- Page 1 SMT 100 SOLAR CONTROLLER www.Thermomax.com...
-
Page 2: Table Of Contents
2.3.1 - A One Pump System ...…………..………………..… 5 2.3.2 - Two Pump Cascade System ……………..………... 6 2.3.3 - Normal AUX Heat Extraction ……………..…….…... 7 SECTION 3 - SMT 100 OPERATION / FUNCTION ..........…... 9 3.1 - Description .………………………………....………………….. 9 3.1.1 - Display Select Indicators ……………………………….. 9 3.1.2 - Temperature Display …………………..……...…………. -
Page 3: Section 1 - Introduction
SECTION 1 INTRODUCTION The SMT 100 is a multi-functional integrated unit providing complete control for the solar heating system. By using microprocessor technology it ensures that the collected energy from the sun is transferred efficiently and harnessed under optimum conditions, while providing valuable information with clarity and ease of use for the user. -
Page 4: Section 2 - Installation / Application
Do not exceed unit ratings as shown on the ratings label. It is advisable to route mains cables away from low voltage or sensor cables. SMT 100 UNIT NOTE: For viewing comfort, the control box should be positioned at eye level. -
Page 5: Sensors
Note: If the outputs from the Auxiliary relay are required to drive a heater with a current rating greater than 3A then a contactor should be used. Thermomax can supply an intermediate device, which may be connected to the SMT 100 to drive an auxiliary load of up to 16A - Part No: C0328. -
Page 6: A One Pump System
TT, the AUX. relay is energised, and when rises above TT, the AUX. relay is de-energised (see SMT 100 Diagram). Connect the output terminal of the AUX. relay to the auxiliary heater or to a contactor (external relay) if the heater has a greater current rating than 3A. -
Page 7: Two Pump Cascade System
2.3.2 TWO PUMP CASCADE SYSTEM In this configuration will run when the tank temperature is below the set point TT, and Pump will run (Pump will switch off) when rises above TT. Insert a link between “L” terminal of the PUMP relay and the common terminal “C”... -
Page 8: Normal Aux Heat Extraction
2.3.3 NORMAL AUX HEAT EXTRACTION When < TC: = OFF; = OFF When > TC < TT: : = ON; = OFF > > TT: : = ON; = ON Extracting excess heat or diverting excess heat. - Page 9 Thermomax can supply an intermediate device, which may be connected to the SMT 100 to drive an auxiliary load of up to 16A – Part No. C0328. Example of a solar hot water system gas or oil auxiliary heating. Logic as 1 above.
-
Page 10: Section 3 - Smt 100 Operation / Function
SECTION 3 SMT 100 OPERATION In order to understand the operation of the SMT 100 this section should be read carefully. DESCRIPTION DISPLAY SELECT TEMPERATURE INDICATORS DISPLAY DISPLAY TEMPERATURE SET FROST PUMP STATE SELECT INCREASE / DECREASE PROTECTION INDICATOR SWITCHES... -
Page 11: Temperature Display
3.2.2 AUXILIARY OPERATION: In the normal mode of operation, the SMT 100 provides the facility, which allows the solar controller to either operate an auxiliary heater for boosting the temperature, or to divert surplus heat to another circuit. This function is... -
Page 12: Frost Protection
TF. To adjust TF, see section 3.3.7. 3.2.4 STORAGE TANK LIMIT TEMPERATURE: The SMT 100 has a useful feature to allow maximum temperature from solar to be limited inside the storage tank (cylinder). The controller can switch off the circulation pump if the stored temperature reaches TS (90°C default). -
Page 13: Setting The Temperature
3.3.6 SETTING THE TEMPERATURE Press the key until the selector lamp is illuminated, then press the keys to set the Delta T (minimum 4°C, maximum +20°C). 3.3.7 Setting the Frost Protection temperature / Storage Tank Limit Temperature Note that the unit must be in PROGRAMMING MODE, (keypad lock disabled) in order to change both values. -
Page 14: Manual Pump Override
3.4.2 MANUAL PUMP OVERRIDE The Pump can be manually switched ON at any time by pressing both the keys together. On release of the keys, the pump will switch to its s previous state. Note that the unit must be in DISPLAY mode for this function to work. -
Page 15: Section 4 - Fault Finding
SECTION 4 - FAULT FINDING Problem: Nothing happens when the unit is powered-up. Cause / Remedy: One of the fuses could be blown - check and replace if necessary (refer to specifications for values). If the fuse blows again, contact the agent where the unit was purchased. Problem: The temperature display is fluctuating. -
Page 16: Section 5 Specifications
Thermomax certifies that this datalogging and / or control device has been manufactured to an ISO 9002 Quality System. Thermomax undertakes to repair or replace the device, if same is shown to be defective in its manufacture and / or components, but Thermomax shall not be responsible for any other financial or economic loss (or any indirect loss) which may be incurred by the buyer / customer or others in the use of the device.
