Valore WiFi Action Camera (V-VMS603)
Thank you for purchasing the Valore WiFi Action Camera (V-VMS7603)
Never miss another moment with the Valore WiFi action camera. Switch freely between Car
DVR and sports action mode with this multipurpose camera and capture more of your
surroundings in a single shot with 170° ultra wide-angle lens.
Important: Please read the user manual thoroughly before using your action camera.
Specifications:
• Image sensor: 10 Mega Pixels CMOS
• LCD: 1.5 inch
• Lens: 170° ultra wide-angle
• Resolution: 1920 x 1080 at 30fps
1280 x 720 at 60fps
1280 x 720 at 30fps
• Input: DC5V/1A
• WiFi distance: 10m
• Battery type: Built-in 3.7V Lithium battery 700mAh
• Video format: MOV
• Video codec: H.264
• Photo Format: JPEG
• Dimension (L x W x D):69 x 39 x 38mm
• Weight: 70g (with waterproof case 137g)
UNDERSTANDING THE PRODUCT
2
1
Package Contents:
• WiFi action camera
• Waterproof housing
• Bicycle holder
• Base x7
• Lens cloth
• USB cable
• Helmet Base
• Bandages
• Suction cup
• Car charger
• Tethers
① ON / OFF / Mode switch
② REC / OK / Wi-Fi
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valore V-VMS603
Summary of Contents for Valore V-VMS603
- Page 1 Valore WiFi Action Camera (V-VMS603) Thank you for purchasing the Valore WiFi Action Camera (V-VMS7603) Never miss another moment with the Valore WiFi action camera. Switch freely between Car DVR and sports action mode with this multipurpose camera and capture more of your surroundings in a single shot with 170°...
- Page 2 WIFI ③ Up (Zoom in)/ IR Light ④ Menu / Back ⑤ Down (Zoom Out) ⑥ REC / OK / Wi-Fi ⑦ Playback ⑧ Microphone / Video Lock ⑨ Reset ⑩ AV Out Micro USB Port Micro SD Card Slot...
-
Page 3: Mounting The Camera
MOUNTING THE CAMERA 1) Please make sure that you are following the regulations and laws set by your Country or states DMV (Department of Motor Vehicles) prior to mounting your camera. This will avoid any accidents and traffic violations that can occur if the camera is mounted in a location that is prohibited by law. -
Page 4: Turning The Camera On
2) Depending on where you’ve chosen to mount the Wi-Fi Action Camera, run the power cable around the trim of your vehicle so that it will not obstruct your view while driving. 3) Insert the car charger into your vehicles cigarette lighter port as shown. A red light on the car charger will light up, indicating it is connected. - Page 5 USED AS ACTION CAMERA A Quick Introduction of how to attach your camera to helmets, gear and equipment. NOTE : Please switch to Sports Mode by pressing On/Off/Switch button before putting into the waterproof case.
-
Page 6: Set Date And Time
SET DATE & TIME 1. Turn on your Wi-Fi Action Camera • Press and hold the Power button until the “Welcome” screen appears 2. Press the Menu button twice to get to “Setup” menu 3. Select the Date&Time • Press the “Down” button until Date&Time option is highlighted •... - Page 7 Up / Zoom In REC / OK / Wi-Fi WIFI Menu / Back Playback MIC / Lock Down / Zoom Out UP/ZOOM IN The UP/ZOOM IN button is used to navigate through out the menu and make setting selections. It can also Zoom-In up to 2x its original distance while in video or photo mode. （Note ：...
- Page 8 MIC/LOCK The MIC/LOCK button is used to switch on/off the audio record (long press). This function also locks the current video recording on your Wi-Fi Action Camera. By locking the video file, it will prevent the file from being manually deleted. POWER / MODE The POWER/MODE button is used to switch between Car mode, Photo and Sports mode , it also used to manually turn the Wi-Fi Action Camera on or off when needed(long press), but in...
