User image 67e9efa4cd6db

Subscribe to Our Youtube Channel

Summary of Contents for Proteus EEC - 1850

  • Page 1 1800 / 1850 Owner's manual...
  • Page 2 EEC-1800 / 1850 ELLIPTICAL ASSEMBLY INSTRUCTION STEP 1. a. FIT FOOT CAPS ( 23 ) TO END OF THE REAR STABILIZER AND CAPS ( 21 ) TO END OF THE FRONT STABILIZER. FIG.A ( PLEASE REFER TO FIG. A ) b.
  • Page 3 FIG. E STEP 3. a. INSERT AXLE SPACER ( 13 ), WAVE WASHER ( 49 ), PIVOT CAP-A ( 14 ), THEN FIT HANDRAIL- L ( 3L ) TO THE AXLE BY USING M8 MIDDLE WASHER ( 35 ) AND M8 BOLT ( 36 ). ( TIGHTEN THE BOLT FIRMLY ).
  • Page 4 ASSEMBLE TENSION CONTROL, MONITOR : FIG. H IF YOUR MODEL IS EEC-1800, PLEASE DO STEP 5 & STEP 6. IF YOUR MODEL IS EEC-1850, PLEASE DO STEP 7. STEP 5. a. RELEASE THE SCREW ( 48 ) FROM THE PARTS OF TENSION CONTROL ( 45 ).
