Summary of Contents for COMPANION COMP2012
-
Page 2: General Warnings
GENERAL WARNINGS • This appliance shall only be connected to a cylinder with 3/8” gas cylinder valve certified to AS2469 standards. • This appliance is designed for outdoor use only and must be operated a minimum of 1000mm from any flammable material or surfaces and materials. •... -
Page 3: Carbon Monoxide Hazard
Owners Manual • It may be hazardous to attempt to fit other types of gas containers or cartridges. • Use only in well ventilated areas. • Always operate appliance a minimum of 1000mm from flammable materials and walls, and a minimum of 1000mm from ceiling. •... -
Page 5: Safety Instructions
Owners Manual saFety InstruCtIOns This appliance must only be used in an above ground open air situation with natural ventilation without stagnant areas, where gas leakage is rapidly dispersed by wind and natural convection. any enclosure in which the appliance is used should comply with one of the following: a. - Page 6 COnneCtIOn your stove is designed to connect directly to a gas cylinder with a 3/8” gas valve using the specially designed lP Gas hose and in built regulator. 1. Check that the cylinder gas control is in the “OFF” position (turned fully clockwise) 2.
-
Page 7: Operating - Stove
Owners Manual OPeratInG - stove 1. Open the Lid of the Stove and Remove the PE Cutting Board 2. Turn the gas cylinder valve on in an anti-clockwise direction for one full turn 3. Turn the gas control in an anti-clockwise direction approximately ¼ of a turn and press the Piezo button 4. -
Page 8: Turning The Stove Off
aDJustInG Heat OutPut 1. Turn the gas control in an anti-clockwise direction to achieve a higher flame and in the clockwise direction for a lower flame. – hiGh turnInG tHe stOVe OFF If the appliance is no longer to be used and to reduce the risk of blocked gas jets caused by excess gas being left in the hose, all remaining gas must be expelled from the hose assembly. - Page 9 Owners Manual OPeratInG – leD light 1. Open the Lid of the Stove position the LED light in the required position by sliding along the length of the lid 2. Press button to turn “ON” and press again to turn “OFF”...
-
Page 10: Care Instructions
SPECIFICATIONS Dimensions 645W x 297L x 159hmm Gas Type Propane Consumption Total 24Mj/hr – Total (12Mj/hr per burner) Inject Size 0.37mm Certificate SAi-400049 Weight 8.8Kg CARE INSTRUCTIONS Using warm soapy water with a mild detergent wipe down all surfaces and areas of the appliance, taking care not to allow water to enter the burner outlets or aeration holes located in the burner tube. -
Page 11: Spare Parts
Owners Manual SPARE PARTS (Optional) PArT NO. DESCrIPTION PArT NO. DESCrIPTION COMP2012-01S CUTTiNG BOARD COMP2012-08S PiEZO ASSY COMP2012-02S LED LiGhT ASSY COMP2012-09S LiD LATCh COMP2012-03S TRiVET COMP2012-10S BURNER TUBE COM2012-04S TRiVET BUMPER COMP2012-11S GAS TRAiN & REGULATOR COMP2012-05S BURNER hEAD... - Page 12 Distributed by Companion Brands Bundoora Victoria 3083 www.companionbrands.com.au...
