FireNET Vapor VPR-SD1
Product Guide
October 2012
Document: 21537_00
Part Number: HA-06-335

Advertisement

Table of Contents
loading

Summary of Contents for Hochiki FireNET Vapor VPR-SD1

  • Page 1 FireNET Vapor VPR-SD1 Product Guide October 2012 Document: 21537_00 Part Number: HA-06-335...
  • Page 3 Hochiki or its representatives. Total Liability To the fullest extent permitted by law that any limitation or exclusion cannot apply, the total liability of Hochiki in relation to the products is limited to: i.
  • Page 4 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Document Conventions The following typographic conventions are used in this document: Convention Description Bold Used to denote: emphasis Used for names of menus, menu options, toolbar buttons Italics Used to denote: references to other parts of this document or other documents.
  • Page 5 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Codes and Standards Information for Air Sampling Smoke Detection We strongly recommend that this document is read in conjunction with the appropriate local codes and standards for smoke detection and electrical connections. This document contains generic product information and some sections may not comply with all local codes and standards.
  • Page 6 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 7: Table Of Contents

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Table of Contents Introduction Detector Installation Mounting the Detector Enclosure Wiring Point Detectors Pipe Network Installation Pipe Specification Fixings Sampling Holes End Cap Bends Capillary Tubes Exhaust Filters Open Area Applications 3.10...
  • Page 8 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 9: Introduction

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Introduction The VPR-SD1 is an aspirating smoke detection system that utilizes an air-sampling pipe network to draw air towards analog addressable point detectors installed inside a sealed enclosure. The single channel VPR-SD1 detector enclosure (Figure 1-1) has one pipe inlet and provision for one or two point detectors allowing for redundant or double-knock detection.
  • Page 10 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 11: Detector Installation

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Detector Installation The VPR-SD1 is provided with the following components: 1 detector enclosure 1 corner stud key 1 blanking baffle 1 ferrite core 1 installation sheet with mounting template 1 product guide Check all components for damage and refer any concerns to your authorized representative.
  • Page 12: Mounting The Detector Enclosure

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Mounting the Detector Enclosure Notes: This equipment must be installed by a qualified installer in accordance with all local and national code requirements. The detector assembly must be installed at an accessible position to facilitate maintenance and testing.
  • Page 13 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Dimensions: 0.87 “ (22.0mm) 1.50 “ 3.72 “ (94.5mm) 4.76 “ (121.0mm) 2.09 “ (38.0mm) ø1.18 “ (53.0mm) ø1.18 “ ø1.06 “ (27.0mm) (30mm) (30mm) 0.87 “ (22.0mm) 10.18 “ (258.6mm) 1.18 “...
  • Page 14: Wiring

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Wiring All wiring connections are made through the terminal blocks (B) in the Wiring Enclosure (A) as indicated on the system wiring diagrams in Section 2.2.3. Notes: Wiring should be installed according to local codes and standards.
  • Page 15 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Figure 2-5: Ferrite core and battery supply wiring Power requirements are dependant on the fan speed. Refer to Chapter 8 for further information. 2.2.2 FAULT Relay (FAULT 2) In the event of a fault condition, the Fault relay will change state. The terminals provide for Normally Open (NO) or Normally Closed (NC) operation and these can be wired using terminating resistors to simulate a zone fault on a conventional control panel or via a loop interface module for an analog addressable panel.
  • Page 16: Point Detectors

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Point Detectors The supported point detectors have successfully passed required tests to allow use within the VPR-SD1 product and application. Refer to Chapter 3 on page 13 for further details of how dilution affects detector sensitivity.
  • Page 17 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide 2.3.2 Baffles Baffles are used to direct the sampled air flow through the point detectors. They are shaped to match a particular model or range of detectors and simply clip into position in the slots provided in the transparent lid of the detector housing.
  • Page 18 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation 2.3.4 Overlabel Application The VPR-SD1 detector is provided with a selection of overlabels containing brand, model number and sensitivity range information for each of the point detectors listed previously in Section 2.3.1. As part of compliance to device listing requirements, the label that corresponds to the point detectors that are being fitted to the VPR-SD1 must be affixed to the markings label found on the right side of the unit contained in this shipping package, as shown below in Figure 2-7.
  • Page 19: Pipe Network Installation

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Pipe Network Installation This section provides a simple guide to pipe installation and should contain all the information required for simple installations based on the standard configurations shown in Section 3.9 on page 17.
  • Page 20: Sampling Holes

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Sampling Holes Sampling holes can either be pre-drilled or drilled in situ. Use a low speed drill with a sharp drill bit to prevent debris from entering the pipe. Always blow compressed air through the pipe after drilling to clear any debris before final connection to the equipment.
  • Page 21: Bends

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Bends 90 degree elbows may be used for making turns in the 3/4" CPVC sample pipe network. The total number of 90 degree elbows in a single pipe run must be kept to 10 or less to maintain acceptable system performance.
  • Page 22: Filters

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Filters Figure 3-4: Filter at inlet of system The sampled air is passed through a filter (order code VPR-SDFILTER) before entering the detector chamber. www.hochiki.com...
  • Page 23: Open Area Applications

