- Page 1 3-AXIS GIMBAL OPERATING MANUAL GHOSTDRONE 2.0 created by EHang, Inc.
- Page 2 Disclaimer Before using 3-axis gimbal, please read the operating manual carefully and familiarize yourself with the operations, warnings and applications. EHang shall not bear any liability or responsibility of the damage of the gimbal, the copter or any other related accessories...
- Page 3 ■Introduction EHang 3-axis gimbal is specially designed for GHOSTDRONE series. It is compatible with GoPro3，GoPro3+, GoPro4 and EHang sports camera. The highly accurate and stable gimbal system can help you create amazing aerial shots. ■Structural Diagram Dampener Bottom Board of the Gimbal...
- Page 4 ■In the Box 3-Axis Gimbal*1 Plate Adapter*1 Adapter Cable*1 Copper Pillar*4 Screw*4...
-
Page 5: Gimbal Assembly
■Gimbal Assembly 1. Put the copter upside down on a soft surface to avoid unnecessary scratches, and use a screwdriver to tighten four copper pillars on the bottom of the aircraft. 2. Connect the gimbal wire to the P1 interface on the plate adapter. Gimbal Wire P1 Interface Plate Adapter... - Page 6 3. Mount the plate adapter to the gimbal by using two screws. Screw Bottom Board of the Gimbal Plate Adapter (Upside down) 4. Fix the gimbal base by tightening two screws on the other two copper pillars.
- Page 7 Aircraft ■Camera Assembly EHang 3-axis gimbal is compatible with GoPro3, GoPro3+, GoPro4 and EHang sports camera. Please note that camera is not included in the box. Take assembling EHang sports camera as instance below. 1. Connect the gimbal black plug with the sports camera’ s USB...
- Page 8 2. Use the camera guard to fix the sports camera lens, and tighten the screws. Completed Assembly...
- Page 9 But limited warranty is still provided. ■Contact Us Business Hour: Monday – Friday 9:00 A.M – 5:00 P.M (PST) Customer Service Phone: +1 650-533-8554 / 888-800-7056 Customer Service Email: support@ehang.com EHang, Inc. reserves all right to interpret this warranty.
