2) Safety Instructions and Warnings! (please read carefully) 3) Inputs and Controls 4) Input selectors & Legends 5) S12A Sub-Bass option 6) Specifications 7) Warranty...
- Page 6 1)Pro2A Pro2A is the latest addition to the OWA speaker line achieving efficient distortion-free dynamic range in an aesthetically appealing trapezoidal profile. Its cabinet features a sleek design with attention to time alignment, reduce baffle reflections and materials designed to minimize low frequency resonance. Its port is optimized to increase the woofer's low frequency extension and sound pressure level capacity.
-
Page 7: Safety Instructions And Warnings
2) Safety Instructions and Warnings Read the information for use Please keep this user manual in a safe place during the lifetime of the product. Heed all warnings. Follow all instructions. Do not use this product near water (for example, in damp rooms or near a swimming pool). ... - Page 8 Servicing Do not attempt to service this product yourself. As opening or removing covers may expose you to dangerous voltage or other hazards, the amplifier may only be opened by qualified personnel. Please refer to your dealer/distributor. Servicing and Replacement Parts All service and repair work must be carried out by an authorized dealer/distributor.
- Page 9 Power Cord Protection Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon them or against them, paying particular attention to cords and plugs, and the point where they exit from the Amplifier Unit.
- Page 10 Connecting When you connect this speaker to other equipment, turn off the power and unplug all of the equipment from the supply source. Failure to do so may cause an electric shock and serious personal injury. Read the user's manual of the other equipment carefully and follow the instructions when making the connections.
- Page 11 DO NOT REMOVE MAINS CONNECTOR GROUND, IT IS ILLEGAL AND DANGEROUS. AC power 115/230v switch Make sure to correctly configure with the correct voltage for your country.
- Page 12 3) Inputs and Controls Pro2A...
- Page 13 4) Input Selectors & Legends The Pro2A is factory pre-set to Analog Input. Just plug in your source and start enjoying the rich sound quality – nothing more to do! Operation: There are four presets stored in the speaker’s memory. The four LEDs give you an indication of which preset and input are active.
- Page 14 Selecting Digital or Analog Inputs Selecting Digital Inputs: If you want to use the direct digital inputs, it’s very simple once you’ve toggled through the simple set-up. Steps are: Using a small blunt tool (like the cotton swap stick one end removed) push and hold the LED selector switch for a full second and LED #1 will be “OFF”...
- Page 15 Press and hold the LED selector switch for one full second and LED #3 and LED #4 will be “OFF”. The speaker is now in 2-Way mode. Note: If you own an Pro2A model; The speaker system will only allow for the Analog mode when selected to 3-Way. Contact Ocean Way Audio support with any questions.
- Page 16 LED Selector Legend Pro2A LED1 – when lit indicates the ‘Analog In’ XLR is active LED2 – when lit indicates the ‘Digital In (AES-EBU)’ XLR is active LED3 off / LED 4 off – System is configured as a 2-way system with no low frequency roll off.
- Page 17 Set up Continued: As you can see, short pushes scroll you through the preset menu while long pushes can either select the desired preset or toggle the input between analog and digital. A long push following short pushes will select a preset whereas an initial long push will toggle inputs.
- Page 18 5) S12A Description S12A can be added to a Pro2A 2-way system if desired. The S12A sub-bass cabinet is a single 12” long throw woofer in a bass reflex cabinet extending the response down to 25Hz. It is powered by an 800 watt amplifier.
-
Page 19: Specifications
6) Specifications Tech Specs Pro2A Powered YES, Accepts analog/digital inputs 24 bit / 192 kHz Driver Configuration 2-way HF Driver Size 1" LF Driver Size 8" LF Driver Power Amp 125watts HF Driver Power Amp 125watts AES3 Digital Inputs Frequency Range 35Hz >... -
Page 20: Warranty
7) Warranty HR4, HR4S, S12A and Pro2A product is under limited warranty as described in the following conditions. Warranty period starts as of date of purchase from the authorized dealer. OWA reserves the right to request original purchase receipt as proof of the date of purchase.
