Page 1: Installation Guide
AT- 4 Installation guide Part number: 103161 2010-04-30 ver #: 1.00 FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 1 of 25... -
Page 2: Table Of Contents
SELECTING THE FREQUENCIES............22 READING RANGE (SENSITIVITY) ............23 PRINCIPLE .................... 23 ADJUSTING THE READING RANGE ............ 23 TECHNICAL SPECIFICATIONS ..............24 PART NUMBERS .................. 25 FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 2 of 25... -
Page 3: Introduction
The system has been developed to read a transponder at a distance of 4 meters in a reliable manner. FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 3 of 25... -
Page 4: Installation
Before removing or installing the parts, always disconnect the power supply. Do not modify or add components to the AT-4, if not indicated by the manufacturer or by FAAC, in order not to jeopardize the compliance of the system with the safety requirements. -
Page 5: Adjustable Mounting Bracket
AT-4 2.3 ADJUSTABLE MOUNTING BRACKET The AT-4 can be oriented into the required detection area thanks to the adjustable mounting bracket. The mounting bracket can be fixed to square round posts. Fig. 2: Adjustable Mounting Bracket The bracket can also be wall-mounted. -
Page 6: Opening The Service Cover
Make sure that the screws are completely loose (or tightened when the cover is closed again). The screws are inserted inside the plastic structure – in this way they cannot be lost. FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 6 of 25... -
Page 7: Connections
AT-4 3 CONNECTIONS 3.1 FASTENING THE CABLES The cables of the AT-4 are connected using EMC type cable glands. Use a shielded cable for the power supply. Mounting instructions: 1. Fit the nut (1), the seal (2) and the cable gland (3) on the cable. -
Page 8: Connections
AT-4 3.2 CONNECTIONS The cables inside the AT-4 are connected by means of connectors with spring terminals which make for an easy and intuitive use. 1. Remove the sheath from the cable for approx. 9 mm ( 0.35 inch screwdriver 2. -
Page 9: Power Supply
AT-4 3.3 POWER SUPPLY AT-4 requires a DC 12 – 24V power supply. The max. current consumption is 1A @ 12VDC, 0.5A @ 24VDC. Connections: 12 - 24VDC. Note: The electrical connection is protected by means of a self-resetting fuse. -
Page 10: Communications
Note 2: Activate the RS232 interface by setting the DIP-switches SW1-2 to ON. See chapter 5.2 for further details. Fig. 9: RS232 wiring FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 10 of 25... -
Page 11: Wiegand, Magstripe, Barcode Connection
Data-0 (green) Clock OUT3 Data-1 (white) Data Data Ground (black) Ground Ground Note: Cable max. length 150 meters CLOCK DATA Fig. 10: MAGSTRIPE wiring FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 11 of 25... -
Page 12: Digital I/O
Normally closed contact Common contact Normally open contact Operation of the contacts: Max. current: Max. voltage: 24VDC Consumption: Contact Power supply Fig. 11: Relay output FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 12 of 25... -
Page 13: Disabled Reading
AT-4 3.5.2 DISABLED READING AT-4 reading can be completely disabled by means of the RDIS input. This input is commonly used together with a sensor (e.g. with a magnetic loop) that detects the presence of a vehicle. Use a voltage-free contact to connect the 5V to the RDIS input. -
Page 14: Tamper Switch
Tamper (common contact) Operation of the contacts: Max. current 50 mA (0.5 Volt voltage drop) Voltage +24 VDC Tamper Fig. 13: Tamper switch FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 14 of 25... -
Page 15: Diagrams Of Connections To Equipment
AT-4 4 DIAGRAMS OF CONNECTIONS TO EQUIPMENT 4.1 CONNECTION TO ACCESS CONTROL Perform the connection between the terminal K2 of the AT-4 reader and the terminal M1 or M2 of the Cobra board. Cobra (M1/M2) Out2 D0-C Out3 D1-D Table 1: connection between terminals Fig. -
Page 16: Connection To Parklite
AT-4 4.2 CONNECTION TO PARKLITE In order to connect the AT-4 reader, you need to disconnect the wiring between the Plite Board and the Pratic 503 Board already existing inside the column. Fig. 15: Internal wiring between Cobra Plite and Pratic 503 FAAC S.p.A. - Page 17 Use a Mixer board and perform the connections according to the diagram below. Parklite Column Mixer board AT-4 Reader Fig. 16: Connection to Parklite FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 17 of 25...
- Page 18 Mixer (J2) Cobra (M1) +12V D1-D D0-C Mixer (J1) AT4 (K2) AT-4 (K3) TD/TR interface RDIS OUT3 OUT2 Table 2: connection between terminals FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 18 of 25...
-
Page 19: Connection To Paragon
AT-4 4.3 CONNECTION TO PARAGON Perform the connection between the terminal K3 of the AT-4 reader and the terminal J96 of the Paragon terminal power board. Fig. 17: Connection to Paragon AT-4 (K3) Power board (J96) RDIS Table 3: connection between terminals FAAC S.p.A. -
Page 20: Setting The Dip-Switches
RS232 interface enabled. RS422 interface enabled. 5.3 SW1-3 SW1-4 The switches SW1-3 and SW1-4 are provided for reserved applications. Please leave them on ON. FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 20 of 25... -
Page 21: Led Description
Power voltage too low. DC-FAIL Internal power missing. T-CRIT Temperature too high. PLL UL PLL released. Try to change frequency. Table 4: LED indications FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 21 of 25... -
Page 22: Selecting The Frequencies
AT-4 7 SELECTING THE FREQUENCIES The AT-4 reader operates in the frequency band of 2.45GHz. When two or more readers are within a 15 m radius, they should be set to different operating frequencies. The selected frequency must observe the local radio regulations. -
Page 23: Reading Range (Sensitivity)
8 READING RANGE (SENSITIVITY) 8.1 PRINCIPLE The reading range of AT-4 can be controlled by the built-in sensitivity function. When the power of the received signal is below the sensitivity level, no identification is possible. The power of the received signal becomes higher when the transponder comes close to the reader. -
Page 24: Technical Specifications
IEC 68-2-29 Eb 25 G, 6 ms, 1000x3 dir 5 – 150Hz, 5 G, 20 Random vibration EN 50155 sweeps x 3 dir FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 24 of 25... -
Page 25: Apart Numbers
TRANSPONDERS Compact Tag 403153 part number: Window Button 786341 part number: Prox Booster 786347 part number: Proximity Card 786334 part number: FAAC S.p.A. Via Calari, 10 – 40069 – Zola Predosa (BO) - Italy Page 25 of 25...
