Option 2: Wired
i.
Make sure a PoE Injector and two Cat5 cables
are available before the connection. (PoE
Injector and Cat5 cables are not included in
the package)
Using a Cat5 cable, connect the PoE
ii.
Injector to the same router that the Home8
Security Shuttle is connected. Using the
other Cat5 cable, connect the PoE Injector
to the Camera's Ethernet interface and DC
power will be delivered to the Camera and
data will be transferred. Power on the PoE
Injector.
Wired (PoE)
Network data
Electrical Power
PoE Injector
(not included)
Router
What's inside:
1x Security Shuttle
1x USB power adapter
2x Power adapters
1x Ethernet cable
Cable waterproof cases
1x USB power cable
Mounting accessories
What you'll need:
• Broadband Internet
• iPhone or Android phone
Mini Outdoor Full HD 2-Camera
Interactive Security Camera System
Quickstart Guide
Model No. V63020US
2x Mini outdoor Full HD cameras
Power waterproof cases
2x Wrenches
• Home router
Advertisement
Related Manuals for HOME8 V63020US
Summary of Contents for HOME8 V63020US
- Page 1 Injector and Cat5 cables are not included in the package) Wired (PoE) Using a Cat5 cable, connect the PoE Injector to the same router that the Home8 Security Shuttle is connected. Using the other Cat5 cable, connect the PoE Injector to the Camera's Ethernet interface and DC...
- Page 2 Step 1: Unpack your devices and accessories Step 2: Power on the Camera and connect it to the system 1. Insert the microSD* card into the Camera Card Slot before 1. Unpack your devices and accessories. 2. Pair the Camera with Security Shuttle within 1-10 feet to make sure the connection is working well. powering up the Camera, if you want to have continuous video recording.
- Page 3 • If your devices still don’t communicate with Security Shuttle, even when they’re in the same room, navigate to > Device Management > + on the Home8 app to add your devices again. How to reset the camera if the app tells you to do so: •...
- Page 4 3. Secure the camera to the wall with the supplied screws. 2.Wait until you see live streaming video from the Home8 app before mounting. Step 5: Installation Both wall mounting and ceiling mounting are suitable for the Camera. Wall mounting will be taken as Secure the Camera to the Wall an example in this section.
