VAMP VEA 3CGi User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VEA 3CGi
Ethernet adapter
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEA 3CGi and is the answer not in the manual?

Questions and answers

Related Manuals for VAMP VEA 3CGi

Summary of Contents for VAMP VEA 3CGi

  • Page 1 VEA 3CGi Ethernet adapter User’s Manual...

  • Page 2: Table Of Contents

    2.1.3. Connection to other VAMP products ....8 3. Configuration................9 3.1. The Ethernet settings of the relay ........9 3.2. VEA 3CGi to the relay and Ethernet network....10 3.3. VAMPSET communication over the Ethernet Network11 4. Dimensional drawing ............13 5. Firmware update of VEA 3CGi ..........14 6.

  • Page 3: General

    1.1. Front panel Figure 1.1-1VEA 3CGi front panel 1. 2 serial ports : connection to VAMP relay (Local + Remote) 2. Ethernet port : 10 Mb/s, RJ-45 connector 3. 4 LED indicators:  Power: Powered by VAMP relay ...

  • Page 4: Application

     NTP time server connects to Ethernet  NTP server gets its time from GPS or Internet  VEA 3CGi gets synchronized via the server, using SNTP  The relay is synchronized to VEA 3CGi via the Local interface Modbus TCP over Ethernet ...

  • Page 5: Operation

     Open the communication tunnel between Port 502 and Remote port, which enables the use of Remote port protocols, e.g. Modbus TCP. Initialization After resetting, the VEA 3CGi performs the following the initialization sequence: Opening the Local port and configuration to speed 38400 b/s.

  • Page 6: Connection

    User’s manual Connection 2.1. Ethernet adapter Figure 2.1-1VEA 3CGi connection cables 100-series 200-series Other VAMP products VAMPSET communication VX015 VX003 VX030 Modbus TCP and ─ VX004M ─ VAMPSET communication and VX003 Vamp 24h support phone : +358 (0)20 753 3264 VMVEAi.EN001...

  • Page 7: Connection To 100-Series Relays

     Powered by VAMP relay via VX015 cable.  The REMOTE port of the 100-series has both REMOTE and LOCAL port signals.  Cable VX015 is connected to both ports of VEA 3CGi. 2.1.2. Connection to 200-series relays Figure 2.1.2-1 Connection to 200-series relay ...

  • Page 8: Connection To Other Vamp Products

    User’s manual Figure 2.1.2-2 VX004 connection to 200-series relay 2.1.3. Connection to other VAMP products  VAMP40: use cable VX030  VAMP96: use cable VX030  WIMO6CP10: use cable VX030 Vamp 24h support phone : +358 (0)20 753 3264 VMVEAi.EN001...

  • Page 9: Configuration

    Ethernet network you are going to use for communications. A fixed IP address must be used because DHCP is not supported in VEA 3CGi. Figure 3.1-1 Connecting cable VX003 to the relay’s front port for the Ethernet settings of the relay.

  • Page 10: Vea 3Cgi To The Relay And Ethernet Network

    Connect VEA 3CGi to a 200-series relay’s LOCAL serial port with cable VX003 . Connect the VEA 3CGi and the PC to an Ethernet Switch (see Figure 3.2-1 ). Connection to 100-series relays is done with VX015 cable and connection to VAMP 40 is done with VX030 cable.

  • Page 11: Vampset Communication Over The Ethernet Network11

    Press “Apply” button and then activate Connection to the relay (see Figure 3.3-2). Figure 3.3-1 Changing the communication settings of the VAMPSET software Figure 3.3-2 Button for activating connection to the relay VMVEAi.EN001 Vamp 24h support phone : +358 (0)20 753 3264...
  • Page 12 The communication with the VEA 3CGi can also be tested using “ping” command via the DOS-window of the Windows operating system (see Figure 3.3-4 ). Figure 3.3-4 Testing connection to the VEA 3CGi with the " ping" command. Vamp 24h support phone : +358 (0)20 753 3264 VMVEAi.EN001...

  • Page 13: Dimensional Drawing

    VAMP Ltd Ethernet adapter VEA 3CGi User’s manual Dimensional drawing Figure. 4-1 Ethernet adapter VEA 3CGi dimensions VMVEAi.EN001 Vamp 24h support phone : +358 (0)20 753 3264...

  • Page 14: Firmware Update Of Vea 3Cgi

    VAMP Ltd User’s manual Firmware update of VEA 3CGi The firmware of the VEA 3CGi module can be updated using Vampset PC software. For the update procedure a PC with Vampset software and a firmware file for the adapter is needed.

  • Page 15: Reference Information

    VAMP Ltd. P.O.Box 810 FIN-65101 Vaasa, Finland Visiting address: Yrittäjänkatu 15 Phone: +358 (0)20 753 3200 Fax: +358 (0)20 753 3205 24h support phone: Phone: +358 (0)20 753 3264 Email: vampsupport@vamp.fi VMVEAi.EN001 Vamp 24h support phone : +358 (0)20 753 3264...
  • Page 16 We reserve the rights to changes without prior notice VAMP Ltd Street address: Yrittäjänkatu 15 Phone: +358 20 753 3200 Post address: Fax: +358 20 753 3205 P.O Box 810, FIN 65101 Vaasa, Internet: www.vamp.fi Finland Email: vamp@vamp.fi VMVEAi.EN001...
