- Page 1 HISCO HD DVR USER’S MANUAL...
-
Page 2: Table Of Contents
COPYRIGHT AND IMPORTANT INFORMATION ..................... 4 WARNINGS ..............................4 INSTALLATION AND PROACTIVE STEPS ......................5 Pre-Cautions ............................5 Location conditions to avoid for installing Hisco DVR System .............. 5 Installation: ............................5 Installing the DVR ..........................6 IMPORTANT SAFEGUARD ..........................7 IMPORTANT NOTICES ........................... - Page 3 5-4 Live view Feature ..........................39 Live view Tool Bar ..........................39 5-5 Remote Search ..........................40 5-6 Remote HD DVR server Setup ......................40 5-7 Camera Group ........................... 41 Group setup ............................41 Connect to Camera Group ........................41...
-
Page 4: Copyright And Important Information
Copyright The contents of this manual may not be copied or reproduced in any manner or form without the prior written consent of Hisco Technologies Canada, Ltd. Important Information Before proceeding, please read and observe all instructions and warnings contained in this manual. -
Page 5: Installation And Proactive Steps
The unit is not exposed to rain or water. The unit is not designed to be waterproof • A UPS(Uninterrupted Power Supply) must be used with the Hisco DVR unit to protects DVR from surges, spikes, lightning and other power disturbances... -
Page 6: Installing The Dvr
DVR on an even surface 2. Plug keyboard and mouse into the appropriate plug at the back of the HD DVR 3. Plug in the monitor cable from the monitor into the video graphic card at the back of the DVR. -
Page 7: Important Safeguard
HISCO HD DVR User's Manual IMPORTANT SAFEGUARD READ INSTRUCTIONS – All the safety and operating instructions should be read before the appliance is operated. RETAIN INSTRUCTIONS – The safety and operating instructions should be retained for future reference. CLEANING – Unplug video monitor or equipment from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. -
Page 8: Important Notices
IMPORTANT NOTICES When the video product exhibits a distinct change in performance – this indicates a need for service. REPLACEMENT PARTS – When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or that have the same characteristics as the original part. -
Page 9: Introduction Dvr System
HISCO HD DVR User's Manual 1. INTRODUCTION DVR SYSTEM This system is PC Architecture HD Digital Video Security System digitizing, compressively saving, retrieving and generating output image information from cameras. Also, this system is Digital Video Security System of Next Generation improving strong points and significantly complementing defects of existing analog CCTV. -
Page 10: Provided Components
1. INTRODUCTION DVR SYSTEM 1-2. PROVIDED COMPONENTS DVR system consists of: • DVR system • DVR Installation CD contains the following DVR Client software Nero Burning Software User’s Manual file (Acrobat PDF type) • Camera Input BNC connector and accessories •... -
Page 11: Setting Up Hisco Dvr System
HISCO HD DVR User's Manual 2. SETTING UP HISCO DVR SYSTEM 2-1. SYSTEM SETTING Hisco HD DVR surveillance program starts automatically once the system powers up. User is required to LOGIN to access HD DVR function Setup Exit HD-DVR Fill in the User ID and password (Use keyboard or virtual computer keyboard, by clicking on the keyboard icon). - Page 12 Beep: DVR output continuous beeping sound from speaker CMS Notify: HD DVR Client receives a notification for video loss Email Notify : When SMTP is set up, HD DVR send a email notification to user. Log write: enable/disable writing motion and sensor status into the log file.
- Page 13 “Temperature error” or “HDD error”. Disable windows function key: Lock windows for only server use if user want to prevent from other tasks. Set Logoff Time: HD DVR system logs out when system is idle after a specific time. Day Light Saving Time : When time reversal occurs according to summer time, it backs up information as long as time reversal occurs to the folder designated.
