KNOW YOUR PRODUCT
MULTI
PURPOSE
MIXER
• 1600w
• Variable Speed
• 2 Gear SettinGS
• 160mm mixinG
paddle
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
07/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Full Boar FBT-1600
Summary of Contents for Full Boar FBT-1600
- Page 1 KNOW YOUR PRODUCT MULTI PURPOSE MIXER • 1600w • Variable Speed • 2 Gear SettinGS • 160mm mixinG paddle INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 07/14...
-
Page 2: Specifications
SPECIFICATIONS - MODEL NO. FBT-1600 Voltage: 230-240V ~50Hz Power: 1600W / 300-700min No Load Speed: 180-460min Speed Settings: Mixing Paddle Size: Ø160mm x 570mm Mixing Paddle Thread: M14 x 2.0mm Weight: 4.6kg KNOW YOUR PRODUCT 1. Side Handles 5. Collet 2. -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT........... Page 02 INTRODUCTION............Page 04 SAFETY INSTRUCTIONS........... Page 04 ASSEMBLY..............Page 08 OPERATION............... Page 09 MAINTENANCE............Page 11 TROUBLE SHOOTING ..........Page 12 DESCRIPTION OF SYMBOLS........Page 12 CONTENTS..............Page 13 WARRANTY.............. -
Page 4: Introduction
INTRODUCTION Congratulations on purchasing a Full Boar Multi Purpose Mixer. Your Full Boar Multi Purpose Mixer FBT-1600 has been designed to mix various materials such as paint, mortar, adhesives and plaster into consistent batches as required for the end user. - Page 5 GENERAL SAFETY INSTRUCTIONS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 6 GENERAL POWER TOOL SAFETY WARNINGS before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 7 MULTI PURPOSE MIXER SAFETY WARNINGS WARNING! Some dust created by power sanding, sawing, grinding, drilling and other construction activities contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints; • Crystalline silica from bricks, cement and other masonry products, and; • Arsenic and chromium from chemically-treated timber.
-
Page 8: Assembly
Assembling and Fitting the Mixing Paddle The Full Boar FBT-1600 comes with a mixing paddle that needs assembly before fitting to the multi purpose mixer. 1. Screw the mixing paddle into the end of the mixing shaft by rotating in a clockwise direction by hand (Fig. -
Page 9: Operation
OPERATION On/Off Trigger 1. To start the mixer, depress the on/off trigger (Fig. 3). Fig. 3 2. To stop the mixer, release the on/off trigger (Fig. 4). CAUTION: The mixing may take a few seconds to come to a complete stop once the on/off trigger is released. - Page 10 OPERATION Varying the Speed The multi purpose mixer has a variable speed dial and a gear selecting switch, which allows the mixer to obtain speeds from 180-700/min (1st gear: 180-460/min, 2nd gear: 300-700/ min). Adjusting the Variable Speed Lever 1. To reduce the speed rotate the variable speed dial by turning it to the left (Fig.
-
Page 11: Maintenance
MAINTENANCE • K eep the ventilation vents of the mixer clean at all times. • T o clean the mixing shaft and paddle first remove from the housing by unscrewing the collet. Then use water to wash off any unwanted material. • A fter each use, blow air through the mixer housing to ensure it is free from all dust particles which may build up. Build up of dust particles may cause the rmixer to overheat and fail. • I f the enclosure of the mixer requires cleaning, do not use solvents but a moist soft cloth only. Never let any liquid get inside the mixer; never immerse any part of the mixer into a liquid. -
Page 12: Troubleshooting
TROUBLESHOOTING Problem Cause Remedy Mixer is not working No power supplied Make sure all plugs are connected and power outlet is in working order Mixer not reaching Incorrect variable speed dial Rotate the variable speed dial to setting increase the max speed required speed Incorrect gear selection Change into 2nd gear using the... -
Page 13: Contents
CARING FOR THE ENVIRONMENT Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way. Please recycle where facilities exist. Check with your local council authority for recycling advice. Recycling packaging reduces the need for landfill and raw materials. -
Page 14: Warranty
WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 069 486 New Zealand 0508 069 486...
