- Page 1 Predia Touch Pro FHD/UHD User Manual www.predia.nl...
- Page 2 User Guide Predia Touch Pro FHD/UHD Welcome! Thanks for purchasing this product. Please read the instructions carefully before using this product. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
User Guide Predia Touch Pro FHD/UHD Contents Safety Instruction ..................................... 1. Installation Requirement ............................ 2. Intoduction ........................................3. Basic Operation ....................................3.1 Power on ................................................3.2 Power off ................................................3.3 Software Installation ......................................... 3.4 Software Uninstall ..........................................3.5 Software Positioning ......................................... - Page 4 User Guide Predia Touch Pro FHD/UHD 10. Multimedia Format Support ......................11. Common Faults and Solutions ....................12. Care and Maintenance ............................13. Technical Parameters ............................
-
Page 5: Safety Instruction
User Guide Predia Touch Pro FHD/UHD Safety Instruction For your safety, please read the following instruction before you use the product. Serious injury or property loss may be caused by improper operations. Do not try to repair the product by your own. - Page 6 User Guide Predia Touch Pro FHD/UHD • Do not install and use new battery together with the used one. • Take out the battery if the remote control is not used for a long period. • Do not expose the battery under overheated environments such as sunlight and firing.
- Page 7 User Guide Predia Touch Pro FHD/UHD • Do not install the product on a carpet or bed clothes. • Do not use a cloth such as table cloth to cover the product. Do not touch the power cable with wet hands to avoid electric shock.
-
Page 8: Installation Requirement
User Guide Predia Touch Pro FHD/UHD 1. Installation Requirement Bearing You can choose the portable or a wall-mounting method according to your needs. The wall mounting can substantially save the space. If you choose portable mounting, use the mounting rack or support. If you want to use a selfmade mounting rack, the bearing capacity of the rack should be at last four times of the display weight. - Page 9 User Guide Predia Touch Pro FHD/UHD NOTE • When you install by wall mounting method, ensure insert the screws into the wall deeper than 10mm. • Do not block ventilation vents. • Reference to the CAS 132-2006 • The dimension of the 4 bracket mounting holes in the back panel is VESA MIS-F compliant (400 x 400mm).
-
Page 10: Intoduction
User Guide Predia Touch Pro FHD/UHD 2. Introduction Thank you for choosing our interactive display. As our latest independently developed and pro- duced human-machine interactive product, the interactive display is a multi-functional display for interactive teaching, digital demonstration, multi-media presentation, touch operations and handwriting. - Page 11 User Guide Predia Touch Pro FHD/UHD Outer Appearance The front view and back view of the product are displayed as follows. For 65" / 70": 12 13...
- Page 12 User Guide Predia Touch Pro FHD/UHD For 75" / 80" / 86": Name Name Enclosure Power on/off Infrared Frame Right Loudspeaker Screen OPS Port Left Loudspeaker Connection Panel 2 Connection Panel 1 Rocker Switch Control Panel Power Outlet Front Cover Plate*...
-
Page 13: Control Panel
User Guide Predia Touch Pro FHD/UHD Control Panel Name Function Description Home Enter/Exit Android home page. Return Return to previous menu. Menu Enter the function menu of screen. Switch among three modes: energy-saving, automatic, and standard. Source Enter the menu to select the signal source. - Page 14 User Guide Predia Touch Pro FHD/UHD Connection Panel 1 Name Function Description Touch Port 1 PC connecting port 1 for touch control. Display Port HD digital display port. HDMI 1 The input terminal 1 for high definition signal, which is used with the Touch Port 1 to operate PC in the way of touch control.
- Page 15 User Guide Predia Touch Pro FHD/UHD Connection Panel 2 Name Function Description Audio Audio input port. The VGA port for an external PC, which is used with the Touch Port 4 to opera- te PC in the way of touch control.
- Page 16 User Guide Predia Touch Pro FHD/UHD Connection Panel 3 Name Function Description Earphone The port for earphone. SPDIF Audio digital output port RS-232 The input port for series signals, which is used by specific control device of serial port to input serial port protocol in order to control the display.
- Page 17 User Guide Predia Touch Pro FHD/UHD On or standby Mute 3. 0--9: Select TV channel or enter number Open the Android home page. Go back or return to the parent menu. Show or hide menu. Show or exit from the list of signal sources.
- Page 18 User Guide Predia Touch Pro FHD/UHD Instructions of Remote Controller The effective area of the remote controller includes the vertical distance within five meters in front of the product, and the area within an angle of 30 degrees from the vertical point to the left and the right.
-
Page 19: Basic Operation
User Guide Predia Touch Pro FHD/UHD 3. Basic Operation 3.1 Power on Step 2 Turn on the interactive display with the 100V-240V 50Hz/60Hz AC power supply. The power cord should be completely plugged into the power outlet, and insert the power connector into the appliance couplers at the bottom side. - Page 20 User Guide Predia Touch Pro FHD/UHD Step 3 Connect the display to the power supply. Switch on the rocker switch (on the right bottom of the rear of the display, next to the power port) to enter the standby status. The power indicator turns red.
