- Page 1 SX-5800 Bedienungsanleitung Owner´s Manual...
- Page 2 Congratulations on your purchase of a ESX SIGNUM Amplifier. These quality audio products are designed and engineered to afford you years of uncompromised musical service. ESX has utilized the latest electronic technologies in order to deliver a superb listening experience.
- Page 3 General Installation Notes The amplifier is generally mounted in the rear trunk area but can be mounted in any convenient area such as beneath a seat. Please be sure to locate this unit where you have reasonable air circulation and protection from moisture. When considering the mounting location you should minimize the length of the power and speaker leads.
- Page 4 5-Channel Amplifier SX-5800 Functions and Controls Power - LED Green LED is illuminated amplifier is on Protect - LED Red LED is illuminated: a) Overheated b) Speaker wires shorted c) Overload (Impedance, less Power) d) Amplifier is damaged LOW PASS - Channel 5 Controls the frequency response of Subsonic-Filter - Channel 5 your speakers upwards.
- Page 5 Channel Amplifier SX-5800 Speaker wiring and Connection Stereo-Mode (5-Channel - with Front-/Rearsystem and Subwoofer) Interconect Cable checklist : • Connect the RCA outputs from head unit with the RCA Inputs (LINE INPUT 1CH&2CH / 3CH&4CH) of • the 4 Channel amplifier with two RCA Cables. •...
- Page 6 Channel Amplifier SX-5800 Speaker wiring and Connection Interconect cable checklist : • Connect the RCA outputs from head unit with the RCA Inputs (LINE INPUT 1CH&2CH / 3CH&4CH) of • the 4 Channel amplifier with two RCA Cables. • Connect the RCA outputs of the (LINE OUT) 4-Channel Amplifier with the RCA inputs(LINE INPUT) of •...
- Page 7 Trouble Shooting...
- Page 8 SX-5800 Kanäle Ausgangsleistung bei 14.4 Volt Watt an 4 Ohm - RMS 4 x 75 / + 1 x 200 Watt an 2 Ohm - RMS 4 x 125 / + 1 x 300 Ausgangsleistung bei 14.4 Volt gebrückt 2 x 250 / + 1 x 300 Watt an 4 Ohm - RMS Frequenzgang -3dB 20Hz - 30kHz...
- Page 9 SX-5800 Output Power Ratings at 14.4 Volts 4 x 75 / + 1 x 200 Watts at 4 Ohms - MAX. Watts at 2 Ohms - MAX. 4 x 125 / + 1 x 300 Output Power Ratings at 14.4 Volts bridged 2 x 250 / + 1 x 300 Watts at 4 Ohms - RMS Frequency Response -3dB...
