QNAP is-1500 iSignager Player Quick Installation Manual

iS-1500
iSignager Player
Quick Installation Guide
Package Contents
iSignager player
● CD-ROM disc
● CD-ROM schijf
● Disco CD-ROM
● Компакт-диск
Hardware Illustration
English
Nederlands
ltaliano
Русский
P/N: 51000-023106-RS V1.0
● Power cord
● Voedingskabel
● Cavo d'alimentazione
● Сетевой шнур
● Quick Installation Guide
● Snelle installatiegids
● Guida all'installazione rapida
● Руководство по быстрой установке
1 2 3 4
English Nederlands
LED Indicators LED indicators
1
Lockable Front Door Afsluitbare voordeur
2
SDHC Card Slot SDHC-kaartsleuf
3
Power Button Voedings-knop
4
Power Connector Voedingsaansluiting
5
RS-232 RS-232
6
Reset Button reset-knop
7
External IR Connector Externe IR-connector
8
RCA Audio RCA Audio
9
S/PDIF S/PDIF
10
eSATA eSATA
11
HDMI HDMI
12
USB 2.0 x 2 USB 2.0 x 2
13
Gigabit LAN Gigabit LAN
14
● Adapter
● Adapter
● Adattatore
● Адаптер
6 8 9 10 12 14
5 7 11 13
ltaliano Русский
Indicatori LED Световые индикаторы
блокировкой передних
Serratura porta anteriore
дверей
Slot per schede SDHC SDHC слот для карты
Tasto d'alimentazione Кнопка питания
Connettore alimentazione Разъем питания
RS-232 RS-232
Pulsante di ripristino Кнопка Reset
Esterno IR Connettore Внешний ИК-разъем
RCA Audio RCA Audio
S/PDIF S/PDIF
eSATA eSATA
HDMI HDMI
USB 2.0 x 2 USB 2.0 x 2
Gigabit LAN Gigabit LAN