-
Page 14: Camera Setting
2. SETTING UP HISCO DVR SYSTEM 2-2. CAMERA SETTING Select Camera: Select the camera to configure. Use Camera: Camera ON/OFF Camera ID: Name each camera. (Max. 17 characters) Covert: hide camera in live screen and Search mode. TDS: Display Data Time and Camera Description PTZ: Enable or disable PTZ control. - Page 15 HISCO HD DVR User's Manual Video Quality : video recording quality Record Schedule: Holiday setting: Apply recording configuration of Sunday to user defined date. Recording schedule for holiday is same as the recording schedule for Sunday. Event recording setting: specify how many frames are recorded after event is triggered.
-
Page 16: Motion Detection Setting
2. To receive notification on CMS client software or email, check CMS notify. 3. User can assign a relay to each camera. When motion event is triggered, HD DVR will trigger digital output signal. Notification Schedule setup Select Motion or senser 1. -
Page 17: Motion Area Setup
HISCO HD DVR User's Manual Motion area setup Select Camera : User can set up motion detection areas for individual camera or click apply all to have the same setting for all HD cameras or Analog Area Setting: Set up motion sensitive area (motion grid). -
Page 18: Display Setup
Display Default Screen: initial start up screen when HD DVR program is running. Page Auto Switch time: the amount of second passes before HD DVR rotate to next camera Display Text: Enable/Disable on screen camera status in live view Spot Monitor: to setup spot monitor for analogue cameras refer to Spot monitor setup. - Page 19 HISCO HD DVR User's Manual Priority between one-split and event: set up Priority between one-split and event trigger. Spot monitor will jump to event camera when spot out is set to Event has more priority. Split Setting: to set up Mixed split.
-
Page 20: Network Setup
2-6 Network setup Accept: Enable/Disable CMS and Email notification. Port Setting: specify which port does HD DVR uses for each function. Network Notify: Specify which stations receive event notification on CMS. Email Setting: HD DVR sends Email notification if event is triggered Recipient: TO &... -
Page 21: User Setting
HISCO HD DVR User's Manual 2-7 USER SETTING User setup In User setting user can add, modify or delete users for different access privileges. Add: User can add a new user. Delete: Choose a user from the list and click DELETE button to delete the user. -
Page 22: Hd Dvr Live View Interface
3. HD DVR Live View interface 3. HD DVR Live View interface Split Screen Arrow User can switch the Live View mode between X1, X4, X6, X9, X10, X13, or X20 screen split. To navigate between cameras click Arrows or click A (Auto) for automatic camera rotation. - Page 23 HISCO HD DVR User's Manual Live Audio Audio setup for specific camera, HD DVR user can listen to cameras with audio equipped With To hear live audio, Select a camera channel and click Audio. After audio control interface is activated, click Play and Audio input from camera is transmitted.
-
Page 24: Manual Backup
Note: saved footage is not AVI format. CD/DVD Burning Hisco HD DVR has build in DVD and CD burning utility. Use CD burn to burn multiple JPG, Video footage and AVI file into a CD or DVD 1. Select DVDRAM drive from Device 2. -
Page 25: Hd Dvr Footage Review
HISCO HD DVR User's Manual 4. HD DVR FOOTAGE REVIEW 4-1 DVR Search Search is a powerful playback program for HD DVR system. It offers various playbacks and searching option for recorded data. Click the Search Button on the DVR Main Screen The Search screen appears as below. -
Page 26: Player Button
4. HD DVR FOOTAGE REVIEW 4-2 Player button • -- Continuous play forward • -- Continuous reverse play • ------- 1 frame forward play • ------- 1 frame reverses play • ------- Stop • -------- Speed increase • ------- Speed decrease Search Function button •... -
Page 27: Save Avi Function
HISCO HD DVR User's Manual 4-3 Save AVI Function Save function let users save the recorded data as an AVI format file onto CD/DVD or other backup drive. Save as AVI video file 1. Click “SAVE” button on the Search main screen and select AVI. -
Page 28: Smart Search
