Related Manuals for Campomatic DW999ES
Summary of Contents for Campomatic DW999ES
- Page 2 ....1 This manual contains sections of Safety Instructions,Operating Instructions, Installation Instructions and Troubleshooting Tips etc. Carefully reading it before using the dishwasher will help you to use and maintain the dishwasher properly.
- Page 3 Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for such a period, before using the dishwasher turn on all hot-water faucets and let the water flow from each for several minutes.
- Page 5 Pre-wash pre-wash For normally soiled loads, wash（42℃） such as pots , plates,glasses rinse/ 3in1 and lightly soiled pans. rinse（68 ℃） standard daily cycle. drying Pre-wash For the heaviest soiled loads, ℃） pre-wash 50 （ such as pots,pans,casserole （ ℃） wash 60 dishes and dishes that have 5/22g.
- Page 6 NOTE: If you open the door when washing, the machine will delay start for several seconds, which will make the dishwasher work much better. There are two ways to reduce the water hardness: one way is using water softener, the other is using detergent.
- Page 7 The dispenser must be refilled before the start of each wash cycle following the instructions provided i n the" Wash Cycle Table".Your dishwashers use less detergent and rinse aid than conventional dishwashers. Generally, only one tablespoon of detergent is needed for a normal wash load. Also, more heavily soiled items need more detergent. Always add the detergent just before starting dishwasher, otherwise it could get damp and will not dissolve properly.
- Page 8 If there is no rinse aid warning light in the control panel, you can judge the amount of rinse aid by the following means. The black dot on the rinse aid dispenser indicates the amount of rinse aid in the dispenser. As the rinse aid diminishes, the size of the black dot decreases.
-
Page 9: Silverware Basket
The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cup and saucers, as well as plates, small bowls and shallow pans(as long as they are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water. - Page 10 We recommend that you place large items which are most difficult to clean into the lower rack: pots, pans, lids, serving dishes and bowls, as shown in the figure to the right. It is preferable to place serving di shes and lids on the side of the racks in order to avoid blocking the rotation of the top spray arm.
- Page 11 Wooden cutlery and utensils-these will leach out and become unsightly. Sensitive ornamental glasses, craft utensil and vases,special antique or irretrievable utensils.These ornaments are not dishwasher-proof. Plastic parts sensitive to hot water. Copper and tin utensils. Utensils w hich are soiled with ash,wax,lubricating grease or ink. Absorbent materials such as sponges and cloths.
- Page 12 The filter prevent larger remnants of food or other objects from getting inside the pump. This residue can occasionally clog up the filters. The filter system consists of a coarse filter,a flat (Main filter) And a microfilter (Fine filter). Main filter Food and soil particles trapped by this filter are pulverized by a special jet on the lower spray arm and washed down the drain.
- Page 13 If your dishwasher is left in an unheated place during the winter, ask a service technician to: Reconnect the water inlet pipe to the Cut off electrical power to the dishwasher. water valve. Turn off the water supply and disconnect the water Remove the filter in the tub the bottom inlet pipe from the water valve.
- Page 14 To clean the edge around the door, you should use only a soft warm, damp rag. To prevent penetration of water into the door lock and electrical components, do not use a spray cleaner of any kind. Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch the finish.
-
Page 15: Dimensions (Mm)
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear and free of impurities. - Page 16 Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher Power supply is not Make sure the dishwasher is turned on and the door is turned on closed securely.
- Page 17 Combination of soft Use less detergent if you have soft water and select a water and too much shortest cycle to wash the glassware and to get them clean. detergent Tea or coffee stains using a solution of 1/2 cup of bleach and 3 cups warm water to remove the stains by hand.
