AEM AQ-1 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction
Manual
STOP! - READ THIS BEFORE INSTALL OR USE!
WARNING:
THIS INSTALLATION MAY REQUIRE WELDING OR INTEGRATION INTO A VEHICLE'S ELECTRICAL SYSTEM. DAMAGE
TO SENSITIVE ELECTRONICS, FIRE, OR EXPLOSION MAY OCCUR IF PROPER PRECAUTION IS NOT TAKEN. IF THERE
IS ANY DOUBT, DO NOT ATTEMPT THE INSTALLATION AND CONSULT A PROFESSIONAL.
NOTE: IT IS THE RESPONSIBILITY OF THE ENGINE TUNER TO ULTIMATELY CONFIRM THE CALIBRATION USE FOR
ANY PARTICULAR ENGINE IS SAFE FOR ITS INTENDED USE. AEM HOLDS NO RESPONSIBILITY FOR ANY ENGINE
DAMAGE THAT RESULTS FROM THE MISUSE OF THIS PRODUCT.
The AEM AQ-1 Data Logger is the ideal entry level data logger for virtually all forms of racing and Motorsports because it
installs easily, can read live parameters from ancillary sensors, AEMnet enabled devices, GPS and more, and put them
into a single log make your data easy to view. Whether you race a late model EFI-equipped OR carbureted vehicle, the
AQ-1 is the ideal solution for your data acquisition needs.
Features
· Four (4) 0-5VDC Analog Inputs with software
selectable 2.2k pull-up resistor
· Four (4) 0-16.5VDC Analog / Frequency Inputs
· Three (3) Digital (Switch to Ground, 16V Max) Inputs
· Serial (RS-232) Input (AEM EMS / NMEA0183 GPS
Only)
· AEMnet (CAN) Input (AEMnet Devices Only)
· 3-axis Internal Accelerometer +/- 4g
· 1000Hz Maximum Logging Rate
· EnviroSeal Boot / Sealed Connector
· 2 GB SD Card (Supports up to 32GB)
· AQ-1 Data Acquisition System Configuration Software
(USB)
· AEMdata Analysis Software
AEM Performance Electronics, 2205 126th Street Unit A, Hawthorne, CA 90250 - Phone: (310) 484-2322
P/N 30-2500
AQ-1 DATA LOGGER
http://www.aemelectronics.com
PN
35-2500
DATA LOGGER MODULE
35-5603
DATALOGGER ENVIROSEAL
35-3008
1-2059
NUT, 6-32 NYLOCK STAINLESS (4)
1-2047
SCREW,PAN HD 6-32x1-1/4 SS (4)
10-2500
Optional
PN
30-2906-96
Description
USB A-B CABLE
INST, AQ-1
Description
HARNESS, AQ1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQ-1 and is the answer not in the manual?

Questions and answers

Related Manuals for AEM AQ-1

Summary of Contents for AEM AQ-1

  • Page 1 DAMAGE THAT RESULTS FROM THE MISUSE OF THIS PRODUCT. The AEM AQ-1 Data Logger is the ideal entry level data logger for virtually all forms of racing and Motorsports because it installs easily, can read live parameters from ancillary sensors, AEMnet enabled devices, GPS and more, and put them into a single log make your data easy to view.

  • Page 2: Installation

    Mounting The AQ-1 is provided with a sealed main connector and EnviroSeal boot to cover the integrated USB port and SD card slot. Nevertheless, care should be taken to located the logger in a relatively clean, dry environment as it is not completely water-proof.
  • Page 3 Analog / Frequency Input 8 (16V Max) Frequency signals must be "clean" DC square wave only RS-232 Serial Tx AEM EMS Series 1/2 or NMEA0183 GPS Only RS-232 Serial Rx AEM EMS Series 1/2 or NMEA0183 GPS Only RS-232 Serial Ground...
  • Page 4 You want a log a pre-existing AIT sensor that's already wired to your engine management system or ECU. No, you don't need a pull-up resistor when You want to log an AIT sensor that you purchased from a third party, like AEM, and installed in your intake and is not connected to any other ECU, EMS, logger.