-
Page 9: Video Quality
• 1080HD @30fps (default) • 720P @30fps • 720P @60fps VIDEO QUALITY The Wi-Fi Action Camera supports various video quality that you can select from. The higher the quality, the better your video quality will be. Use the UP/DOWN keys to scroll through the options. Press the REC/OK button to select your desired settings. -
Page 10: Motion Detection
MOTION DETECTION The motion detection option is used to enable/disable motion detection recording. While the Wi-Fi Action Camera is on, and is on standby, any movement in front of it will trigger a recording. The Motion Detection feature consists of the following options: •... -
Page 11: Setup Settings
• On • Off (default) SETUP SETTINGS The Setup menu configures the Wi-Fi Action Camera’s system settings such as date and time, language, default settings, etc. It can be accessed from the Car Mode, Photo and Sports Mode. Press the Menu button twice to access the Setup menu. The Setup settings consist of the following configuration options. -
Page 12: Auto Power Off
AUTO POWER OFF The auto power off option is an auto shut-down feature which, after a set time frame of inactivity (not recording) or standby, the Wi-Fi Action Camera shuts off. The auto power off feature consists of the following options: •... -
Page 13: White Balance
LANGUAGE The language option lets you change the language of the Wi-Fi Action Camera. The language feature consists of the following options: • English (default) • French • Spanish • Italian • Chinese • Russian • Japanese FREQUENCY The frequency option switches between the two most commonly used refresh rates “60Hz” and “50Hz”. -
Page 14: Photo Mode Settings
SYSTEM This option Include Firm Version / Default Setting / Card info configuration. • Default Settings - The default setting option is used apply the Wi-Fi Action Camera’s manufacturer default settings. • Firm Version - The version option is used to view the Wi-Fi Action Camera’s firmware. •... -
Page 15: Capture Mode
• Date Stamp - Enables/Disables date stamp on recorded events. • Sharpness – Image sharpness configuration. • Exposure – Image exposure adjustment. RESOLUTION The Wi-Fi Action Camera supports various “Mega Pixel” resolutions that you can select from. The resolution feature consists of the following options: •... - Page 16 DATE STAMP The date stamp option lets you enable or disable the time stamp from being displayed on all the photos. The date stamp feature consists of the following options: • Off • On (default) SHARPNESS The sharpness option lets you select the image sharpness of the photos being taken. They make edges appear more defined by darkening the darker pixels and brightening the brighter pixels.
- Page 17 your desired settings. The available options include: • 1080HD @30 fps (default) • 720P @30 fps • 720P @60 fps VIDEO QUALITY The Wi-Fi Action Camera supports various video quality that you can select from. The higher the quality, the better your video quality will be. Use the UP/DOWN keys to scroll through the options.
-
Page 18: Playing Back Videos
PLAYBACK SETTINGS The Playback settings menu provides actions for video clips or photos that have been recorded in the Carcam. In the Playback mode, you can press “OK” button to play/pause and press the “Menu” button twice to open up the Playback configuration menu. The Playback settings consist of the following configuration options: •... - Page 19 BUTTON ACTION DESCRIPTION -Selects the highlighted event to playback/view Press once (when not playing REC/OK -Confirm an option when prompted back video) Press once (when not playing -Pause the video back video) Press once -Switches to “Video” mode MODE -Used to navigate through the recorded events Press once (during multiple file view) Press once (during video playback) - Fastforward the video...
- Page 20 Connect the device Wi-Fi 1. Enter the Settings of your smartphone • Turns the Wi-Fi on • Find the Wi-Fi named “view-0001” and select . 2. Connect the Wi-Fi • Type in the initial password “12345678” and get connected • “ Wi-Fi connection is ready..” screen appears on Wi-Fi Action Camera. Application 1.
- Page 21 2. Download / Delete files • Press the icon at lower left corner to enter files browser and download / delete the files 3. Change Settings • Press the Settings icon at upper right corner to enter device settings . •...
- Page 22 1.5 ” TFT LCD LCD Size Image Sensor Digital HD color CMOS Viewing angle 170°A+ grade high -resolution ultra wide -angle Language for options English /French/Spanish/Italian/ Traditional Chi nese/ Simpli ed Chinese/Japanese/ R ussian Video resolution 1080P 1920*1080 @ 30fps , 720P 1280*720 @ 30fps , 720P 1280*720 @ 60fps Video/Photo formats...
-
Page 23: Technical Support And Warranty
All information, trademarks, logos, graphics, and images (“Materials”) provided on this user manual are copyrighted or trademarked and are the property of Valore Lifestyle Pte Ltd. Any unauthorized use of any material contained on the instruction manual may violate copyright laws, trademark laws, laws of privacy and communications statutes.
