R180E Series
Thank you for buying our product
·
To make sure your operation is right and safe, please read this
manual careful ly before use.
·
Unauthorized copying or disseminating of this manual is i l legal.
·
The content of this manual including the product' s parameters are
subject to change without notice.
·
Every effort has been made to ensure the accuracy of this manual,
so if you find anything wrong or being omitted, please contact us
immediately, and we wi l l be very appreciate!
·
company shal l not be l iable for any errors or for direct or
indirect incidental or consequential damages when use this printer.
·
company shal l not be l iable for any errors or for direct or
indirect incidental or consequential damages in connection with the error
operation.
·
It is a Class A product and may cause radio interference in
environment. In this case, user may be required to make adequate
measures.

User Manual

V1.0
Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R180E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wuhan Guide R180E Series

  • Page 1: User Manual

    R180E Series User Manual V1.0 Thank you for buying our product · To make sure your operation is right and safe, please read this manual careful ly before use. · Unauthorized copying or disseminating of this manual is i l legal.
  • Page 2: Table Of Contents

    Content Machine Specification ……………………………………………………………1 Operation Insctruction …………………………………………………………2 Accessories …………………………………………………………………………5 Hardware………………………………………………………………………………6 Print Preparation …………………………………………………………………8 1.Software Installation ………………………………………………………8 2.USB3.0 Driver Installation…………………………………………………11 3.Panel Description ……………………………………………………………17 4.Operation Preparation ………………………………………………………18 5.Start Point Setting …………………………………………………………18 6.Menu Bar Main Function………………………………………………………18 7.Print Quality …………………………………………………………………19 8.Print Head Cleaning …………………………………………………………20 9.Print Head Physical Calibration …………………………………………21 10.Print Head Bidirectional Calibration……………………………………24 11.Double Heads Printing Position Calibration……………………………26...
  • Page 3: Machine Specification

    Machine specification R180E/R180E(UV) Model R180E/R180E(UV) Printhead Piezo electric printhead DX5 No.of printhead 2 pieces Max print width 1800mm Max print height ≤30mm Dimension 3160*1130*1330(L*W*H) print mode standard production 4PASS 30㎡/Hr Printing speed 6PASS 20㎡/Hr 8PASS 15㎡/Hr 16PASS 8㎡/Hr model Eco solvent ink/UV color 4 colors/6 colors/8 colors Temperature...
  • Page 4: Operation Instruction

    Operation instruction Recommendation for computer configuration Hardware:CPU: 3.00GHZ Memory: 4.00GB Mother board: equiped with PCI slot Chipset: INTEL System: WINXP-SP3 Data interface: USB3.0 MICROSOFT WINDOWS XP PROFESSIONAL WARNING & CAUTION marks to warn the user that deformity,serious injuries or death may caused if any wrong operation.
  • Page 5 D o n o t u s e t h i s p r i n t e r u n d e r Do not put cartridge, cleaning solution the following environment: open or waste inks under the following f i r e s , e l e c t r i c s p a r k , s t a t i c environment: electricity,high temperature or any...
  • Page 6 When pull out the plug please seize hold Do not damage or modify the power cord, of the plug not the power cord. and do not over fold, twist, pull, bend or pinch the power cord, even put otherwise plug might be damaged and fire heavy items on it.
  • Page 7: Accessories

    Accessories 1.Accessories checking USB cable:1 Keys:2 Three core power cord 5M:1 Square tube:1 L e f t f e e d i n g M a n u a l m o d e l Disk:1 Ring:2 bracket:1 feeding(left):1 R i g h t f e e d i n g M a n u a l m o d e l...
  • Page 8: Hardware

    Hardware Parts name Main View NOTICE Guide rail(carriage rail,please keep clean and DO NOT touch the rail or put clear,put on ubricating oil regularly) h a n d i n t o t h e r i g h t c a b i n unless adjust the printhead height.
  • Page 9: Back View

    Back View 12.media 14.Convey belt 13. Back guide 11.Convey belt tension pressing tension device(adjust device(guide the device(adjust the level(press the the tension of convey plate movement) tension of convey net) printing media) net) Right View 15.Power switch 19.Media pressing level 16.Led switch 17.Vacuum fan switch 20.Feeding system...
  • Page 10: Print Preparation