  • Page 5: Wiring: Digital Input

    The following Garmin GPS receivers have been validated for use with the AQ-1 · Garmin GPS 18x PC – 1 Hz model with DB9 connector and 12 volt power adapter - The 30-2906-96 AQ-1 Harness comes with the appropriately wired DB9 connector that can simply be plugged into the Garmin GPS 18x PC.
  • Page 6 The USB cable may be plugged either directly into AQ-1 itself or, if using the AEM 30-290x-96 harness, may be plugged in to the harness' USB connector -- they are electrically equivalent. Note: if this is the first time the AQ-1 is being used, please wait for Windows to recognize the device which, on some PCs may take up to sixty seconds;...
  • Page 7 USB to an AQ-1 that is powered by a 12V system through the main connector. Device Information When connected to an AQ-1 via USB, this area will display information about the device itself and its SD card if installed. Status Bar Displays the current connection and logging status.
  • Page 8 Reset To Factory Configuration - Resets connected logger's configuration to factory default settings. Update Firmware - Do not perform unless instructed by AEM Technical Support. Reboot Device - Performs a reboot of the currently connected logger. Not typically necessary.
  • Page 9 · Useful for testing logger configuration Device Date And Time · Log files will be time stamped using this date/time · AQ-1 date/time setting will reset if permanent 12V power is removed · Select method by which AQ-1 date/time should be...
  • Page 10 Live Data · Displays the raw voltage measured at the input pin · Displays the scaled value as will be recorded in the log · AQ-1 requires 12V power at main connector for proper readings Sensor Wizard · Load known sensor calibrations from Wizard database ·...
  • Page 11 · Records the duty cycle (in percentage) of the incoming signal such as may be typical on a fuel injector · The AQ-1 accommodates a typical 12V port injection fuel injector is without additional input circuitry/ conditioning · Duty cycle percentage may be based off the high or...
  • Page 12 Live Data · Displays the raw level measured at the input pin · Displays the scaled value as will be recorded in the log · AQ-1 requires 12V power at main connector for proper readings 10/25/2016 - DOCUMENT NUMBER: 10-2500...
  • Page 13 'Accel Lateral', 'Accel Longitudinal', 'Accel Vertical' · Set the sampling rate of this input Live Data · Perform calibration and ensure the AQ-1 is in the proper mounting position · Displays the current acceleration measured by the logger including Earth's gravity (Vertical = 1g) 10/25/2016 - DOCUMENT NUMBER: 10-2500 ©...
  • Page 14 · This procedure must be performed to ensure proper accelerometer readings Configuration: Serial/GPS The serial input allows logging of an NMEA0183 Serial GPS or the serial telemetry output of an AEM Series I or Series II EMS. Channel Options · Enabled checkbox determines if channel is logged or ·...
  • Page 15 The AEMnet input provides "Plug and Play" functionality and allows logging for AEMnet devices. AEMnet Devices / Auto Discover · Connect the AEMnet devices to the AQ-1 and ensure all devices are powered then click Auto Discover to configure the AQ-1 to log the...
  • Page 16 The Sensor Wizard is available on the majority of the input configuration pages to assist in configuration. It is essentially a database of sensor calibrations that AEM has compiled and made available for selection. The filters may be utilized to drill down to find the sensor you would like to connect to a particular input;...
  • Page 17 Log Files / SD Cards The AQ-1 Data Logger includes a removable Secure Digital (SD) Card 2GB card that is located on the back of the logger. To remove the SD card, push the card in until a soft click is heard. The card will release and can be pulled out. To insert the card, push the card in until a soft click is heard.
  • Page 18 Occasionally, the SD card may require re-formatting. This can be accomplished by inserting the SD card into the AQ-1, connecting the AQ-1 to a PC via the USB cable, and using Windows Explorer to format the drive. FAT (or FAT16) is the recommended file system for the fastest performance;...

  • Page 19: Faq & Troubleshooting

    Secure Digital (SD) and Secure Digital High Capacity (SDHC) rated cards are compatible with the AQ-1. SDXC and beyond are not approved for use. · SD/SDHC cards are rated as Class 2, Class 4, Class 6, or Class 10.
  • Page 20 Verify the two vertical lines are one inch apart on the printed drill template. Due to variances in printers, the print size may need to be adjusted if the two vertical lines are not one inch apart. 10/25/2016 - DOCUMENT NUMBER: 10-2500 © 2016 AEM Performance Electronics...

  • Page 21: 12 Month Limited Warranty

    AEM’s option, w hen determined by AEM that the product failed due to defects in material or w orkmanship. This w arranty is limited to the repair or replacement of the AEM part. In no event shall this w arranty exceed the original purchase price of the AEM part nor shall AEM be responsible for special, incidental or consequential damages or cost incurred due to the failure of this product.

  • Page 22: Specifications

    8 / 226 oz / g Supply Voltage Supply Current (13.8V) nominal 150.0 Operating Temperature -4 / -20 degF / degC max (16V Supply) 185 / 85 degF / degC 10/25/2016 - DOCUMENT NUMBER: 10-2500 © 2016 AEM Performance Electronics...
