additional potential siphon lock
in the system.
8.3 Thorough cleaning
Undo the seven securing clips
and gently remove the lid (If
there is any difficulty, insert a
coin into the slot provided and
turn gently). Gently remove the
foam from the filter vessel and
squeeze out the dirt. Using the
water in the filter, rinse out each
foam in turn using a sponge
action and squeeze the dirty
water outside the filter vessel.
Reposition the clean foam(s)-
ensuring they lie flat. It may help
to remove some of the water
from the vessel.
Refit the lid, making sure the
seal is in position and free of dirt
and debris. Add a light coating
of silicone grease to the seal if
required to aid assembly. Re-
engage the seven securing clips,
ensuring all are firmly in place,
and retighten the viewing lens.
8.4 Back-Flush cleaning
It is possible to increase the
interval between thorough
cleans by back flushing the
Bioforce filter. This is simply
achieved by swapping over the
inlet and outlet pipes or
connecting a separate waste pipe
to the Bioforce inlet and
switching the pump back on.
Note: Ensure that the return pipe
is not left in the pond but is
allowed to go to waste. Swap
the pipes back over once water
from the filter runs clear (about
30 seconds).
8.5 Normally, there is no need to
remove the foam support plate.
However, if you need to access
the biomedia, remove the
support plate by lifting it clear of
Filter Equipment Selection Chart.
Chart for guidance only. Based upon 4m length Cypriflex, 1 metre static lift from pond water level.
Model
Bioforce 3000UVC
Bioforce 5500UVC
Bioforce 8000UVC
Based on maximum fish stocking levels as described in Section 6.
*
9. CARE OF THE UV QUARTZ
TUBE
9.1 Especially in hard water areas
10. WINTER STORAGE
10.1 IMPORTANT: When not in use,
11. CLEARWATER
GUARANTEE
■ You have followed the
■ You are using equipment of the
Max Pond
Max Pond
Size*
Size
(with fish)
(without fish)
Litres (gallons)
Litres (gallons)
3000 (650)
6000 (1300)
5500 (1200)
11000 (2400)
8000 (1700)
16000 (3400)
the vessel (See fig.6). Make sure
you refit the support plate
correctly, so that the bio media is
not released.
the quartz sleeve sheathing the
UVC lamp may become covered
in lime scale. This will reduce the
efficiency of the unit if it is
allowed to build up. To clean,
switch off the pump and the
power supply to the UV, remove
the lid and central tube, as
described in note 2.1, and wipe
the quartz tube with a soft cloth
moistened with a gentle
cleaning agent such as vinegar
(See fig 7). The maximum life of
a lamp is 12 months continuous
use. Replace the lamp after this
time, even though it may still
glow.
the unit should be removed,
thoroughly washed and
cleaned, dried and stored in a
dry frost protected area.
Always store the unit with the
lid off to ensure adequate
ventilation and drying.
WE GUARANTEE YOU
CLEARWATER OR YOUR MONEY
BACK. This guarantee runs for 12
months after purchase, provided
that:
installation and operating
instructions;
correct size, according to the
Max Flow rate
Recommended Recommended
/Hour
Hose Internal
dia, mm (inch)
Litres (gallons)
2000 (440)
20mm (
minimum
3000 (660)
25mm (1")
5500 (1200)
25mm (1")
pond sizing chart
■ You consult our help line (0121
313 1122) early enough for any
problems to be put right
■ The product has been returned
undamaged
A refund can only be authorized by
Hozelock Cyprio and is made at the
place of purchase.
Please note that the Clearwater
Guarantee does not cover loss of
water clarity when blanketweed, as
opposed to greenwater algae, is the
cause.
12. HOZELOCK CYPRIO 2
YEAR PRODUCT
GUARANTEE
If this filter, excluding the UV lamp
and foams, becomes unserviceable
within 2 years of the date of
purchase it will be repaired or
replaced at our option free of
charge, unless in our opinion it has
been damaged or misused.
Liability is not accepted for damage
due to accident, improper
installation or use. Liability is
limited to replacement of a faulty
filter. This guarantee is not
transferable. It does not affect your
statutory rights.
To obtain the benefits of the
guarantee, firstly contact Hozelock
Cyprio Consumer Services who may
request that the filter is sent along
with proof of purchase directly to
the address below.
Hozelock Cyprio
Midpoint Park
Birmingham
B76 1AB
England
www.hozelock.com
Hozelock Cyprio
Pump
3
⁄
")
Titan 2000
4
Titan 3000
Titan 5500
