Mounting Requirements

Bearing

You can choose the potable or wall mounting method according to your needs. Wall mounting can
substantially save the space.
If you choose portable mounting, use the mounting rack or support. If you want to use a self-made
mounting rack, the bearing capacity of the rack should be at last four times of the actual weight of
the display. The bearing capacity of the mounting support must be at least four times of the actual
weight of the display to ensure steadiness of the interactive panel.
When you choose wall mounting, the bearing capacity of the mounting surface must be at least four
times of the weight of the display. When the mounting surface is a wall or ceiling of a building, the
wall must be built with solid bricks, concrete or materials of equal intensity. If you need to mount
the display on a loose surface such as an old brick wall, wood plank wall, solid brick wall, metal or
non-metal structure wall, or a wall with a thick decoration layer, take necessary consolidating measu-
res to ensure that the display is steadily mounted.

Ventilation

Ventilation requirements
Nominal power
Larger than 100W
Note: If the product is mounted inside a wall or a cabinet, in addition to the above-mentioned requi-
rements, the area of ventilation holes at the bottom, top and two sides must be at least 50% of the
sealing surface to ensure proper ventilation.
6
Manual
Predia Touch Pro
Distance to the mounting surface (cm)
Left and right sides
10
Top
Bottom
20
20
Back
10
