- Page 1 161 505 77-1 2014-01-16 Providing sustainable energy solutions worldwide Installation- and maintenance instructions CTC EcoZenith C 530 / 510...
- Page 3 Installation- and maintenance instructions 161 505 77-1 2014-01-16 CTC EcoZenith C 530 / 510...
-
Page 4: Table Of Contents
FOR THE PROPERTY OWNER Welcome _______________________________________________________________________ Important to remember! ______________________________________________ Safety Instructions _______________________________________________________ Hot water ______________________________________________________________ CTC EcoZenith C 530 design _____________________________ CTC EcoZenith 510 design _________________________________ Operation and maintenance _____________________________ Safety valve for the tank and radiator system ______ Draining the tank... -
Page 5: For The Property Owner
You are now the owner of a CTC EcoZenith C 530 or CTC EcoZenith 510. CTC EcoZenith C 530 is a buffer tank with a volume of just over 500 litres and has among other features inbuilt solar and hot water coils for use, for example, as the first tank in a wood boiler system. -
Page 6: Important To Remember
Important to remember! Pay special attention to the following points on delivery and during installation: • Transport and store CTC EcoZenith C 530 and 510 upright. A unit can be laid on its back for a short time if necessary. -
Page 7: Hot Water
For the property owner Hot water CTC EcoZenith C 530 contains a total of about 40 metres of finned, copper coil for heating water. This pre-heats the water through the lower tank and then passes through the upper tank for the final temperature increase. -
Page 8: Ctc Ecozenith C 530 Design
For the property owner 2. CTC EcoZenith C 530 design The illustration below shows the design of the unit. Fresh water connections Top connection The building’s fresh water supply For connecting an expansion is connected here. The cold water vessel and/or safety valve. -
Page 9: Ctc Ecozenith 510 Design
(Immersion heaters are accessories) Connections Connections are placed symmetrically on both sides Insulation of the tank. The tank is insulated with 90 mm thick, moulded polyurethane foam to minimise heat loss. CTC EcoZenith C 530 l 510... -
Page 10: Operation And Maintenance
For the property owner 4. Operation and maintenance When your new CTC EcoZenith C 530 or 510 has been installed, you should, together with the installation technician, ensure that the installation is optimal. Let the technician show you how it works and should be maintained. Purge the radiators after about three day’s operation and add water as necessary. -
Page 11: For The Installation Technician
This section is intended for the technician responsible for one or several of the installations needed for CTC EcoZenith C 530 and 510 to function as desired by the property owner. Take some time to go through the functions and settings with the property owner and answer any questions. - Page 12 For the installation technician Unpacking When the CTC EcoZenith C 530 or 510 has been placed at the installation site, the packaging can be removed. Make sure the unit has not been damaged during transportation. Notify the forwarding agent of any transportation damage.
- Page 13 The rear insulation sections and top cover should be fitted before the CTC EcoZenith C 530 or 510 is placed against a wall or in a corner for pipe and electrical connection. These parts are delivered separately and they are easier to fit if there is space around the unit.
- Page 14 Fit the plastic top at the front and tip it backwards to locate it under the mixing valve actuator. Fit the 4 provided zinc-grey screws in the prepared holes. Ensure that the top is correctly aligned with the front. CTC EcoZenith C 530 l 510...
-
Page 15: Pipe Installation
Fit a pressure gauge to the expansion pipe or radiator return pipe. Expansion vessel connection It is best to connect the CTC EcoZenith C 530 or 510 to a closed expansion vessel. If an open system is used, the distance between the expansion vessel and the highest radiator should exceed 2.5 metres, otherwise the... -
Page 16: Technical Data
2 x 18,6 Hot water coil circulation (finned) Solar coil (finned) Pressure drop diagram – hot water coils Tryckfallsdiagram varmvattenslingor Flow [l/min] Flöde [l/min] Pressure drop diagram – solar coil Tryckfallsdiagram solslinga Flow [l/min] Flöde [l/min] CTC EcoZenith C 530 l 510... -
Page 17: Measurements
11. Pocket for temperature sensor, Ø6.5 mm CTC EcoZenith 510 Heat connection, G 1 1/4” int Expansion vessel/Top con/Lifting socket, G 1 1/4” int Immersion heater connection, G 2” int 11. Pocket for temperature sensor, Ø6.5 mm CTC EcoZenith C 530 l 510... -
Page 18: Declaration Of Conformity
Försäkran om överensstämmelse Declaration of conformity Déclaration de conformité Declaration of conformity Konformitätserklärung Enertech AB Box 313 S-341 26 LJUNGBY försäkrar under eget ansvar att produkten confirme sous sa responsabilité exclusive que le produit, declare under our sole responsibility that the product, erklären in alleiniger Verantwortung, dass das Produkt, CTC EcoZenith som omfattas av denna försäkran är i överensstämmelse med följande direktiv,... - Page 20 Enertech AB. P.O Box 309 SE-341 26 Ljungby Sweden. www.ctc.se, www.ctc-heating.com...
