- Page 1 user manual...
- Page 2 FEATURES Metallic headband inner structure. Premium comfort improved earcups. Unbeatable 7.1 virtual sound. Origen team special edition. Fully retractable LED microphone. In-line controller. Driver compatible with Windows 7, 8, 8.1 and 10. CONTENT Headphone with mic + inline controller with a USB connector.
- Page 3 SPEAKER SPECS. Driver Unit..................53mm Sensitivity..................97 dB Headphone Impedance..............32 Ω Max Input..................100mW Frequency Response..........10Hz - 20KHz MICROPHONE SPECS. Directivity...............Uni-directional Microphone Sensitivity.............-38 dB Impedance...................2.2k Ω Frequency Response..........50Hz ~ 20KHz Dimension................6 x 2,7mm...
-
Page 4: Installation
InstallatiOn GUIDE Ekho H80 Origen is compatible with PC. Go to www.ozonegaming.com, search for Ekho H80 Origen and down- load the drivers and software. Using the USB connector, plug the headset into any free USB port. Install the software following all the instructions in the installation window. Please... -
Page 5: Inline Controller
ekhO INLINE CONTROLLER Volume up Volume down Mute sound Mute microphone... - Page 6 * LED indicator on microphone: LED off when MIC is MUTED...
- Page 7 GUIDE COnfiguratiOn In the tray, click OZONE logo to pop-up the Ekho H80 Origen Control Panel Customize your own setting via adjusting the functions within control panel: Right clicking in the speaker icon a new speakers settings: menu pop-up and you can choose between differents options to set up...
-
Page 8: Volume Control
COnfiguratiOn speakers settings: 1. VOLUME CONTROL Adjust the master and front volume with the sliders, you can mute or lock L and R channels clicking in the icons. -
Page 9: Sample Rate
2. SAMPLE RATE Choose the sample rate quality, you can choose between 44.1 KHz or 48 KHz sample rates. - Page 10 3. EQUALIZER Choose the eq preset that suits more your gaming style or create a new one and store it in the manual input box.
-
Page 11: Environment Effects
4. EnvirOnment effects If you enable the environments effects, two new options will be available for you to set up. You can pick an environment to apply and manage the room size to have a better sound experience. - Page 12 5. 7.1 ch virtual speaker Setting on the 7.1 ch virtual speaker will give you full access to configure your sound channels individually. Clicking in the left side icons you can rotate and move the speakers to fit your sound preferences.
- Page 13 6. sOUND FX You can adjust the sound special effects clicking in the desired box and moving the sliders to configure the key shifting and vocal fading effects.
- Page 14 7. surrOUND MAX You can turn on the surround max feature clicking in the box but only if you previously turned on the 7.1 ch virtual speaker.
- Page 15 micrOphOne settings: 1. VOLUME CONTROL Adjust the mic-in and monitor volume with the sliders, you can mute them clicking in the icons.
- Page 16 2. SAMPLE RATE Choose the sample rate quality, you can choose between 44.1 KHz or 48 KHz sample rates.
-
Page 17: Voice Effects
3. vOice effects Enable the voice effects clicking on them. Set the microphone echo moving the slider and choose a magic voice effect clicking in the desired icon. - Page 18 4. micrOPHONE BOOST This feature is enabled by default, to disable it just click on the box.
- Page 19 This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste. For more information, contact the retailer or the local authorities in charge of waste management. ©2016 OZONE Gaming Gear. All rights reserved.
- Page 20 WWW.OZONEGAMING.COM...
