Summary of Contents for Sentencia Volumo
- Page 1 Technical Manual WATER SOFTENER © 2016 erie water treatment TM-EN-Sentencia-Rev2016.01...
-
Page 2: Table Of Contents
Default parameter settings ....................Page 17 Exploded view - System .......................Page 18 Exploded view - Cover assembly ..................Page 20 Exploded view - Valve body assembly - Volumo ..............Page 22 Exploded view - Valve body assembly - Volumo ..............Page 24 Exploded view - Valve body assembly ..................Page 26 Technical data - Volumo .......................Page 28... -
Page 3: Warning & Safety Instructions
WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the water softener, we advise you read and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in this Technical Manual. -
Page 4: Operating Conditions & Requirements
OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE: min. 1,4 / max. 8,3 bar this system is configured to perform optimally at an operating pressure of 3 bar (±½ bar); in case of a lower or higher operating pressure the performance may be affected negatively! ... -
Page 5: Installation
INSTALLATION 5. Connect the house/application to the outlet of the 3-valve Picture 1&10 bypass system (). To facilitate the installation, you may want to remove the salt lid and main cover from the water softener. DRAIN 1. Remove the salt lid. 2. -
Page 6: Start-Up
START-UP PRESSURIZING PERFORM REGENERATION 11. Manually initiate a regeneration, by pressing the scroll 1. Make sure the bypass system is in 'bypass' position. button repeatedly until the display shows: 2. Make sure the electronic controller of the water softener is in service mode. Regen in 10 sec 3. -
Page 7: Electronic Control Panel
ELECTRONIC CONTROL PANEL Picture 7 REGENERATION MODE In regeneration mode the display shows the actual symbol button function regeneration cycle and, where relevant, the total remaining to advance to the next SCROLL regeneration time and remaining cycle time: parameter to increase the value of the Rgn:XXX CycY:ZZZ parameter to decrease the value of the... - Page 8 ELECTRONIC CONTROL PANEL PROGRAMMING INSTRUCTIONS - INSTALLER Before entering the programming mode, make sure that the control valve is in the service mode. 1. Press the scroll button; the display will show: Language:English Press the up or down button to set the ...
- Page 9 ELECTRONIC CONTROL PANEL 7. Press the scroll button again; the display will show: PROGRAMMING INSTRUCTIONS - PARAMETER SET LEVEL MTR:SNAP SENSOR All configuration parameters on this water softener have Press the up or down button to set the type of ...
- Page 10 ELECTRONIC CONTROL PANEL EZ3P5e EZ3PB r11: display shows the software version DIAGNOSTICS LEVEL (for factory purpose only). CapToUse: display shows the remaining capacity. Besides of all programming parameters, a series of operating Fill: display shows the refill time used for the previous ...
-
Page 11: Maintenance
MAINTENANCE = inlet valve to water softener is OPEN ROUTINE CHECKS = outlet valve from water softener is CLOSED Regularly the user should perform a basic check to verify if the WATER CONDITIONER SALT water softener is functioning correctly, on the basis of the following control points: 1. -
Page 12: Hydraulic Flow Diagrams - Volumo
HYDRAULIC FLOW DIAGRAMS - VOLUMO SERVICE BRINE DRAW SLOW RINSE REFILL SERVICE BRINE DRAW / SLOW RINSE REFILL PREPARATION Page 12... -
Page 13: Hydraulic Flow Diagrams - Volumo
HYDRAULIC FLOW DIAGRAMS - VOLUMO SERVICE BACKWASH BRINE DRAW SLOW RINSE FAST RINSE REFILL SERVICE BACKWASH BRINE DRAW/SLOW RINSE FAST RINSE REFILL Page 13... -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Hard (untreated) water Open or defective bypass Close or replace bypass to service Water softener in regeneration Wait until regeneration finishes or manually advance regeneration to end No salt in brine cabinet Add salt and initiate regeneration manually Salt bridging Break salt bridge(s) and initiate regeneration manually... - Page 15 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Control valve fails to Low operating pressure Check operating pressure; must be higher than 1,4 draw brine Drain flow adjuster closed too much Open drain flow adjuster slowly until unit draws brine Plugged injector and/or brine restrictor Clean injector and/or brine restrictor Plugged injector filter Clean injector filter...
