StatClean
USER MANUAL
FEATURES:
Large Tank Capacity
Large Tank Capacity
Control panel with capacitive
sensing technology
Drainage valve
Two industrial grade
ultrasonic transducers
Two ceramic heaters
3-color LED display
Independent control circuit
for each ultrasonic transducer
Multiple circuit protectors
Moisture-proofed PCB with
industrial IC
Two cooling fans
Multiple optional accessories
Solid and advanced structural
design
SD-485 US EN R1_StatClean user manual.indd 1
- Ultrasonic Cleaner
Tank capacity 6.0 L / 1.6 gallon.
Tank size: 32.5 x 20.5 x 9.9 cm / 12.7" x 8.1" x 3.9"
Patented design, basket can be raised and suspended to
drain water.
Solid panel top. Durable, reliable, resistant to water and
harsh chemicals.
Convenient to use.
Uniform distribution of ultrasonic waves, strong cleaning,
high durability.
Mounted underneath the bottom of the tank for safe and
even heating; more durable construction.
1 to 30-minute full range timer, 5 temperature settings, actual
temperature thermometer, degas and solution usage timer.
40% higher cleaning efficiency, not susceptible to
interference, more durable.
When overloaded or improperly used, the protectors shut
down the power to certain areas to protect the machine.
Capable for different working environments with better anti-
interference performance.
One for cooling of PCB boards, one for cooling of ultrasonic
transducers. Improve heat dissipation and beneficial for
continuous operations.
Suspendible plastic basket, stainless steel rack and tray,
indirect cleaning tank, beaker and double beaker holder.
4.5 mm thick wall housing made from engineering grade
plastic with tongue-in-groove design for better waterproof
and drop-proof performance.
1
2016-06-09 12:58 PM
Advertisement
Table of Contents
Related Manuals for SciCan StatClean
Summary of Contents for SciCan StatClean
- Page 1 StatClean - Ultrasonic Cleaner USER MANUAL FEATURES: Large Tank Capacity Tank capacity 6.0 L / 1.6 gallon. Tank size: 32.5 x 20.5 x 9.9 cm / 12.7” x 8.1” x 3.9” Large Tank Capacity Patented design, basket can be raised and suspended to drain water.
- Page 2 INTRODUCTION Use filtered water for best results. PRINCIPLES OF ULTRASONIC CLEANING Millions of tiny air bubbles are generated within liquid by high frequency vibration. The air bubbles burst when in contact with object and dislodge the debris to achieve the cleaning effect. Using tap water is sufficient;...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS PRODUCT STRUCTION AND ACCESSORIES CONTROL PANEL AND OPERATIONS OPERATION GUIDELINES MEMORY OPERATIONS COMMON CLEANING METHODS PRODUCT EXPLODED VIEW CARE AND MAINTENANCE OPTIONAL ACCESSORIES SPECIFICATIONS SD-485 US EN R1_StatClean user manual.indd 3 2016-06-09 12:58 PM... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Keep CLEANER away from children! Please store the ultrasonic cleaner where it is not reachable by children. Danger to children! Danger of death through suffocation! Keep the packaging material from children. This appliance shall not be used by children. Keep the appliance and its cord out of reach of children. -
Page 5: Important Safety Instructions
SAFETY PRECAUTIONS Use filtered water for best results. Other observations: • Do not operate the product without filling the tank with water. Running dry will damage the unit. • Do not plug in the power cord before adding water to the tank. Do not fill the tank above the Max line to avoid overspill. -
Page 6: Product Struction And Accessories
PRODUCT STRUCTURE & ACCESSORIES H. I. 88:88 8:88 A. Top Cover Control panel B. Stainless steel tank G. Handlesa C. Housing H. Power switch D. Drainage pipe fitting Power socket Drainage valve handle Cover holder STANDARD ACCESSORIES: Power cord Hose Working Time Display Multistage Thermeter Set Termperature Display... -
Page 7: Control Panel And Operations
CONTROL PANEL & OPERATIONS 10:00 – Working Time Display. It counts down after work is started. – Multistage Thermometer. Solid green light indicated that the water temperature is 0-30% of the set temperature. Solid orange light indicated that the water temperature is 30- 60% of the set temperature. - Page 8 CONTROL PANEL & OPERATIONS On/Off Key. After powering on, the LED display shows 10:00, which is the initial default time (as shown), and the unit is ready with the normal working status. Press On/Off key twice and the cleaning starts. The cleaning stops when the timer counts down to 00:00.
-
Page 9: Operation Guidelines
OPERATION GUIDELINES Remove the cover and put it on the cover holder vertically. Put items in the basket then put them in the cleaning tank. Add general purpose OPTIM 28 (see OPTIM 28 label for specific dispensing instructions) to a level between MIN and MAX and above the area to be cleaned. - Page 10 OPERATION GUIDELINES Select one of the four cleaning methods recommended later. 1. When the heater is needed, press TEMP button to select one of the 5 preset temperatures. Press Heater key twice, flashes, indicating the heater is turned on. When the water reaches the set temperature, dims, indicating the heater is turned off.
-
Page 11: Memory Operations
MEMORY OPERATIONS This unit is equipped with advanced power off memory capability. It memorizes the last timer setting once the cleaning cycle is started, and the last temperature setting once the heater is started. 1. Last timer setting recall. 5 seconds after the timer counts down to 00:00, the last timer setting will reappear. -
Page 12: Common Cleaning Methods
COMMON CLEANING METHODS A. Regular cleaning Use filtered water for best results. Suitable Locations: Dental and medical offices and labs. Cleaning Method: Put the items to be cleaned inside the basket and put the basket inside the tank. Add clean chemicals to the cleaning tank to a level between “MIN”... - Page 13 COMMON CLEANING METHODS C.Enhanced cleaning. Debris accumulated over a long period of time, heavily soiled. Cleaning Method: Large items can be put in the tank directly. Small items can be put in the basket then put in the tank. Do not put the items on top of each other to avoid rubbing during cleaning.
-
Page 14: Product Exploded View
PRODUCT EXPLODED VIEW SD-485 US EN R1_StatClean user manual.indd 14 2016-06-09 12:58 PM... - Page 15 Item Material Top handle Lid-window Lid-top Lid-bottom Top ring Stainless steel handle SUS 304 Basket foldable handle 1 Basket foldable handle 2 Plastic basket Silicon seal Silicone rubber Stainless steel tank SUS 304 Left cover Left handle Left panel Inner tank Front cover Drain SUS 304...
-
Page 16: Care And Maintenance
CARE AND MAINTENANCE Do not turn on the unit without water in the tank. Even though the unit is designed with multiple protections, if it is turned on for over 15 seconds without water in the tank, it may damage the unit or severely reduce the life of the unit. A thermal switch is attached to the bottom of the cleaning tank. -
Page 17: Optional Accessories
OPTIONAL ACCESSORIES Suspendible plastic basket The basket has foldable handles. It can be raised and suspended above water to drain water. Beaker and beaker holder Place the beaker holder with beaker(s) across the top of the main cleaning tank as shown. Add water to the main tank so the water level reaches the beaker(s). Add solution inside the beaker(s). -
Page 18: Specifications
SPECIFICATIONS Description StatClean Ultrasonic Cleaner Model SC-P4862 Max. 5.0 L / 1.3 gallon (US) Tank Capacity 6.0 L / 1.6 gallon (US) Min. 3.35 L / 0.9 gallon (US) Tank Size 32.3 x 20.5 x 9.9 cm / 12.7” x 8.1” x 3.9”...
