5. Specifications

Specifications are intended for reference only. The design may be modified to improve features or functionality
without notice.
Specifications
Input Voltage
Input Current (charging)
Input Current (non-charging)
Shutter Open time (Sync time)
Shutter full cycle time
Output Current Sink (Flash Sync)
Max Voltage on Flash Sync Port (Steady State)
Operating Temperature
Weight (shutter)
Weight (controller)
Open Diameter
Shutter Life
Filter Threads
Adapter Ring Threads
Optical path depth
*Shutter can be rebuilt after wear out.
MIN
10
-
-
-
-
-
-
5
40,000*
12
NOM MAX UNITS
14.8 16.8
2000 - mAdc
30 - mAdc
5.8 -
16 -
- 1
- 40
25 60
500
285
30
Cycles
34x0.5
37x0.5
Vdc
ms
ms
Adc
Vdc
C
g
g
mm
mm
mm
mm