-
Page 21: Power Off
User Guide Predia Touch Pro FHD/UHD Step 4 Press power switch on the control panel or Power on the remote controller to turn on the interactive display. The OPS is boot. The power indicator turns green. Power switch (on the front panel) 3.2 Power off... -
Page 22: Software Installation
User Guide Predia Touch Pro FHD/UHD 3.3 Software Installation • Recommended configuration: - CPU: Inter (R) Core i3 2.27GHz or AMD CPU with equivalent performance and above - Memory: 1GB - Hard drive: 1GB - Graphics card: supports DirectX 9 or above •... -
Page 23: Software Positioning
User Guide Predia Touch Pro FHD/UHD 3.5 Software Positioning To work normally, the handwriting of the projected image on the touch LED display should coincide with the actual one to calibrate accurately. The following situations need calibration. • The first time to use the interactive handwriting LED. -
Page 24: Positioning Method For Windows 7 System
User Guide Predia Touch Pro FHD/UHD Step 15 Use the pen to click and hold the center of the flickering cross. Do not release it until the flickering cross moves to the next point. Repeat and complete the positioning process according to the instructions on the interface. - Page 25 User Guide Predia Touch Pro FHD/UHD Step 18 Click Calibrate in Tablet PC Settings window. Step 19 Use the pen to click and hold the center of the flickering cross. Do not release it until the flickering cross moves to the next point. Repeat and complete the positioning process...
-
Page 26: Ops Installation
User Guide Predia Touch Pro FHD/UHD Step 20 Click Yes after the calibration is completed. • To ensure the handwriting accuracy, use the pen provided together with the interactive display rather than a finger to perform calibration. • Positioning errors may cause touch function failure on the interactive display. In this case, you need to perform positioning one more time. -
Page 27: Toolbar Introduction
User Guide Predia Touch Pro FHD/UHD 4. Toolbar Introduction The toolbar has three modes: Home Page, Task Manager, and Whiteboard. Under any of the three modes, you can click on the toolbar to go back to the previous page and click to exit from other programs or go back to the home page from other signal sources. -
Page 28: Task Manager
User Guide Predia Touch Pro FHD/UHD 4.1 Task Manager In the task manager, you can view current running programs, switch and end programs. Click to enter the task manager as shown in the following figure: View Running Programs In the task manager, scroll up and down to view the current running programs. -
Page 29: Whiteboard
User Guide Predia Touch Pro FHD/UHD 4.2 Whiteboard The whiteboard provides the writing function. In the whiteboard program, you can select a pen, line weight and color to write and use an eraser to erase content on the whiteboard. You can also print and clear the content on the whiteboard. - Page 30 User Guide Predia Touch Pro FHD/UHD Click Settings to set the color and shade of the whiteboard, as shown in the following figure: Pen, Line Weight and Color If the marker is selected, click and hold for two seconds to set its line weight and color.
- Page 31 User Guide Predia Touch Pro FHD/UHD Eraser Two methods are available to erase written errors or content as follows: • Click to select the eraser, and then you can use it to erase the content on the whiteboard. • Use five fingers to touch the screen and a circle is displayed indicating the scope for erasing.
-
Page 32: Gallery
User Guide Predia Touch Pro FHD/UHD 4.3 Gallery You can enter the gallery to view images one by one or play them as slides. Click in the application programs to enter the gallery. All folders containing images are displayed. •... -
Page 33: File Manager
User Guide Predia Touch Pro FHD/UHD • View images one by one Click one image in a folder. Scroll left to show the previous image and scroll right to show the next image. • Play slides on the upper right corner of the folder and select Slideshow to play images as slides. -
Page 34: System Settings
User Guide Predia Touch Pro FHD/UHD 4.5 System Settings Click on the toolbar to enter the system settings interface. The Network, Apps, Language & input, Date & time, Energy Saving, Switch machine Settings, Clear screen shots, Printing, Permis- sions Settings, Smart eye protection, Source Settings, Background setting and... -
Page 35: Audio Only
User Guide Predia Touch Pro FHD/UHD 4.7 Audio Only Press AUDIO ONLY on the remote controller to turn off the screen but keep audio on. To turn on screen again, touch any place on screen or click AUDIO ONLY again to return to normal operation mode. -
Page 36: Application Programs
User Guide Predia Touch Pro FHD/UHD 4.9 Application Programs Click on the toolbar to enter the application program page. All application programs in the system are displayed. Scroll right and left to turn the page, as shown in the following figure:... - Page 37 User Guide Predia Touch Pro FHD/UHD Calculator Click to enter the calculator application. Click digits and operators on the keyboard to perform calculation. Calculator Click to start the music program. The music in the local disk is displayed by artists, albums,...
