CYLINDER HEAD GASKET

The head gasket uses carbon graphite as a parent material and the bore areas are made of stainless steel and given
improved durability.
AA
A–A' section

CYLINDER BLOCK

The cylinder block is made of a special cast iron and has a compact structure with no sleeves and a bore pitch
of 72 mm.
Cylinder Block
Crankshaft Bearing Cap
BB
B–B' section
Journal Bearing
Specifications
Bore diameter (mm): d
Stroke (mm)
Pitch (mm): p
Number of cylinders
Number of bearings
Parent material
Bore sections
Oil holes
Crankshaft
Thrust Bearing
65.0
66.0
72.0
3
4
Material
carbon graphite
stainless steel
copper
47
