- Page 1 ElEctronIc 2 DIal tap tIMEr co1701 InstructIon Manual...
-
Page 2: Table Of Contents
table of contents Technical Data..............p1 Glossary................p2 Applications & Safety Instructions........ p3 Connecting to the Tap & Operation Modes....p4 Tap Timer Diagram............p5 Manual Operation (ON / OFF)......... p6 Automatic Programming..........p7 Notes Pages..............p8 - 9 Warranty................Back Page... -
Page 3: Technical Data
technical Data Tap Connection: 20mm BSP Female Hose Connection: 12mm Hose Snap-on or 20mm BSP Male Water pressures: Max. 8 Bar 800kPa Water Temperature: Max. 40ºC Irrigation Medium: Clean Water Batteries: 2 x 1.5V AAA Alkaline Batteries (Not Supplied) -
Page 4: Glossary
Glossary 1. Universal Tap Adaptor 5. Battery Compartment 2. Tap Connection 6. Clear Screw-on Cover 3. Union Nut 7. Snap-on Hose 4. Control Dials Connection... -
Page 5: Applications & Safety Instructions
applications & safety Instructions This Electronic 2 Dial Tap Timer is ideal for watering small garden areas, pots & flower beds, fitting directly onto your garden tap. Safety Instructions For reasons of long life reliability, only use good quality ALKALINE batteries. To prevent the tap timer failing through weak batteries during a prolonged absence, the batteries must be replaced before re-use. -
Page 6: Connecting To The Tap & Operation Modes
connecting to the tap & operation Modes For connection you need a water tap with a 20mm or 25mm thread. 1. Unscrew the union nut (3) to enable the water tap connection (2) to move freely. 2. Screw the tap timer firmly onto the water tap by the tap connection. Turn the unit to face you so the Control Dials (4) can be easily seen. -
Page 7: Tap Timer Diagram
tap timer Diagram “How often” Dial “How long” Dial • • Turn the dial to select: Turn the dial to select: from every hour from 1 minute upto to once a week. 120 minutes. • • Select from the Select from the 11 positions 10 positions or Reset. -
Page 8: Manual Operation (On / Off)
Manual operation: (on / oFF) Turn the “How Long” Dial to “ON”. The unit will water until this dial is turned to “OFF”. NOTE: There is a 10 second delay. oFF: The “OFF” position on the “How Long” Dial will stop an automatic or manual watering cycle. -
Page 9: Automatic Programming
automatic programming Install the 2 x 1.5V AAA Alkaline batteries in the battery tray. Please note the polarity + and - . Select “How Long” you wish to water (10 position dial from 1 minute to 120 minutes). Select “How Often” you wish to water (11 position dial from every hour, to once a week). The unit will commence watering within 10 seconds to confirm the automatic watering start time. -
Page 10: Notes Pages
notes page... - Page 11 notes page...
-
Page 12: Warranty
Manual OFF? Warranty: We will honour all statutory guarantees that this product is of acceptable quality. (including that it is fit for purpose) HOLMAN Industries: 47 Walters Drive, Osborne Park, WA 6017. Ph: +61 8 9204 1011 www.holmanindustries.com.au...
