Summary of Contents for Ecoped ode

  • Page 2 PRINTSPEC: EN_ODE-2010v1 © 2010 MIDLAND INTERNATIONAL INC.
  • Page 3 TIONS ET AVERTISSEMENTS DE CE MANUEL. WARNING / AVERTISSEMENT This manual should be considered a permanent part of your ECOPED and should remain with the ECOPED when resold or otherwise transferred to a new user or operator. The manual contains important safety...
  • Page 5 During the warranty period ECOPED will repair, provide replacement parts or replace your ECOPED Ode at no charge at the discretion of ECOPED. This war- ranty does not cover normal wear items or damage caused by neglect or misuse of the product.
  • Page 6 BOTH the registration form and UPC label must be submitted in order to activate the warranty coverage. To register your ECOPED by mail, submit both the UPC label and com- pleted registration form to the address listed on the form. You can also register your ECOPED online at: www.ecoped.ca (UPC label must still...
  • Page 7 If your ECOPED requires warranty service, please contact the ECOPED customer service center at 1-877-528-3772 for instructions on filing for a warranty claim. You can also find a list of authorized ECOPED ser- vice centers listed on the website: www.ecoped.ca. When requesting warranty service you must have your copy of the Warranty Registration form and the sales receipt for authorization.

  • Page 8: Table Of Contents

    CONTENTS Important Registration & Warranty Your ECOPED Safety 1.1 Age Restrictions..........1.2 Safety Legend........... 1.3 Important Safety Notes........1.4 Safety Decals and Locations......1.5 Safety Gear............Display Unit & Controls 2.1 Left Handlebar........... 2.2 Right Handlebar..........2.3 Ignition.............. 2.4 Display Unit............
  • Page 9 Maintenance 5.1 Battery Maintenance......... 5.2 Battery Recycling..........5.3 Lubrication............5.4 Tires..............5.5 Brakes.............. 5.6 Storage............. 5.7 ECOPED Cleaning..........Specifications............33 Notes............... 34...

  • Page 10: Safety

    Operation is prohibited for anyone under the age of 16. KNOW YOUR ECOPED The operator of the ECOPED is responsible for their own personal safety, as well as the safety of others. Never operate the ECOPED without proper understanding of Safety Training in the Owner’s Manual.

  • Page 11: Important Safety Notes

    • Always use both brakes at the same time when stopping. • Never accelerate and have one or both brakes engaged at the same time. This will damage the motor and drivetrain. • Do not remove any components as this will jeopardise your safety and the performance of your ECOPED. • Never exceed speeds of 32km/h (20mph). • Do not carry cargo that will obstruct your front or rear line of sight. • Always operate your ECOPED at safe speeds which will allow you to avoid any sudden obstacles and allow for safe braking.
  • Page 12 • Do not operate the bicycle if tires are not within the recom mended pressures. • Take extra caution and follow installation instructions when modifying your ECOPED with factory accessories. • Never exceed the stated load capacity for your ECOPED. Cargo should be evenly distributed and attached securely. Reduce speed and follow the instructions in this manual for carrying cargo and make sure to allow longer distances for braking.

  • Page 13: Safety Decals And Locations

    ECOPED carefully. If any of the decals shown in this manual differ from the decals on your ECOPED, always read and follow the instructions of the decals on the bicycle. If any decal becomes illegible or comes off, contact ECOPED for a replacement.

  • Page 14: Safety Gear

    Goggles are also an important safety compnent of your safety gear. When travelling on your ECOPED, insects and airborne debris may become a serious hazard, and hitting them may result in eye injury. Your goggles will protect you...

  • Page 15: Display Unit & Controls

    2. DISPLAY UNIT 2.1 LEFT HANDLEBAR Make sure to familiarize yourself with the controls. Your left handlebar has the following controls: 1. Left Brake Lever - Use for engaging or disengaging the rear brake. 2. Left Grip 3. Intensity Switch - By toggling between the two modes, you can increase or decrease your headlight intensity.

  • Page 16: Right Handlebar

    Release the lever to disengage the brake. 2. Right Grip - The throttle grip. Twisting the throttle grip towards you will speed up the ECOPED. Twisting it away from you will slow the ECOPED down. 3. Headlight and Dash Light Switch - Slide the switch to the left to only turn the instrument panel light on.

  • Page 17: Ignition

    ECOPED from ignition jack based theft. You are also provided with a unique set of keys, which work specifically and only with your ignition. To turn your ECOPED on, simply insert and twist the key to the ‘ON’ position.

