TransTel Communications, Inc.
1095 Jupiter Park Drive, Suite 7
Jupiter, FL 33458
http://www.transtelcommunications.com
Phone 561-747-4466
©2000 TransTel
TMS-100 Plug-N-Play
For
SK-824 Electronic
Telephone System
Installation - Quick Reference Guide
TransTel Communications, Inc
Advertisement
Related Manuals for TransTel Communications TMS-100 P
Summary of Contents for TransTel Communications TMS-100 P
-
Page 1: Telephone System
TMS-100 Plug-N-Play SK-824 Electronic Telephone System TransTel Communications, Inc. Installation - Quick Reference Guide 1095 Jupiter Park Drive, Suite 7 Jupiter, FL 33458 TransTel Communications, Inc http://www.transtelcommunications.com Phone 561-747-4466 ©2000 TransTel... - Page 2 ©2000 TransTel Communications, Inc.
- Page 3 Notes For SK-824 & TMS-100 Plug and Play Voice Mail SK-824 - Information The table listed below shows the database changes necessary for a SK-824 Plug and Play KSU in order to install a TMS-100 configured as a Plug and Play. First, you must decide which Single Line Telephone Station Circuits that you wish to use for voice mail.
- Page 4 Database Items that must be changed for Plug-N-Play installation for SK-824. This is for a system with a 4 port TMS-100 and a SK- Item Description Plug-N-Play 01-01-05 Busy Reminder Tone Interval 6=30 seconds 01-02-01 Single Line Telephone Dial 5=16 seconds Tone Timeout 01-02-02 Single Line Telephone –...
- Page 5 Basic Plug and Play Information For example: If your voice mail ports are connected to extensions 31, 32, 33 and 34, you need to program 25-31-03, 25-32-03, 25-33-03 and 25-34-03 all with the value of 1. This setting is vital to proper Greetings Text programming for voice mail connectivity.
- Page 6 Form 28 – Extension Number – 06 n the Chains section everything should be blanks, except for Done, which should be set to 999 and Delay, which should be set at 0. User Toll Classification – Night Service Like the previous forms listed, you need to enter the extension numbers that are connected to voice mail.
- Page 7 Using 3 Digit or 4 Digit Extension Numbers Form 42 – CO Line – xx - Day Ringing Assignment If you program your SK-824 for 3 digit extension numbering or 4 digit numbering, you will need to change the integration information for the Form 42 determines the stations that will ring on an incoming call.
- Page 8 So Form 46-01-xx through 46-40-xx may exist in your SK-200. TMS Information The following parameters have been pre-set by TransTel to enable Form 47-01 – Hunt Group Access Code Plug-N-Play operation. In order for stations to easily call the voice mail system, each of the Database Entry/Verification TMS-100 voice mail extensions must be assigned to a Hunt Group.
