WiFi Action Camera (V-VMS601)
Thank you for purchasing the Valore Action Camera.
Capture your best action moments with this compact and waterproof WiFi action camera.
High definition image quality and 170° wide-angle shooting ensure you get sharp footage
every time.
Important: Please read the user manual thoroughly before using your WiFi action camera.
Specifications:
• Model: V-VMS601
• Image sensor: 12 mega pixels CMOS
• LCD screen: 2.0"
• Lens: 170° wide-angle
• Resolution: 1920 x 1080 at 30fps
1280 x 720 at 60fps
• Input: DC5V/ 1A
• Wifi distance: 10m
• Battery type: 3.7V Lithium battery 900mAh
• Video format: MOV
• Video codec: H.264
• Photo format: JPEG
• Dimension (L x W x D): 59 x 41 x 25mm
• Weight: 43.4g (with waterproof case 151.5g)
UNDERSTANDING THE PRODUCT
①
②
③
④
Package Contents:
• Sport DV
• Waterproof housing
• Bicycle holder
• Base x 7
• Clip x 2
• Lens cloth
• Protective Backdoor
① OK/WiFi button
② Status indicator light
⑤
⑥
③ Power button
⑦
④ Lens
⑤ Microphone
⑧
⑥ Micro SD card slot
⑦ USB input
⑧ HDMI input
• USB cable
• Helmet base
• Bandages
• 3M adhesive
• Tethers
• Battery
Advertisement
Table of Contents
Related Manuals for Valore V-VMS601
Summary of Contents for Valore V-VMS601
- Page 1 WiFi Action Camera (V-VMS601) Thank you for purchasing the Valore Action Camera. Capture your best action moments with this compact and waterproof WiFi action camera. High definition image quality and 170° wide-angle shooting ensure you get sharp footage every time.
-
Page 2: Getting Started
⑧ ⑦ ① ② ③ ④ ⑤ ⑥ ① LED Screen ⑤ Speaker ② Operation indicator ⑥ Down button ③ Charging indicator ⑦ Battery cover ④ Up button ⑧ Battery cover lock GETTING STARTED To power ON: Press and hold the Power Button. To power OFF: Press and hold the Power Button. -
Page 3: Video Mode
SETTING Press the ‘Down’ button to enter the settings menu. Press OK button to select mode setting or general setting. Repeatedly press the Up and Down button to cycle through options and press the Ok/WiFi button to select desired option, press Power button to go back to the previous menu：... -
Page 4: Photo Mode
To stop recording: Press the Ok button. The camera status light stop flashing. This camera automatically stops recording when the battery is out of the power. Your Video will be saved before the camera powers OFF. PHOTO MODE To capture a photo, verify the camera is in photo mode. If the photo icon on your camera’s LCD screen is not showing, press the Power button repeatedly until it appears. -
Page 5: Camera App
CAMERA APP Connecting to the iSmart DV App (Wi-Fi Edition Only) The iSmart DV App lets you control your camera remotely using a smartphone or tablet. Features include full camera control, live preview, photo playback and sharing of select content and more. 1. -
Page 6: Technical Support And Warranty
All information, trademarks, logos, graphics, and images (“Materials”) provided on this user manual are copyrighted or trademarked and are the property of Valore Lifestyle Pte Ltd. Any unauthorized use of any material contained on the instruction manual may violate copyright laws, trademark laws, laws of privacy and communications statutes.