Smart Search (Motion Search) Click Set and draw Motion Detection box by dragging left mouse button. Click “Search” button and HD DVR will search for pixel changes in the Area box. Event information is listed on the left hand side. -
Page 29: Image Post Production
Stop video and Click COLOR button to show COLOR ADJUST menu (shown right). Click and drag left or right to adjust brightness, contrast, and saturation. HD DVR also has the ability to Sharpen/Blur image, convert color to Grayscale. Original: Reverse all changes applied to image. -
Page 30: 4-7Setting
4. HD DVR FOOTAGE REVIEW GOTO Function GOTO function enables user to go to specified Date and time using following GOTO dialog box. The GOTO feature allows user to go to an exact time and date of a recording. Simply enter the Date, Time, and Camera, and click the OK button. -
Page 31: Central Management System (Cms)
HISCO HD DVR User's Manual 5. Central Management System (CMS) CMS is the remote management program for the HD DVR system, which is installed on a remote site and connected to a network. Major functions are as below: • Remote monitoring function •... - Page 32 5. Central Management System (CMS) 3) Choose English as the language for CMS 4) CMS installation will start and automatically interface. proceed to next step. 5) When installation is complete, click Finish to restart computer...
-
Page 33: Cms Client Uninstall
HISCO HD DVR User's Manual CMS client Uninstall To uninstall CMS Client, click Uninstall and OK to confirm. To Uninstall CMS via Control Panel, 1.) Click Start menu/Control Panel and double click Add or Remove Programs 2.) Click Change/Remove and Ok to confirm Uninstall. -
Page 34: Cms Main
5. Central Management System (CMS) 5-2 CMS Main Click on the ‘CMS' icon on the client computer. Client login screen will appear Default ID/password is admin/1111 Note: ID/Password is case sensitive Live View Control bar HD DVR Site List Live view Cameras... -
Page 35: Client Program Setting
THIS COMES FIRST CMS allow user to connect to multiple HD DVR system with one log in ID/password. Each HD DVR site has different account and password; so HD DVR server can control which content is accessible by user. Only admin account has privilege to modify site accessible for each user. -
Page 36: Register New Site
5. Central Management System (CMS) To add user account, log in as admin and click Add in user Setup. User name: log-in ID Password: log-in password at CMS start up. Authority to CMS setup: allow specified user to change local setting except user set-up Register New Site, Click on the “Setup”... - Page 37 ID & Password: username and password on HD DVR server with remote access privilege After inputting information for remote HD DVR server, click Registration to add remote HD DVR. This information can be edited or deleted using the Modify or Delete button.
-
Page 38: Cms Local Setting
CMS local Setting Login: set up automatic login when starting CMS Display: if client program is connected to remote HD DVR and no picture for LiveView; disable Overlay use and restart CMS program. Channel Split: initial Camera display Mode of the CMS... -
Page 39: Live View Feature
Manually change display camera to next. Display rotation Automatically cycle through camera on live view Auto camera rotation PTZ control panel is functional when HD DVR has it enabled Pan/Tilt/Zoom camera PTZ control panel in Setup CMS user can communicate with HD DVR operator if both... -
Page 40: Remote Search
Bookmark Select Image Data 5-6 Remote HD DVR server Setup Once connected to remote HD DVR, if you have proper privilege you can manage HD DVR server remotely. After logged into CMS client software, select HD DVR Site and Setup. -
Page 41: Camera Group
Click Group Add to create new camera group. To modify or delete group, select group name and click "Group Name Edit" or "Group Delete" Drag and drop camera from different HD DVR in the Group Array from the Site list of the CMS main screen. -
Page 42: Iphone/Smartphone (Smartview)
6. iPhone/SmartPhone (Smartview) 6. iPhone/SmartPhone (Smartview) 1. Access to the App store and search 2. Search and Install “Smartview” 3. Add and Save New DVR info 4. Access DVR iPhone SmartPhone(Android)
