Summary of Contents for DAITEM 230-21X
- Page 2 If the user does access these parts, the product guarantee will be considered null and void and DAITEM shall not be held responsible for any problems. Touching the siren’s internal parts and/or electronic components can damage the product. Furthermore, the siren is designed in such a way that these parts and components do not need to be accessed for operation or maintenance purposes.
- Page 3 (press on the control panel keypad to check the version). • The operating differences with former ranges are described in the compatibility booklet available in the Daitem installers section at www.daitem.co.uk. The external universal transmitter is fitted with: Test button Terminal block n°...
- Page 4 1.3 Technical detector type applications: terminal block n° 1 applications: terminal block n° 2 • Door and window detector: using a Using a Daitem technical sensor normally closed contact (surface (household technical detectors operate mounted, flush-mounted, wide gap, etc.). around the clock as they do not depend on •...
- Page 5 4 application examples are given below. Example 1: gate/side door opening Example 2: flooding detected by Daitem detection (using terminal block n° 1). technical probe (using terminal block n° 2) wide gap normally closed contact Example 3: peripheral detection based Example 4: person’s weight detected by...
- Page 6 2. Preparation Power supply 1. Remove the cover. 2. Insert the detector cable • The lithium battery pack is clipped into place (see photo in the cable gland. below). 3. Insert the cable through • An alignment arrow on the lithium battery pack shows the opening in the base which way to connect it.
- Page 7 3. Default configuration 4. Apprentissage The external universal transmitter is IMPORTANT: during recognition program - factory-configured for use with terminal ming, the product to be programmed for use block n° 1. with the control panel does not need to be placed next to it.
- Page 8 2. Carry out the programming sequence described below: 1. Press then 2. Press & hold 3. The control panel 4. The control panel waits for 5. The control on the control panel the “Test” waits for a group the time delay to be chosen: panel confirms keypad to move to button until...
- Page 9 5. Advanced configuration operations 5.1 How is a loop configured? Choose whether the loop is used for a detector or a system control type application Detector type application System control type application Choose the sensor type Choose the contact type Choose the order sent Choose the detector type when the loop is activated...
- Page 10 5.2 Configurations for a system control type application Configuration type Parameter Configuration options Parameter Configuration options Parameter value (cont.) value 1/ Type of NO monostable command OFF Group 12 3 external NC monostable command OFF Group contact(s) NO bistable command OFF Group NC bistable command OFF Group...
- Page 11 Roller blind/shutter detector Roller blind/shutter detector Fire detector Fire detector Technical detector SONIN Daitem flood detector SONCS Daitem mains power failure detector SONPC Daitem freezer breakdown detector SONHG Daitem freeze detector 3/ 90 sec. Disabled No inhibition inhibition...
- Page 12 5.4 To be filled in according to the application(s) to be performed Application Parameter n° Parameter value Configuration sequence LED indicator lamp ON LED indicator approx. lamp OFF approx. 10 sec. 5 sec. approx. 10 sec. approx. sec. sec. digit digit digit 2 sec.
- Page 13 Configuration example: configuring the universal transmitter for a technical detector application (see table on page 141). approx. 1 sec. 2 sec. Start Press once Press once then Press once to select the to confirm 3 times to select parameter selection the parameter number value (1 3)
- Page 14 6. Connection 6.1 Connection terminal blocks IMPORTANT: disconnect the battery before Terminal blocks n° 1 and n° 2 each have 3 terminals. connecting the terminal blocks. Terminal block n° 2: special connection with polarising Terminal block n° 1: slot to limit risk standard connection of pole reversal...
- Page 15 6.2 Connecting several types of external contact • Series-wired NC contacts: Max. loop length: 10 m - surface or flush-mounted normally NO/NC closed contacts, - glassbreak sensor (piezo-electric), - shock sensor, 5 series contacts max. - other non-specific sensors. Max. loop length: 10 m •...
- Page 16 7. Installation 7.1 Fixing the external universal transmitter IMPORTANT Fixing method: • Make sure there is a 1. position the casing distance of at least with the cable gland 2 meters between each product, except between facing downwards, two detectors. 2.
- Page 17 7.2 Fixing and connecting the external contact(s) Flush or surface-mounted encapsulated • Surface mounting (NC): contact and cable normally closed contact magnet to be screw-fixed and aligned (using spacers if necessary) • NC loop with anti-tamper protection against loop cutting: •...
- Page 18 Surface-mounted contact Magnet position contact Cover magnet magnet base screw-fixed Possible magnet Incorrect magnet to door positions positions Contact shims Normally closed ground contact Base Magnet to be screw- screw-fixed fixed to 5 mm max. to door doorframe Contact 60 mm max. to be screw-fixed to doorframe Surface-mounted screw contact...
- Page 19 7.3 Fixing the technical probes Each probe is connected to the external Depending on the customer’s needs the universal transmitter by a flat connecting probe can be positioned vertically or cable (1.2 m long). The cable must be horizontally on the ground to detect a pulled taut when each probe is fixed.
- Page 20 For vertically-fixed probes, the metal plate REEZER BREAKDOWN PROBE fixing hole must be placed high up. Probe. Connecting cable. Bushing. Œ Ž • To detect a water level of 2 mm, the Bushing groove. Freezer seals. bottom of the plate must be fixed 1 to 2 cm from the ground.
- Page 21 The freeze probe measures temperature in REEZE PROBE Inside wall. Metal plate. Dowel. its close environment. Œ Ž Screw. Shelf. Probe. Magnet. We recommend you place this probe more ‘ ’ than 1.5 m above ground level (fixed to an inside wall or placed on a shelf) but out of the way of draughts.
- Page 22 AINS POWER FAILURE PROBE Multi-socket. Device to be protected. Wall socket. Œ Ž Connecting cable. Time switch. Switch set for ‘ 5 hours. Switch set for 18 minutes. ’ Œ ‘ Œ ’ Ž ...
- Page 23 8. Operating test Connect the lithium battery pack. Testing the loop 8.1 Testing the power supply “beep, test, detector X, group Y, immediate (or delayed Press the test button once to check that or combined)” the battery is working properly. The LED indicator lamp should light up red.
- Page 24 8.3 Testing the loop (example: 8.4 Testing the Daitem technical gate/side door opening probes detector) 8.4.1 Simulate the following incidents in the home: The LED indicator lamp comes on each • flooding: immerse the 2 probe contacts. time the loop is activated.
- Page 25 8.4.2 Put the probe back in its final 9. Maintenance position: • flooding: wipe the probe and put it back 9.1 Changing the battery on its metal plate, To change the battery: • freezer breakdown: put the probe back 1. put the control panel in installation in the freezer.
- Page 26 • The lithium battery pack must be replaced by the same type of pack with the same technical characteristics, i.e. (3.6 V - 4 Ah). • We advise you to use the DAITEM BatLi25 pack available in the catalogue in order to guarantee individual safety and equipment reliability.
- Page 27 Connection terminal block for technical probe terminal block n° 2 Maximum number of external contacts (terminal block n° 1) Maximum length of connection loop 10 m outdoor Power supply DAITEM 3.6 V lithium battery pack Battery life 5 years Radio links TwinBand 400/800 MHz ®...
