ACCU-STEAM GAS G2 GRIDDLE
WARNING
Improper installation, alteration,
adjustment,service, cleaning or maintenance
of this commercial appliance could result in
property damage, serious injury or death.
Read and understand the installation, operational,
maintenance instructions before installing,
servicing, or operating this commercial
appliance.
AccuTemp Products, Inc. · 8415 North Clinton Park · Fort Wayne, IN 46825 ·800 210-5907 · accutemp.net
SERVICE MANUAL
Record the serial number, model number (identification
decal located on the left side panel of the commercial
appliance) , voltage and the install date. Please have
this information when calling for assistance.
Serial Number:
Model:
Install Date:
NOTE
Advertisement
Table of Contents
Related Manuals for Accu-Steam G2
Summary of Contents for Accu-Steam G2
- Page 1 SERVICE MANUAL ACCU-STEAM GAS G2 GRIDDLE WARNING NOTE Improper installation, alteration, Record the serial number, model number (identification adjustment,service, cleaning or maintenance decal located on the left side panel of the commercial of this commercial appliance could result in appliance) , voltage and the install date. Please have property damage, serious injury or death.
- Page 2 Toll Free 800.480.0415 Office 260.469.3040 260.493.8914 Email service@accutemp.net Web Site www.accutemp.net Accu-Steam™ G2 Gas Service Manual PAGE 2 SP8042-1609...
- Page 3 Indicates a potentially hazardous situation; which, if unchanged, will result in minor or moderate injury. DANGEROUS VOLTAGE NOTE Advises the reader of information or EARTH GROUND instructions, vital to the operation or maintenance of the equipment. Accu-Steam™ G2 Gas Service Manual PAGE 3 SP8042-1609...
-
Page 4: Safety Precautions
Unplug equipment prior to removing any components effected by electricity. PERSONNEL INJURY HAZARD WHILE PICKING UP OR MOVING HEAVY EQUIPMENT. Always use at least 2 people and proper lifting techniques when picking-up, moving, or flipping-over heavy equipment. Accu-Steam™ G2 Gas Service Manual PAGE 4 SP8042-1609... - Page 5 Only QUALIFIED service technicians/electricians should perform the equipment installation, to ensure that all electrical and safety requirements are met; and that all wiring is performed in accordance with all national, state, and local electrical codes. Accu-Steam™ G2 Gas Service Manual PAGE 5 SP8042-1609...
- Page 6 WARNING & CAUTION NOTES WARNING ONLY QUALIFIED SERVICE TECHNICIANS SHOULD PERFORM MAINTENANCE ON THIS EQUIPMENT. CAUTION GRIDDLE MAY HAVE SHARP EDGES. Accu-Steam™ G2 Gas Service Manual PAGE 6 SP8042-1609...
-
Page 7: Table Of Contents
-Gas Valve ..........................-Ignition Control Module ......................-Flame Sensor ......................... -Igniter ............................. -Infrared Burner ........................-RTD Sensor(s) ........................Testing -RTD ............................-Flame Sense ........................... -Gas Pressure .......................... Preventative Maintenance ......................Schematic ..........................Warranty ..........................Accu-Steam™ G2 Gas Service Manual PAGE 7 SP8042-1609... -
Page 8: Sequence Of Operation
Sequence of Operation When the G2 griddle is plugged in, AC line voltage is supplied to the primary side of the transformer. The voltage out of the secondary side of the transformer is 24VAC nominal. Yellow and blue wires out of the transformer. -
Page 9: Specification Sheet
18. When the digital controller sees the resistance value for the set point temperature, it cuts power to the ignition control DC coil relay and breaks the connection to the ignition module causing the griddle to stop heating further. Griddle Specifications Sheet Accu-Steam™ G2 Gas Service Manual PAGE 9 SP8042-1609... -
Page 10: Troubleshooting Guide
ERROR CODE? ERROR CODE UNIT PLUGGED E001? HEAT LIGHT ON? E002? UNIT HEATING OVERTEMP? BREAKER ON? CHECK FAULT LIGHT PROPER INTERNAL FLASHING TEMPERATURE VOLTAGE UNIT CORRECT FAULT LIGHT ON OPERATING VOLTAGE NORMAL Accu-Steam™ G2 Gas Service Manual PAGE 10 SP8042-1609... - Page 11 Fault light If burners did not ignite, check gas pressure, cycle power. flashing If burners did ignite and unit is heating, check for poor connections in the harness at the fault timer relay. Accu-Steam™ G2 Gas Service Manual PAGE 11 SP8042-1609...
- Page 12 If display temperature is greater than 50 degrees different than measurement device, verify Temperature measurement device. If measurement device appears to be accurate, measure RTD. If RTD measures normally, replace temperature controller. If RTD measures out of specifications (temp/resistance), replace RTD. Accu-Steam™ G2 Gas Service Manual PAGE 12 SP8042-1609...
