Summary of Contents for Sheng Jay Automation Technologies K12-Pro
-
Page 2: Table Of Contents
2. Movie Resolution ........15 3. Datetime ............16 4. Audio ............16 5. Language ............17 6. TV ..............17 7. About ............18 K12-Pro Specification ..........18 Product Description The K12-pro support full HD video recording. All the recorded... -
Page 3: Caution
data save in the SD memory card and use can view the recorded video via embedded 2’4 inch LCD. The most important feature of k11 is to clarify responsibility when accident occurs. The truth can be restored in seconds. Caution ... - Page 4 video images. Please do not leave unnecessary objects around the device. If a damaged or a non-authentic SD card is used, the recorded data maybe damaged or will not record. Device warm up time is around 20 seconds, please wait patiently.
- Page 5 for any data lost C. Interference Keep product’s distance from electronic equipment that could emit electromagnetic waves such as GPS navigation device or cell phone. The electromagnetic waves would affect record quality. D. Maintenance Do not disassemble, repair, or alter the product. Any malfunctions, errors, or product damage are found attributable to user, user may not be qualified for warranty service.
-
Page 6: Product
Product A:Power On/Off H:LCD On/Off B:MIC I: GPS receiver input C: Cradle connector J:Power Input D:Camera K:Indicator E: SD Slot L: Function Key F: AV OUT M:2.4 inch LCD G:Earphone... - Page 7 Function Key A: Backward: Non-recording mode: Enter setting mode. Video Mode: select previous video / video play backward Setting mode: Back to non-recording mode B: Forward: Video Mode: Next Video/Video Forward Setting mode: Enter next step C: Video mode: In Non-recording mode: Enter Video mode D: Up: Recording mode: Zoom In Setting: UP...
- Page 8 Package 1.Main unit*1 2.Power Cable*1 3.Manual*1 4. Cradle*1 ※Please check Package ※GPS Receiver(Optional). This device has no navigation functi on. The GPS receiver only receive GPS and display on the re corded video only...
-
Page 9: Feature
Product Feature 1. Auto Recording 2. high quality 2.4’LCD 3. Full HD video recording quality 4. Support MP4 format Support 4-32GB SDHC SD card 6. G-Sensor 7. Loop record 8. Super capacitor 9. Zoom in/Out Feature 1. Auto Recording； Start recoding data when turn on the vehicle. Stop recording while vehicle is turned off then saves last file to SD card. - Page 10 3. Full HD Quality Video Record 1080 P /HD 1920x1080 pixel，FPS 30 Bring you back to the scene. STOP 4. MPEG/MP4 Format No need to install new software. The START recorded data can be played in various video player program such as Gretech Online Movie Player，...
- Page 11 7. Loop Recording Continue recording to keep updating newest data. For example, if SD card is full, the system erases oldest file, and save new file to instead of oldest one. 8. Super capacitor It is safer than the lithium battery. Save the last file after vehicle is turned off.
-
Page 12: Lcd Display
Super capacitor，Save the last file after vehicle is turned off. Resistant to high temperatures Simple design with easy installation and operation GPS Receiver (Optional). This device has no navigation function. The GPS receiver only receive GPS and display on the recorded video only LCD Display A. -
Page 13: Setting Mode
The red mark display recording status is on B. Voice status Record Voice; Non-recording voice C. Loop recording, one file per two minute D. The current view of camera E. Time and date: Display current time and date Setting mode How to enter setting mode? A. -
Page 14: Setting Mode Option
Setting Mode option A: setting option B: current setting... -
Page 15: Format
1. Format Format your SD car. After SD card fromat completed, press “A” key to back to Non-recording mode and press “F” key to start record the video 2. Movie Resolution Resolution setting: (1) 1920 x 1080(Full HD) (2) 1280 x 720(HD) -
Page 16: Datetime
3. Datetime Date and time setting (1) “D” “E” key to adjust time. (2) “A” “B” key to move the option 4. Audio Micphone voice recording setting (1) “D” “E” key to select function on or off... -
Page 17: Language
5. Language Language setting: Select option and press “B” key or “F” key to s et the language 6. TV AV out setting: (1)NTSC (2)PAL (3) “D” “E” key to select format... -
Page 18: About
7. About Verison information K12-Pro Specification SD card SD 卡，Support 32GB English、Korea、Simplified Chinese 、 Language Traditional Chinese Power Input：12-24V 50/60HZ Output：5V/1.5A AV out Voice, video out GPS(optional) External GPS antenna 500 Mega pixel CMOS SENSOR Camera 120 degree 2.4"TFT Operation... - Page 19 File system：FAT32 Format：MP4： Video 1920*1080,30FPS ( 10500Kbps avg.) 1280*720P,30FPS(5200Kbps) Video play System :PAL//NTSC...