    Print Preparation 1.Software installation 1)Double-click software installation package and installation interface pops up. 2)Click “browse” to choose installation location, and then click “next”. Please do not install printer driver on C drive in computer.
  • Page 11 3)If selected shortcut installation location, then just click next. 4)Choose whether to create a shortcut. 5)Installation interface pops up and click “install”.
  • Page 12 6)Installation progress displays. 7)Click “finish”. Before printing, please install print driver and USB3.0 driver and then the machine can be used.USB3.0 driver installation steps, please refer to page 11-16.
  • Page 13: Usb3.0 Driver Installation

    2.USB3.0 driver installation USB3.0 installation (windows 7 system) 1)Right-click “computer” and select “manage”. Manage 2)Click “device manager”. Device manager 3)Right-click “YiLi USBboard” and select “update driver software”. Yili USBboard Update driver software USB3.0 driver installation must require that the machine is switched on and connected USB3.0 data cable.
  • Page 14 4)Select “browse computer to find driver software”. Brouse computer to find driver software 5)Select “browse”. Brouse 6)Select “x86” folder in print software installation location. “x86”folder...
  • Page 15 7)Click “next”. Next 8)Security alert dialog box pops up and select “install this driver software anyway”. Install this driver software anyway 9)Click “close” to finish USB3.0 installation. Close...
  • Page 16 USB3.0 installation (XP system) 1)Right-click “my computer” and select “device manager”. Device manager 2)In “device manger” and under “other device” to find “YiLi USB3.0”. Other device YiLi USB3.0 3)Right-click “YiLi USB3.0” to select “update driver software”, then driver update dialog box pops up, select “yes, install this driver anyway”,then click “next”.
  • Page 17 4)Installation dialog box pops up, select “install from a list or specific location” and click next. Install from a list or specific location 5)Click “browse”. Brouse 6)In print software installation directory “XENONS-R180-E-2HEAD-4C- CHS-1.0.0.1”,under the subfolder “driver”, select “X86”and click “ok”. XENONS-R180-E-2HEAD-4C-CHS-1.0.0.1 “Driver”folder “x86”folder...
  • Page 18 7)Click “next”. Next 8)Installation progress displays. 9)Security software will pops up, select “allow load”. Allow load 10)Finish USB3.0 installation. Finish...
  • Page 19: Panel Description

    3. Panel description display panel Display variety of information. “ p r i n t q u a l i t y ” “cancel” button button “cleaning” “pause” button button “ t e s t ” “base point” button button “...
  • Page 20: Operation Preparation

    4.Operation preparation When turn on, screen will display interface: base point value Base point Bidirectional printing Height Media type Media type: R ROLL B BOARD Height value 5.Start point setting Before printing, set the print base point position, use [ ] and [ ]to set the NOTICE...
  • Page 21: Print Quality

    7.Print quality ECLOSION options PICSPACE NO_ECLOSION Printing direction options Set the space between Close ECLOSION effect BI_DIRECTION(Default): the 2 pictures. The head will print during moving ECLOSION TYPE1 from right to left,and left to Strong ECLOSION effect right. MEDIA Printing Media type: ECLOSION TYPE2 The printing speed is faster than PP/Photo/Light_Film/...
  • Page 22: Printhead Cleaning

    8.Printhead cleaning INKFILL START Flash spray setting START TEST PRINT INKFILL STOP PASSNUM Start cleaning Press [CLEANING] to show cleaning interface, use [ ] and [ ] to show [START]/[TEST PRINT]/[INKFILL START],press [ENTER] to confirm, press [ ] back to previous menu. HEAD CLEANING HEAD CLEANING ENTER...
  • Page 23: Printhead Physical Calibration

    9.Printhead physical calibration [About printhead calibration] To get good print quality, it is necessary to do the printhead calibration. If the printhead is not adjusted, bandings or other problem will appear when printing,which will lower the print quality. Loosen the 8pcs of screws on the sliding block, up and down move the carriage, to make the left side and right side of printhead is parallel...
  • Page 24 *Reference* If upper line is at the right side of lower line, you need to adjust the screw which at the front of side plate. If upper line is at the left side of lower line, you need to adjust the screw Which at the back of side plate.
  • Page 25 Through adjusting the regulating screws of left printhead, to make the red and black line are aligned straightly in the test graph. front and back knob Power on, press [cleaning→print test B],to print test graph, as right picture showed. Loosen the set screws of right printhead, to adjust the front and back knob of right printhead, to make the test graph which separately...
  • Page 26: Print Head Bidirectional Calibration

