Control terminal 'Touch'
1
Speed readout for patient
2
Connectors (e.g., for blood pressure cuff , SpO2)
3
Adjustment of handlebar angle
4
Castors
5
Baseplate (large)
6
Leveling feet to adjust the ergometer to uneven fl oors
7
Sockets for power cord and connection cables (under-
8
side of ergometer)
Power switch (toggle switch [ I / 0 ])
9
Saddle adjustment with clamping lever
10
(optionally with gas pressure spring or motor)
