MTB Cameras MTB-7400Q User Manual

7 inch wide tft lcd color quad system
Hide thumbs

Advertisement

Quick Links

Download this manual
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
To reduce the risk of electric shock do not remove cover(or back)
No user serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with arrowhead symbol,within an equilateral
triangle,is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Design and specification are subject to change without notice.
MTB-7400Q
7" Wide TFT LCD Color Quad System

USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the MTB-7400Q and is the answer not in the manual?

Questions and answers

Related Manuals for MTB Cameras MTB-7400Q

Summary of Contents for MTB Cameras MTB-7400Q

  • Page 1: User Guide

    MTB-7400Q 7" Wide TFT LCD Color Quad System WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN To reduce the risk of electric shock do not remove cover(or back) No user serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrowhead symbol,within an equilateral triangle,is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 2 Checking the main unit and supplied accessories Features / Technical Specifications Checking the main unit and supplied accessories MTB-7400Q (QUAD MONITOR) Operations 4-14 Using MTB-7400Q in the car SystemWiring Sun Shield MTB-80 Rear View Camera Features / Technical Specifications RESOLUTION...
  • Page 3 Operations Accessories Menu Control Keys Power Key Power Camera & Input Cable - When POWER OFF (which means STANDBY state), the LED lights in RED color. - When POWER OFF, the R gear and the WINKERS (Left / Right) and the TACHOMETER make that the linked each camera operates for displaying its field of view on the monitor.
  • Page 4 DIMMER Key SYSTEM - Locate the cursor at SYSTEM by SPLIT and/or CA.SEL Keys. - The brightness is adjusted manually at the POWER ON mode, - Select the proper system in your region by VOLUME Up/Down Keys. if DIMMER is selected in OSD set-up. - Factory default is PAL.
  • Page 5 PICTURE NOR / MIR NOR / MIR PICTURE NOR/MIR NOR/MIR CONTRAST 50 (0-100) NOR/MIR BRIGHT 50 (0-100) NOR/MIR COLOR 50 (0-100) TINT 50 (0-100) CAMERA1 - Display NOR/MIR set-up Screen by pressing the MENU Key 9 times and locate the cursor at CA1 by SPLIT and/or CA.SEL Keys. CONTRAST - Select the desired viewing mode between NOR and MIR by Volume Up/Down Keys.
  • Page 6 TRIGGER / TIME TIME TRRIGGER TRI 1 TIME - After locating the cursor at TRI 1 TIME by SPLIT and/or CA.SEL Keys, TRI1 (CA1~QUAD) select the desired delaying time for the selected viewing mode among 0 ~ 9 seconds by Volume Up/Down Keys. TRI2 (CA1~QUAD) - Factory Default : 0 second...
  • Page 7 SPLIT1 / SPLIT2 TACHO GRAPH TACHO GRAPH SPLIT1 SPLIT2 TACHO SW ON/OFF SOURCE 1 CA1 (CA1~CA4) SOURCE 1 CA1 (CA1~CA4) TACHO CA1 (CA1~QUAD) SOURCE 2 CA2 (CA1~CA4) TACHO TIME 0 ~ 9 SOURCE 2 CA2 (CA1~CA4) FREQUENCY 67 HZ (10 ~ 101HZ) AUDIO CA1 (CA1~CA4) AUDIO...
  • Page 8 TRIPLE TRIPLE SOURCE 1 CA1 (CA1~CA4) SOURCE 1 CA1 (CA1~CA4) SOURCE 2 CA2 (CA1~CA4) SOURCE 2 CA2 (CA1~CA4) SOURCE 3 CA3 (CA1~CA4) SOURCE 3 CA3 (CA1~CA4) AUDIO CA1 (CA1~CA4) AUDIO CA1 (CA1~CA4) TRIPLE - Display PIP set-up Screen by pressing the MENU Key 9 times - Display TRIPLE set-up Screen by pressing the MENU Key 9 times and locate the cursor at PIP by SPLIT and/or CA.SEL Keys.
  • Page 9 QUAD QUAD QUAD - Display QUAD set-up Screen by pressing the MENU Key 9 times and locate the cursor at QUAD by SPLIT and/or CA.SEL Keys. APPLICATION DISPLAY SOURCE1 SOURCE 1 CA1 (CA1~CA4) - After locating the cursor at SOURCE1 by SPLIT and/or SOURCE 2 CA2 (CA1~CA4) CA.SEL Keys,...
  • Page 10 Using MTB-7400Q in the car System Wiring For using MTB-7400Q on the dashboard After connecting power to the unit through the Cigarette adaptor, press [Power button] on the main unit or on the Remote Control to power on. MTB-7400Q Set up with Stand Bracket Kit and fix the Stand Bracket Kit on the dashboard of the car.
  • Page 11 MTB-10C Rear View Camera Specifications Waterproof Aluminium Diecasted Low Illumination Color CCD Camera. Mirror & Normal Image Views IMAGE SENSOR 1/3" Sony Super HAD Color CCD (Compatible with Sharp CCD) EFFECTIVE PIXELS NTSC : 270,000 Pixels / PAL : 320,000 Pixels RESOLUTION 380 TV Lines SYNCHRONIZING SYSTEM...