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Open Area Applications Figure 3-5: Example of an VPR-SD1 system with one pipe 3ft ( Figure 3-6: Example of VPR-SD1 system with a tee and two pipes Distance from unit to Tee must be at most 1 m and pipes should be balanced, be of equal length and have equal number of holes.
  • Page 24 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation 3.9.1 Open Area Sampling Pipe Network Design The VPR-SD1 supports a number of pre-engineered pipe network designs.These designs incorporate suction pressure and transport time considerations. Caution: The performance of this system is dependent upon the pipe network. Any extensions or modifications to the designed installation may cause improper operation.
  • Page 25 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Figure 3-7: Predesigned Pipe Network Example - Single Pipe Figure 3-8: Predesigned Pipe Network Example - Tee and Two Pipes www.hochiki.com...
  • Page 26 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Pipe network components required for open area applications are ordered separately. Refer to Table 3-4 for further information. Table 3-4: VPR-SD1 Open Area Application Accessories List Name Part Number Description CPVC Pipe VPR-STS-210 Diameter = 3/4", Length = 210', Orange CPVC Pipe...
  • Page 27: 3.10 Duct Applications

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide 3.10 Duct Applications Although flexible tubes are typically used in duct installations, CPVC pipes may also be used together with flexible tubes. The total length of the flexible tube and CPVC pipe must not exceed the specified maximum length. Refer to Chapter 8 for further information.
  • Page 28 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Table 3-5: Duct Application Parts List Name Part Number Quantity VPR-SD1 VPR-SD1 Duct Installation Kit VPR-KIT-DS-SZ Female Elbow for elbow of duct probe KIT-DS-SZ-FE Male Connector for inlet pipe and exhaust pipe...
  • Page 29 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide 3.10.1 Duct Application Accessories List The following accessories can be ordered. Name Part Number Description Flexible Tube Pairs 50' Flexible Tube Pair VPR-FTUBE-50D OD = 3/4", ID = 1/2" ID, Length = 50' 25' Flexible Tube Pair VPR-FTUBE-25D OD = 3/4", ID = 1/2"...
  • Page 30 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation 3.10.2 Duct Pipe Network Installation Rules 1. While not mandatory, it is recommended that when possible locate probes a minimum of six duct widths downstream from bends or inlets. Such locations ensure that air flow is non-turbulent and that smoke is properly mixed with air in the duct for maximum detector/sensor efficiency.
  • Page 31 Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Notes: The sample and exhaust tubes should be installed in a location of relatively non-turbulent air flow and within the intended opening velocity range of 0-4000 feet per minute (0 to 1220 m/minute). It is recommended that measurements of airflow and examination of engineering specifications that define expected duct air velocities under all conditions and that measured velocities do not exceed the airspeed rating of the detector to be used.
  • Page 32 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation 3.10.4 Inlet Tube Selection Ensure that the sample and exhaust tube has a secure end cap or rubber plug to the end tube. Figure 3-14: Inlet Tube Orientation 3.10.5 Flexible Tube / CPVC Pipe Installation 1.
  • Page 33: Configuration

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Configuration Display Functions The icons that are present on the system display are shown below. BARGRAPH of AIRFLOW SPEED 2, 3, 4 AIRFLOW OK, HIGH AIRFLOW, LOW AIRFLOW POWER ON FAN FAULT...
  • Page 34: User Interface

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation User Interface Press and hold SELECT and CHANGE keys simultaneously for 1 sec to initialize function selection. Press and release SELECT key to sequentially step through functions. Press and release CHANGE key to modify setting.
  • Page 35: Parameters

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Parameters The Fan Speed, Flow Limits and Flow Sensitivity need to be set for each installation prior to Flow Calibration and testing. It is not possible to provide the settings for all possible installations but the following guidelines should assist in the commissioning of the unit.
  • Page 36 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation 4.3.3 Flow Sensitivity This setting determines the system's responsiveness in reporting blocked sampling points or broken pipes. The number of sampling points and fan speed are the main factors to consider for this setting.
  • Page 37: Testing

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Testing Note: Testing should only be carried out by qualified personnel. To prevent unwanted alarms, ensure that the proper authorities have been informed and that the unit has been isolated from the fire alarm system.
  • Page 38 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 39: Maintenance

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Maintenance Maintenance should only be carried out by qualified personnel. To prevent unwanted alarms, ensure that the proper authorities have been informed and that the unit has been isolated from the fire system.
  • Page 40 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Figure 6-1: Air Inlet Filter Removal www.hochiki.com...
  • Page 41: Point Detector Replacement

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Point Detector Replacement To remove and replace the point detector: 1. Disconnect power from the VPR-SD1. 2. Loosen the four screws that secure the clear plastic cover to the housing base. 3. Insert a small blade screwdriver into the lock release slot in the base. Rotate the sensor counterclockwise to remove it from the base.
  • Page 42 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 43: Troubleshooting

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Troubleshooting Problem Possible Solutions Power light flashing. Ensure supply to BATTERY connector within limits. No lights on display. Ensure supply leads correctly orientated. Ensure that BAT FUSE Fan not running. correctly seated in socket and fuse not blown.
  • Page 44 FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation This page is intentionally left blank. www.hochiki.com...
  • Page 45: Specifications

    Hochiki America Corporation FireNET Vapor VPR-SD1 Product Guide Specifications Number of Detectors 1 or 2 Analog Addressable (not supplied) Dimensions (L x W x H) 10.2 in x 6.52 in x 12.6 in (258.6 mm x 165.7 mm x 320.6 mm) Weight 7.27 lbs (3.3 kg)
  • Page 46: Www.hochiki.com

    FireNET Vapor VPR-SD1 Product Guide Hochiki America Corporation Typical current consumption figures for different fan speeds. Results are based upon an VPR-SD1 installation with 33 ft (10 m) of standard, 1in. (25 mm) aspirating pipe per channel. The unit was powered from a 24 VDC power supply.