  • Page 18: Wheels

    2.5 WHEELS Your ECOPED runs on two wheels, each made up of one rim, one tire and one tube. Each rim is specially designed for their use on ECOPED electric bicycles. 2.6 TIRES Your ECOPED runs on two identical hard compound tires to ensure maximum longevity.

  • Page 19: Battery

    2.8 BATTERY Your ECOPED is equipped with a 4.8V, 8A (Rated) lead acid recharge- able battery that has a life of about 400-500 charges and is designed to carry you on a distance of 50-60km, depending on the terrain, slope, and load. All of these factors will influence the battery’s life per charge.
  • Page 20 ECOPED. CAUTION! Using a charger or battery that is not certified for use with your ECOPED may result in personal injury or permanent damage to your bicycle. See your ECOPED dealer for placement information.

  • Page 21: Lighting

    ECOPED. A sound will also be emitted in order to keep you in- formed. When braking, a red light will go off on the back of the bicycle.
  • Page 22 2.9.1 LEFT/RIGHT SIGNALS The procedures below outline how to signal turns with your ECOPED. 1. Slide the switch to either the left or right. The switch will click and then go back to its initial position. 2. To turn the signal off, press the switch down and it will click back into its initial position.

  • Page 23: Inspection

    Failure to inspect your ECOPED before operating increases the risk of an accident or equipment damage. Always inspect your ECOPED each time before riding, and make sure it is in a safe operating condition. When performing an inspection, follow the steps below and they will help you to perform an efficient and correct inspection that will ensure you a safe and prolonged life for your ECOPED.
  • Page 24 The tire pressure should be from 28-34PSI in order to ensure a safe ride. HORN Check that the horn buttons work. The horn installed on your ECOPED is loud and must not be tested indoors, as this may cause hearing damage. LIGHTS Check the headlights by turning them on and off.

  • Page 25: Inspection After Riding

    3.2 INSPECTION AFTER RIDING After riding, make sure that your ECOPED is turned off and the key removed from the ignition. Make sure to leave the battery charging by plugging the charger into your ECOPED. Make sure that one of the two kickstands is engaged when your ECOPED is parked.

  • Page 26: Seasons

    Doing so will put your safety and your ECOPED at risk. CAUTION! Your ECOPED must not be operated on snow or winter salt covered roads. Salt and frigid temperatures are harmful to the circuits inside of your ECOPED and must be avoided.

  • Page 27: Pedaling

    CAUTION! Speeding will cause damage to the wheel mechanism of your ECOPED and may result in loss of control and personal injury. 4.4.3 RIDING UPHILL Riding uphill requires experience and knowledge of your ECOPED’s potential.

  • Page 28: Acceleration

    Your ECOPED is designed to gradually accelerate to a speed of 32km/h from a standstill position. Depending on the total load, it may take a few hundred meters for your ECOPED to accelerate to its top speed. Travelling at top speed can be very dangerous if not carried out correctly.

  • Page 29: Maintenance

    When folding the double stand back its position, step on the little foot pedal and force the bicycle forward while keeping your weight on the pedal. Never sit on your ECOPED when it is parked with the double stand deployed, as this may permanently damage the kick- stand mechanism.

  • Page 30: Battery Recycling

    CAUTION! Cargo areas have limited load capacity restrictions, which must be precisely followed otherwise loss of control, injury, and damage to your ECOPED may occur. 5.6.1 WINTER STORAGE Prior to prolonged winter storage, the battery must be fully charged...

  • Page 31: Ecoped Cleaning

    5.6.3 ECOPED STORAGE Follow the steps outlined below when storing your ECOPED for long periods of time. 1. Prior to storage, make sure to remove the battery from your ECOPED.
  • Page 32 into unwanted areas. Before you start cleaning, make sure that the key is removed from the ignition. Use a wet cloth to clean out and remove any unwanted debris, such as dirt, dust, and grass. If you notice any debris stuck in the chain drive, make sure to carefully remove it.

  • Page 33: Specifications

    Load Capacity: 125Kg Constant Driving Distance: 40-50km Max Climbing Ability: 16 degrees Charging TIme: 6-8 hours Maximum Speed: 32km/h 0-30km/h Acceleration: 4.12 seconds Minimum Operating Temperature: -10°F - 14°F Maximum Operating Temperature: 40°F - 104°F For full specifications, please visit www.ecoped.ca...

  • Page 34: Notes

    7. NOTES...
