Roda X-Frizzy RU-B07A Service Manual

Split type
Hide thumbs

Advertisement

Quick Links

Download this manual

AIR CONDITIONER

SPLIT TYPE
SERVICE MANUAL
X-FRIZZY
RS-B07A/RU-B07A
RS-B09A/RU-B09A
RS-B12A/RU-B12A

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-Frizzy RU-B07A and is the answer not in the manual?

Questions and answers

Related Manuals for Roda X-Frizzy RU-B07A

Summary of Contents for Roda X-Frizzy RU-B07A

  • Page 1: Air Conditioner

    AIR CONDITIONER SPLIT TYPE SERVICE MANUAL X-FRIZZY RS-B07A/RU-B07A RS-B09A/RU-B09A RS-B12A/RU-B12A...
  • Page 2 CONTENTS PAGE PRODUCT SPECIFICATIONS REFRIGERATION DIAGRAM INTRODUCTIONS OF INSTALLATION REMOTE CONTROLLER INTRODUCTIONS BRIEF INTRODUCTION FOR USAGE WIRING DIAGRAM DISASSEMBLY & ASSEMBLY TROUBLESHOOTING GUIDE EXPLODED VIEWS & PARTS LIST OPERATION DETAILS CURRENT & WIRING DIAGRAM OF PCB...
  • Page 4 7000 BTU 9000 BTU 12000 BTU 7000 BTU 9000 BTU 12000 BTU...
  • Page 10 .10.
  • Page 11 .11.
  • Page 12 .12.
  • Page 13 .13.
  • Page 14 AUTO COOL DRY HEAT FAN SPEED STRONG HIGH MID LOW AUTO TIMER ROOM ONOFF SWING2 SWING SLEEP CLEAN HEALTH FRESH ELE.H FUNGUSPROOF SCREEN LOCK MODE ON/OFF SPEED TIMER SWING SWING2 STRONG FEELING CLEAN HEALTH SLEEP SCREEN FUNGUSPROOF .14.

  • Page 15: Buttons Description

    Buttons description AUTO COOL DRY HEAT FAN RUNNING MODE DISPLAY SPEED STRONG HIGH MID LOW AUTO SPEED DISPLAY TIMER TEMPERATURE, TIME DISPLAY ETC ROOM ONOFF SWING2 SWING SWING OR ON/OFF DISPLAY SLEEP CLEAN HEALTH FRESH FEATURES DISPLAY ELE.H FUNGUSPROOF SCREEN LOCK MODE ON/OFF SPEED...
  • Page 16 FEELING button When it displays FEELING button Press this button can be used to set the feeling function. The LCD shows the actual room temperature when the function set and it shows the setting temperature when the function cancelled. This function is invalid when the appliance at the Fan mode.
  • Page 17 SET UP+ DOWN- button Press the SET - button,you can set the temperature range from 16 to 32,Display will change when you touch the button. CLEAN button a. When remote controller is at the off state, press CLEAN button, the wind guiding bars turn to initial postions for cooling, the A/C runs CLEAN function with max duration 35mins.The purpose of this function is to clean dust on evaporator and dry the inside water of evaporator and...
  • Page 18 button 12.SWING Press this button, the horizontal wind direction vanes can swing automatically, when you have the desired vertical wind direction, press it again, the horizontal wind direction vanes will be stopped at the situation of your choice. button 13.HEALTH Press this button, you can turn on or off the health function.

  • Page 19: Fix Batteries

    Usage Fix batteries 1.Slide open the cover according the direction indicated by arrowhead. 2.Put into two brand new batteries (7#), position the Ј batteries to right electric poles (+ -). 3.Put back the cover. Automatic operation mode 1.Press the ON/OFF button, the air-conditioner starts to operate.

  • Page 20: Fan Operation Mode

    Fan operation mode 1.Press the ON/OFF button, the air-conditioner starts to operate. 2.Press the MODE button, select the Cooling or Heating operation mode. 3.Press the SPEED button, you can select fan speed. You can select fan speed from LOW, MID, HIGH. 4.Press the button again, the air-conditioner stops.
  • Page 21 Attention 1.Aim the remote controller towards the receiver on the air- conditioner. 2.The remote controller should be within 8 meters away from the receiver. 3.No obstacles between the remote controller and receiver. 4.Do not drop or throw the remote controller. 5.Do not put the remote controller under the forceful sunrays or heating facilities and other heating sources.
  • Page 22 .22.
  • Page 23 .23.
  • Page 24 .24.
  • Page 25 .25.
  • Page 26 .26.
  • Page 27 .27.
  • Page 28 .28.
  • Page 29 .29.
  • Page 30 .30.
  • Page 31 .31.
  • Page 32 .32.

  • Page 33: Chapter 7 Disassembly & Assembly

    Chapter 7 Disassembly & Assembly .33.
  • Page 34 .34.
  • Page 35 .35.
  • Page 36 .36.
  • Page 37 .37.
  • Page 38 .38.
  • Page 39 .39.
  • Page 40 .40.
  • Page 41 .41.
  • Page 42 .42.
  • Page 43 .43.
  • Page 44 .44.
  • Page 45 .45.

  • Page 46: Chapter 9 Exploded Views & Part List

    Chapter 9 Exploded Views & Part List .46.
  • Page 47 .47.
  • Page 48 .48.
  • Page 49 .49.

  • Page 50: Chapter 10 Operation Details

    Chapter 10 Operation Details .50.
  • Page 51 .51.
  • Page 52 .52.
  • Page 53 .53.
  • Page 54 .54.
  • Page 55 .55.
  • Page 56 .56.
  • Page 57 .57.
  • Page 58 Chapter 11 Current & Diagram of PCB .58.
  • Page 59 .59.
  • Page 60 .60.
  • Page 61 .61.
  • Page 62 .62.