-
Page 38: Temperature Reminder And Thermal Shutdown
User Guide Predia Touch Pro FHD/UHD 4.10 Temperature Reminder and Thermal Shutdown Temperature Reminder The real-time temperature of the interactive display is displayed on upper left corner of the home page. Click the temperature display area on the top-left corner of screen to switch between Celsius and Fahrenheit. -
Page 39: Signal Source Selection
User Guide Predia Touch Pro FHD/UHD 5. Signal Source Selection The following three ways are used to select a signal source: • Press SOURCE on the remote controller. • Press Source on the control panel of the interactive display. •... -
Page 40: Menu
User Guide Predia Touch Pro FHD/UHD 6. Menu After switching to selected signal source, press MENU on the remote controller. A menu is display- ed, including Sound Mode, Screen Setting, and Display setting. Scroll left and right on the screen or press to switch between entries. - Page 41 User Guide Predia Touch Pro FHD/UHD Screen Setting The Screen Setting page displays options including Auto, P2P, 16:9 and 4:3. Two ways are used to set the options: • Click an icon and set the option. • and press OK to modify the option. Press RETURN to exit the menu.
- Page 42 User Guide Predia Touch Pro FHD/UHD Under VGA signal source, Auto mode cannot use. • Display Setting The Display setting page displays options including STANDARD, LIGHTNESS, VIVID and EYE PRO- TECTION. Two ways are used to set the options: •...
-
Page 43: Eco Mode
User Guide Predia Touch Pro FHD/UHD 7. ECO Mode Caution • Please switch off the display when it is not used, and enable the function of Audio Only when you do not need to watch the display, helping to reduce power consumption and save energy. -
Page 44: Serial Port Control
User Guide Predia Touch Pro FHD/UHD 8. Serial Port Control The RS-232 port of the interactive display is defined as follows: Connect RS-232 port to the PC or controlling device. Enable RS-232 serial port connection and complete the following configuration. - Page 45 User Guide Predia Touch Pro FHD/UHD Function Controlling Code Function Controlling Code ← HDMI 4 7F 08 99 A2 B3 C4 02 FF 01 51 CF 7F 08 99 A2 B3 C4 02 FF 01 2C CF → 7F 08 99 A2 B3 C4 02 FF 01 56 CF 7F 08 99 A2 B3 C4 02 FF 01 2D CF ↑...
-
Page 46: Vga Signal Input
User Guide Predia Touch Pro FHD/UHD 9. VGA Signal Input VGA (Video Graphics Array) is the computer display standard for analog signal. VGA port is the special port on the computer which uses the VGA standard for data input. The following table lists the specifications of various VGA signal input. -
Page 47: Multimedia Format Support
User Guide Predia Touch Pro FHD/UHD 10. Multimedia Format Support Media Type File Format File Extension Image JPEG, BMP, PNG .jpg, .bmp, .png Movie MPEG1, MPEG2, MPEG4, H.264, .avi, mpg, .dat, .vob, .div, H.265, RM, RMVB, MOV, MJPEG, .mov, .mkv,.rm, .rmvb, .mp4, VC1, DivX, FLV (Support 1080P, 4K .ts, .trp, .asf, .flv... -
Page 48: Common Faults And Solutions
User Guide Predia Touch Pro FHD/UHD 11. Common Faults & Solutions Symptom Possible Cause Solution The service The drive program is not Install the drive program correctly. program fails to be correctly installed. connected. The USB port (lead) is not Change the USB lead or check if the connected or is faulty. - Page 49 User Guide Predia Touch Pro FHD/UHD Symptom Possible Cause Solution The handwriting The color of the pen is the Change the color of the pen. cannot be shown or same as or similar to the no touch signal is background color.
- Page 50 User Guide Predia Touch Pro FHD/UHD Symptom Possible Cause Solution • The image or sound Find out the electric appliance that causes the interference and move it is interrupted. away from the interactive display. • Do not share the power socket of the display with the electric appliance that causes interference.
-
Page 51: Care And Maintenance
User Guide Predia Touch Pro FHD/UHD 12. Care and Maintenance Maintenance Tips • Do not put or install the product near a heat source or under direct sunlight, or in dusty or humid places, or somewhere the product may be hit or damaged by mechanical vibration. To maximize the performance, it needs to be put away from equipment such as grid, large metal objects and radar stations as far as possible. -
Page 52: Technical Parameters
User Guide Predia Touch Pro FHD/UHD 13. Technical Parameters Specification Parameter Backlight Type Aspect Ratio 16:9 Physical Resolution 3840x2160 Pixel (4K)/ 1920x1080 (2K) Viewing Angle 178° Display Colors 10bit LCD Brightness 370cd/m Contrast Ratio (Typical) 4000:1 Response Time (Typical) Viewing Angle 178°... - Page 53 User Guide Predia Touch Pro FHD/UHD Specification Parameter Multimedia File Formats Support Image: JPEG, BMP, PNG Video: MPEG1, MPEG2, MPEG4, H.264, H.265, RM, RMVB, MOV, MJPEG, VC1, DivX, FLV (Support 1080P, 4K HD Decoding) Audio: MP3, M4A, (AAC) Speaker Position...