-
Page 13: Digital Controller
ON/OFF (S5) button and Temp (S6) button together for 8 seconds or until “LOC” is displayed. This will allow the cooks to only use the preferred settings. Accu-Steam™ G2 Gas Service Manual PAGE 13 SP8042-1609... - Page 14 To reset from any error, unit must be turned OFF, repaired, and then turned ON. When any error is displayed, outputs are forced open. The following chart illustrates the programming logic and program level indication: Accu-Steam™ G2 Gas Service Manual PAGE 14 SP8042-1609...
-
Page 15: Replaceable Components
Hi-Limit Board. This RTD is a 100Ω. (Red heat shrink sleeve for 100Ω identification) Heat Lamp 24v Red -Receives 24VAC power from the ignition module and AT0E-1800-2 indicates the valve is open. Accu-Steam™ G2 Gas Service Manual PAGE 15 SP8042-1609... -
Page 16: Parts Identification, Removal And Installation
2. Lower front access panel by removing the screws in the upper corners of the panel. 3. Take note of wire location 4. Remove wires and hardware securing relay. 5. Reinstall in reverse order. Accu-Steam™ G2 Gas Service Manual PAGE 16 SP8042-1609... -
Page 17: Control Board
3. Locate the Hi-Limit control board. Take note of wires and their terminals, remove wires. 4. Remove nuts and washers securing board to panel, remove panel. 5. Reinstall in reverse order. Accu-Steam™ G2 Gas Service Manual PAGE 17 SP8042-1609... -
Page 18: Transformer
3. Locate the Fault timer, take note of wire location and remove wires. 4. Remove hardware securing timer. 5. Remove timer. 6. Reinstall in reverse order. 7. Set timer pot to 6 seconds. Accu-Steam™ G2 Gas Service Manual PAGE 18 SP8042-1609... -
Page 19: Gas Valve
2. Lower front access panel by removing the screws in the upper corners of the panel. 3. Locate the module and remove wires. 4. Remove hardware securing module. 5. Remove module. 6. Reinstall in reverse order. Accu-Steam™ G2 Gas Service Manual PAGE 19 SP8042-1609... -
Page 20: Flame Sensor
6. Reinstall in reverse order. Note: When diagnosing a bad burner, often times the exterior back side of the burner will have black or gray discoloration in a circular or half moon shaped pattern. Accu-Steam™ G2 Gas Service Manual PAGE 20 SP8042-1609... -
Page 21: Rtd Sensor(S)
114.68 1146.82 156.91 1569.10 120.03 1200.38 162.08 1620.88 125.37 1253.72 167.24 1672.44 130.68 1306.84 172.37 1723.77 135.97 1359.74 177.48 1774.89 141.24 1412.41 182.57 1825.78 146.48 1464.86 187.64 1876.45 151.7 1517.09 192.68 1926.89 Accu-Steam™ G2 Gas Service Manual PAGE 21 SP8042-1609... -
Page 22: Flame Sense
AccuTemp gas equipment and are often the most neglected. Flame Sense The ACCU-STEAM G2 gas griddle has a flame sensing circuit to determine if the system has proper combustion. When the system is turned on gas is sent to the burner and an electronic ignition tries to ignite the griddle. -
Page 23: Gas Pressure
AccuTemp gas equipment and are often the most neglected. Gas Pressures The ACCU-STEAM G2 gas griddle requires the proper gas pressure setting to operate properly. All pressure readings should be taken after the unit has reached a temperature of at least 200°F and while it is running to ensure proper flow rates. -
Page 24: Preventative Maintenance
20 volts, if less than this replace transformer. NOTES: 1) AccuTemp-approved service providers should complete these PM tasks. Accu-Steam™ G2 Gas Service Manual PAGE 24 SP8042-1609 Note: Some information is not relevant for all appliances. - Page 25 AT2T-3912-1 120V-240V ACCU-STEAM G2 GAS GRIDDLE Accu-Steam™ G2 Gas Service Manual PAGE 25 SP8042-1609...
-
Page 26: Warranty
Improper installation can affect your warranty. Installation is the responsibility of the Dealer, Owner/ User or the Installation Contractor. See: Section One, Installation of the Owner s Manual. For Service Call 800-480-0415 or email: service@accutemp.net Accu-Steam™ G2 Gas Service Manual Accu-Steam™ G2 Electric Installation and Operators Manual PAGE 4 MP5018-1605 PAGE 26... - Page 27 NOTES ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ ____________________________________________ Accu-Steam™ G2 Gas Service Manual PAGE 27 SP8042-1609...
