  • Page 1 Unicont SPb Ltd Analog digital programmable converter ADPC-101 Technical Documentation (101-4-30102013) St. Petersburg 2013 v.4.1...
  • Page 2: Table Of Contents

    6. AUXILIARY MODE FOR DISPLAY OF SIGNAL STATUS AT INPUT TERMINALS........................12 7. ADDITIONAL DISPLAYING MODES ...............13 8. MENU FUNCTIONS AND CHANGING OF SETTINGS .........13 9. EXAMPLE OF CONNECTING ADPC-101 ..............17 10. TRANSPORTATION AND STORAGE ..............18 11. RECYCLING ........................19 12. WARRANTY ........................20 13.
  • Page 3: General

    Technical Documentation ADPC-101 General Thank You for purchasing our ADPC-101 navigation device. Design and production of this device are developed in compliance with applicable industrial standards for marine use. This device is mounted on ships with gyrocompasses and logs not capable to generate current values in NMEA format for navigation equipment needing course and speed data in digital form.
  • Page 4 Unicont SPb Ltd Technical Documentation ADPC-101 Rate of course variations (during vessel turning) up to 80 degrees/s 2. Log:  voltage pulses (stepper type interface);  “closing” contact  voltage up to 350V  100/200/300/400/500/600 pulses per mile Input specification ...
  • Page 5: Device Installation

    Unicont SPb Ltd Technical Documentation ADPC-101 Working temperature -20..+55 °C Storage temperature -60..+70 °C Weight 1.5 kg Overall dimensions 200 x 134 x 64 mm Device installation Mount unit in easy of access place, for example: vertical wall inside of ship.
  • Page 6 Unicont SPb Ltd Technical Documentation ADPC-101 Figure 1 ADPC-101 mounting dimensions Input channels Converter has four cable entries to route wires from external devices inside the device and to connect them to relevant terminals of terminal strips.  connect cables to terminal blocks of unit ...
  • Page 7 Unicont SPb Ltd Technical Documentation ADPC-101 Inputs: CS1-, CS1+, CS2-, CS2+, CS3-, CS3+, CSR-, CSR+. 1.1 Synchro type gyrocompass. Synchro type gyrocompass is connected as follows:  output of 1st winding is connected to contacts CS1+, CS3-;  output of 2nd winding is connected to contacts CS2+, CS1-.
  • Page 8 - input voltage is approximately 3V - input voltage is approximately 6V J10: ADPC-101 terminate channel of interface RS-422 ADPC-101 does not terminate channel of interface RS-422 Contacts J9 and JP1 use for programming and never using during exploitation of unit Page 8...
  • Page 9: Unicont Spb Ltd Technical Documentation Adpc

    Unicont SPb Ltd Technical Documentation ADPC-101 Figure 3 Wiring diagram for synchro type gyrocompass. Page 9...
  • Page 10 Unicont SPb Ltd Technical Documentation ADPC-101 Figure 4 Wiring diagram for stepper type gyrocompass. Page 10...
  • Page 11: Unit Operation

    Unicont SPb Ltd Technical Documentation ADPC-101 Unit operation Caution  Before device commissioning, at first complete installation procedure (see para. 4 “Device installation”) and connections (see p.4 “Device Installation”). 5.1 Device switch on procedure When power is applied, device transfers to review mode of course and speed values;...
  • Page 12: Auxiliary Mode For Display Of Signal Status At Input Terminals

    Unicont SPb Ltd Technical Documentation ADPC-101 Use key [SHIFT] key to change cases. The status of case can be visually defined by cursor status:  blinking cursor with illumination of font recticle – lower case;  no blinking (underlining) – upper case.
  • Page 13: Additional Displaying Modes

    Unicont SPb Ltd Technical Documentation ADPC-101  logic ‘0’ denotes that the contact is opened  logic ‘1’ denotes that the contact is closed. The unit will be in this mode until operator initiates exit by pressing on any key.
  • Page 14 Unicont SPb Ltd Technical Documentation ADPC-101 8.1 Gyrocompass tuning 8.1.1. GYRO ratio - 360x, 240x, 180x, 90x, 60x, 36x GYRO sign – direction of compass rotation: positive, negative. 8.1.2. GYRO type – gyrocompass type: selsyn, stepper. 8.1.3. Note Again enter the current compass value during switching of stepper/ synchro compass type.
  • Page 15 Unicont SPb Ltd Technical Documentation ADPC-101 LOG bounce delay – time for programmable deletion of contact 8.2.2. “bounce”: 10 ms, 20 ms, 30 ms, 40 ms, 50 ms, 70 ms, 100 ms. 8.3 Serial port tuning COM baudrate – baud rate, bit/s: 2400, 4800, 9600, 14400, 8.3.1.
  • Page 16 Unicont SPb Ltd Technical Documentation ADPC-101 NMEA LOG fmt – format of output NMEA line with current speed 8.8.4. value: Disabled - output of speed value is disabled VMVTG - $VMVTG,,,,,x.x,N,,*cs VMVBW - $VMVBW,x.x,,A,,,*cs (NMEA v 2.0) IIVTG - $IIVTG,,,,,x.x,N,,*cs IIVBW - $IIVBW,x.x,,A,,,*cs...
  • Page 17: Example Of Connecting Adpc-101

    Unicont SPb Ltd Technical Documentation ADPC-101 Example of connecting ADPC-101 Page 17...
  • Page 18: Transportation And Storage

    Unicont SPb Ltd Technical Documentation ADPC-101 Transportation and Storage The divice shall be stored in heated space at air temperature of +5 ºС to +35 ºС (maximum values of -55 ºС to +70 ºС), at relative humidity of air not exceeding 95 % at temperature of +25 °C and content of dust, oil, moisture and aggressive admixtures in the air not...
  • Page 19: Recycling

    Unicont SPb Ltd Technical Documentation ADPC-101 Recycling Do not recycle the packing of a new product, its parts with defects identified during its operation as well as the overage product as common household waste since they contain materials and raw materials suitable for their recovery.
  • Page 20: Warranty

    Unicont SPb Ltd Technical Documentation ADPC-101 Warranty The manufacturer guarantees the unit ADPC-101 complies with this manual provided that the operation, transportation and storage conditions are adhered to during the warranty period. The unit’s warranty period expires 24 months from the date of its shipping from the manufacturer’s storehouse.
  • Page 21: Date Of Packing

    Unicont SPb Ltd Technical Documentation ADPC-101 DATE OF PACKING № Analog digital programmable converter ADPC-101 name of article designation serial number Packed Unicont SPb Ltd., Russia. Manufacturer according to the requirements of the current technical documentation. post signature clarification of signature...