-
Page 16: Electrical Wiring Diagrams
ELECTRICAL WIRING DIAGRAMS VOLUMO = flow meter = power lead = 24VAC auxilliary contact, closed during regeneration (max. 500mA) = refill solenoid (white) = drain solenoid = key pad ... -
Page 17: Default Parameter Settings
DEFAULT PARAMETER SETTINGS Model Volumo Resin Hardness unit °f °f °f °f °f Exchange capacity per liter resin (°f M (1) (2) Resin (liters) Override (days) Cycle 1: BRINE DRAW/SLOW RINSE (min) Cycle 2: REFILL (min) SNAP SNAP SNAP SNAP... -
Page 18: Exploded View - System
EXPLODED VIEW - SYSTEM Page 18... - Page 19 Brine valve assembly 464 to be cut to length BW3.5/0403 Brine well, 403 mm Volumo 11L, Volumo BW3.5/0538 Brine well, 538 mm Volumo 15L, Volumo 20L, Volumo BW3.5/0823 Brine well, 823 mm Volumo 26L, Volumo 32L, Volumo 20L, Volumo H1016/4...
-
Page 20: Exploded View - Cover Assembly
EXPLODED VIEW - COVER ASSEMBLY Page 20... - Page 21 EXPLODED VIEW - COVER ASSEMBLY Item Description Remark 38377 Screw, PCB cover 72565 PCB cover 15/102 Screw, PCB 72535 Printed Circuit Board Volumo 72534 Printed Circuit Board Volumo 38496 Main cover 38549 Front panel assembly 72685 Backwash solenoid cable (black) Volumo only ...
-
Page 22: Exploded View - Valve Body Assembly - Volumo
EXPLODED VIEW - VALVE BODY ASSEMBLY - VOLUMO Page 22... - Page 23 EXPLODED VIEW - VALVE BODY ASSEMBLY - VOLUMO Item Description Remark 15/90 Screw, solenoid retainer (4x) 413/134/24 Solenoid 541/229 Retainer, solenoid 413/58 Guide, solenoid 413/62 Spring, solenoid plunger 74099 Plunger, solenoid 74098 Diaphragm, solenoid 15/222 Screw, back cap (4x)
-
Page 24: Exploded View - Valve Body Assembly - Volumo
EXPLODED VIEW - VALVE BODY ASSEMBLY - VOLUMO Page 24... - Page 25 EXPLODED VIEW - VALVE BODY ASSEMBLY - VOLUMO Item Description Remark 15/90 Screw, solenoid (6x) 413/134/24 Solenoid (2x) 541/229 Retainer, solenoid 413/58 Guide, solenoid (2x) 413/62 Spring, solenoid plunger (2x) 74099 Plunger, solenoid (2x) 74098 Diaphragm, solenoid (2x)
-
Page 26: Exploded View - Valve Body Assembly
EXPLODED VIEW - VALVE BODY ASSEMBLY Item Description Remark 15/87 Screw, valve head 72216 Valve head 541/300/G Drain flow control 2,0 gpm 11L, Eco 15L, Eco 541/300/J Drain flow control 2,6 gpm 185/115/1 O-ring, drain line adaptor 74018 Nut, drain solenoid 74016 Drain line adaptor 74019... - Page 27 Page 27...
-
Page 28: Technical Data - Volumo
TECHNICAL DATA - VOLUMO Technical specifications: Model Sentencia Volumo Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure... -
Page 29: Technical Data - Volumo
TECHNICAL DATA - VOLUMO Technical specifications: Model Sentencia Volumo Resin (Ltr) Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure... - Page 30 Page 30...
- Page 31 Page 31...
- Page 32 Manufactured & Assembled by erie water treatment a division of Aquion, Inc. www.eriewatertreatment.com...