    10.Printhead Bi-direction calibration * Only required when the print direction is set to be [BI_DIRECTION] under [PRINT QUALITY]. This adjustment is for bidireciton printing offset adjustment. This operation should be carried out when you change media, or printhead height is adjusted. Press [MENU] and [ ],to select BIDIRECTION.
  • Page 27 Press[ ] [ ]to add step 4 selected value to the step 5 value, then press [ ENTER ] to confirm and exit interface at the same time. BIDIRECTION-------1 BIDIRECTION-------1 ADJUST ADJUST ENTER Go back to step 2, take a test printing. Test result Current value 10 9 8 7...
  • Page 28: Double Heads Printing Position Calibration

    11.Double heads printing position calibration * Double printheas printing calibration is limited to two printheads machines. This calibration is to adjust the two heads printing coincidence from right to left, left to right and front to back. When moving printhead or re-install the driver, it is necessary to take this operation.
  • Page 29 Press [ ] to select ADJUST,press [ ] and [ ] to enter adjusting calibration value, and add step 4 value to the current value. HEAD1----HEAD2(RL) HEAD1----HEAD2(RL) ADJUST ADJUST Go back to step 2, step 3 and take test printing. Test result Current value 10 9 8 7...
  • Page 30 Enter OVERLAP submenu, press [ENTER] to start test printing. Test results No deviation value Check test printing result, choose the value of line without overlap, in this case, the value without overlap is “1”. 用Use [ ] to select ADJUST,use [ ] and [ ] to change the value of step 11, and press [ENTER] to confirm.
  • Page 31: Same Color Calibration

    12.Same color calibration Same color calibration is used for distance calibration of two groups of head nozzles with the same print color. To ensure that all in the same vertical position when printing. According to the finest line’s value printed in the same color calibration to increase or decrease in software of same color calibration parameters, so that final 0 corresponds to the line is the finest.
  • Page 32: Color Calibration

    13.Color calibration The purpose is to print different color on the same horizontal position, in order to print perfect picture effect. According to the printed color calibration chart, increase or decrease the most overlap value of variety color and K color in color calibration software parameters.
  • Page 33: Board Print Setting

    14.Board print setting Before printing, please adjust print head height to avoid scratch the head. Print head setting: press “test” to increase carrier height, push the carrier on top of print media slowly, then fine tuning the carrier height (the height between carrier and print media 1.7-2.0mm will be better).
  • Page 34: Maintenance

    Maintenance Change cartridge D o n o t u s e t h i s p r i n t e r u n d e r t h e Do not put cartridge, cleaning solution following or waste inks under the following environment: open fires, electric spark, environment: static electricity, high temperature or...
  • Page 35 NOTICE Only use the water-based ink. Unplug the cartridge. Insert a new cartridge. Cartridge Cartidge slot...
  • Page 36: Handle Waste Ink

    Handle waste ink Please handle waste inks as following steps when ink reaches the limit level of waste ink collecting box or you need to move the machine. Collect the waste ink via our waste-ink collecting container. The fire or illness may caused if waste ink leak or evaporate.
  • Page 37: Machine Cleaning

    Machine cleaning NOTICE Before cleaning please turn off the main power switch and unplug the power cord first. *Turn off the sub power switch first and then turn off the main power switch. Do not add lubricating oil on mechanical parts. Do not use solvent cleaning solution to clean.
  • Page 38: Printhead Maintenance

    Printhead maintenance The printer and the surrounding working environment must accord with the requirement for equipment.(Temperature:20-32℃,Humidity:40-60%),and the surroundings should not have the equipments which have strong magnetic field and may cause a lot of dust. In process of using,you have to keep platform clean without foreign matter to avoid scratching the surface of print head.
  • Page 39: Frequently Asked Questions

    FAQ handling Reasons Solutions Machine 1.The main switch of power is not on. 1.Switch on the main power. can’t work 2.The emergency stop switch in both 2.Switch on the emergency stop switch after power sides is not on. in both sides. 3.The air switch inside machine is not 3.Switch on the air switch inside.
